- Page 1 Ion Pro RT Ion 200 RT Flare RT...
-
Page 2: About This Manual
About this manual This manual is for Bontrager lights Ion Pro RT, Ion 200 RT (headlights) and Flare RT (tail light). RT indicates light is rechargeable and remote controllable when paired with Bontrager Transmitr remote, PN 502865, or another ANT+ compatible device. - Page 3 List of parts You may have purchased one or more of the following lights. Ion Pro RT Ion 200 RT Flare RT Light Mount Quick Connect 16˚ Bracket for tail light Front of bike PN W533846 Quick Connect 0˚ Mounting Bracket Mounts to the seatpost or a rack.
-
Page 4: Battery Charging And Care
Status LED To turn on, double click (Ion Pro RT) (similar to a computer mouse) and single click (Ion 200 RT / Flare RT) the power button. To turn off, press and hold the power button. To change mode, quick-press the power button. -
Page 5: Power Button
Model Status LED Charge, % Duration Color (hours) Red Flash <25% Yellow Flash 25% - 75% Ion Pro RT Green Flash 75% - 99% Green Steady 100% Red Flash 0% - 75% Ion 200 RT Green Flash 75% - 99%... -
Page 6: Caring For The Battery
WARNING The lights may be hot and could cause a burn or damage material it may contact. Do not activate (turn on) light in enclosed area. Avoid accidental wireless activation. Caring for the battery Store the light at room temperature in a dry place. Avoid moisture, or extreme hot or cold. -
Page 7: Installation
Ion Pro RT information, installation, and special features Installation 1. Loosen knob and open. 31.8mm 2. Adjust for bar size (31.8mm or 35mm). 35mm 3. Close and tighten knob. 4. Slide light onto mount until it locks in place. NOTE: Use provided shim to fit 25.4 bars. - Page 8 The Transmitr Remote (or select Garmin Edge computers, sold separately) allows remote control of the light. This feature is only available on the Ion Pro RT, Ion 200 RT, and the Flare RT as well as other compatible Transmitr lights.
- Page 9 Using the Transmitr Remote To turn on all lights ON: Quick-press the center button. OFF: Press and hold the center button. To turn on an individual light ON: Quick-press the corner button that controls the light. OFF: Press and hold the same button. To change modes of an individual light Each quick-press of a button that controls a light will cycle through the modes.
- Page 10 Ion 200 RT information, installation, and special features Installation To attach with the Quick Connect 0˚ offset bracket 1. Place the quick connect on the handlebar with the hook in front. 2. Stretch the strap under the bar and connect to the hook. NOTE: Use the second hook to latch excess strap.
-
Page 11: European Union Compliance
Ion Pro RT and Ion 200 RT do not comply with German StVZO regulations! Trek Bicycle Corporation and Bontrager hereby declare that the wireless device identified as ‘Ion Pro RT’, ‘Ion 200 RT’ and ‘Flare RT’ are in compliance with the following European Directives: •... -
Page 12: Fcc Compliance
Statements of Regulatory Compliance FCC Compliance Ion Pro RT FCC ID: 2AHXD-552373 Ion 200 RT/Flare RT FCC ID: 2AHXD553852 This device complies with part 15 of the FCC Rules. Operation is subject to the following conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. -
Page 13: Industry Canada Compliance
This Ion Pro RT lighting equipment complies with FCC and IC radiation exposure limits set forth for an uncontrolled environment. The radiated output power of the Ion Pro RT Wireless Device is below the Industry Canada (IC) radio frequency exposure limits, when used as directed in this manual (Note: attaching this light to a helmet changes the absorption characteristics of the light-body system). - Page 14 Fyshwick (ACT) 2609 AU Tel: +61 (02) 61 732 400 If you wish to see this manual in another language, please visit trekbikes.com/manuals and look for the Ion Pro RT/Ion 200 RT/Flare RT manual on the Manuals and user guides page.
