EN
Electronic Water Level
The Zircon
WL 25 Pro Electronic Water Level is an ideal tool
®
for determining level reference points up to 25 ft. (7.5 m) away.
The WL 25 Pro simplifies working alone or around corners with
accurate and reliable measurements and is ideal for a number
of applications, including erecting fences, building decks,
positioning drainage, plumbing, setting forms, completing masonry
work, or remodeling interiors. The WL 25 Pro features a 25 ft.
(7.5 m) hose, mounting bracket and screw, hose connector,
and filler nozzle.
Tube-Cleaning Brush
WL 25 PRO KIT ATTACHMENTS
WL 25 Pro Kit
Filler Nozzle
Mounting Bracket
Top Hose
Mounting Screw
Hose Clamp
Hose
ON/OFF
Switch
Sensing Tube
Level Line
Indicator
Power LED
Audio Output
Bottom Hose
Hose Connector
Hose Connector
Advertisement
Related Manuals for Zircon WL 25 Pro Kit
Summary of Contents for Zircon WL 25 Pro Kit
- Page 1 (7.5 m) hose, mounting bracket and screw, hose connector, and filler nozzle. Top Hose Hose Clamp Tube-Cleaning Brush Hose ON/OFF Switch Sensing Tube Level Line Indicator Power LED Audio Output Bottom Hose Hose Connector WL 25 PRO KIT ATTACHMENTS Filler Nozzle Hose Connector Mounting Bracket Mounting Screw...
-
Page 2: Installing Battery
INSTALLING BATTERY Press battery door release and remove door. Snap 9V battery onto connector and place inside battery compartment. Replace door and snap shut. ASSEMBLING THE WL 25 PRO Using the hose connector provided, attach one end of the long hose to the lower end of the short hose that passes through the body of the unit. - Page 3 You can also mount the WL 25 Pro above or below that reference point, measuring up or down from your marks to the desired position. Fasten the unit at both top and bottom to ensure stability. If the unit swings from side to side, your level points will change and give you inaccurate readings.
- Page 4 SLOWLY raise it again. open in a dry place and out of sunlight. The longer the working tube, hosing in 25 ft. (7.5 m) lengths. You can also call Zircon Customer the more time it takes for the ADDITIONAL HOSING IS AVAILABLE water levels to stabilize.
- Page 5 $10.00 to cover shipping and handling, will be repaired or replaced, at Zircon’s option. If the returned product is no longer available, Zircon may replace the product with a similar product of similar function. This is your sole and exclusive remedy for breach of this Limited Lifetime Warranty.
