- Page 1 HC68 High Performance Dual Beam E-focus Headlamp • Spotlight/Floodlight Adjustable • Auxiliary Red Light • USB-C Rechargeable Note: Please remove the insulation film before the first use.
-
Page 2: Specifications
Specifications Dimensions: 91.5mm × 34.75mm × 26.5mm (3.60" × 1.37" × 1.04") Weight: 118.5g (4.18oz) (Bracket and Headband Included, and Battery Not Included) 70g (2.47oz) (Bracket, Headband and Battery Not Included) Accessories NITECORE NL1835HP 18650 Li-ion Battery (3,500mAh), Spare O-ring, USB-C Charging Cable, Headband, Bracket Battery Options Nominal Type Compatibility Voltage NITECORE NL1835HP (3,500mAh) 18650 3.6V Y (Recommended) Button Topped 18650 Rechargeable 18650 3.6V/3.7V Y (Compatible) Li-ion Battery (Discharge Current Over 8A) Primary Lithium Battery CR123 Y (Compatible) Rechargeable Li-ion Battery RCR123 3.6V/3.7V Y (Compatible) Flat Topped 18650 Battery 18650 ─ N (Incompatible) Button Topped 18650 Rechargeable Li-ion 18650 ─ N (Incompatible) Battery (Discharge Current Below 8A) Note: DO NOT attempt to use the HC68 to charge CR123/RCR123 batteries. -
Page 3: Battery Installation / Removal
3.6V/3.7V Y (Compatible) Li-ion Battery (Discharge Current Over 8A) Primary Lithium Battery CR123 Y (Compatible) Rechargeable Li-ion Battery RCR123 3.6V/3.7V Y (Compatible) Flat Topped 18650 Battery 18650 ─ N (Incompatible) Button Topped 18650 Rechargeable Li-ion 18650 ─ N (Incompatible) Battery (Discharge Current Below 8A) Note: DO NOT attempt to use the HC68 to charge CR123/RCR123 batteries. Technical Data 100% SPOTLIGHT 100% FLOODLIGHT AUXILIARY RED LIGHT FL1 TURBO BEACON STANDARD HIGHER HIGH ULTRALOW HIGHER HIGH ULTRALOW HIGH FLASHING 1,800 950... - Page 4 2. CAUTION! Possible dangerous radiation! Don't look into the light! May be dangerous for your eyes. 3. When the power is low, please stop using the product and recharge the battery as soon as possible to avoid damage to the battery. 4. When the product is kept in a backpack or left unused for prolonged time, please remove all batteries to prevent accidental activation or battery leakage. 5. DO NOT submerge the headlamp into any liquid when it is hot. Doing so may cause irreparable damage to the light due to the difference of air pressure inside and outside of the tube. Battery Charging The HC68 is equipped with an intelligent charging system. As illustrated, tighten the battery cap after inserting the battery and unscrew the charging port cap until the charging port is fully exposed. Then use the USB cable to connect an external power supply (e.g. a USB adapter or other USB charging devices) to the charging port to begin the charging process. • During the charging process, the power indicator will flash slowly to inform the user. • When the battery is fully charged, the HC68 will cease the charging process and the power indicator will become steadily turned on to inform the user. • The charging time for an 18650 rechargeable Li-ion battery (3,500mAh) is approx. 3 hours. (Charged via the 5V/2A adapter) Primary White Light On/Off On: When the light is off, short press the Power Button to turn it on. Off: When the light is on, short press the Power Button to turn it off. (The HC68 has a memory function. When reactivated, the headlamp will automatically access the previous memorized status.) Brightness Levels When the light is on, short press the "+" Button each time to increase the brightness level in sequence from ULTRALOW to HIGHER. When the light is on, short press the "-" Button each time to decrease the brightness level in sequence from HIGHER to ULTRALOW. Spotlight/Floodlight Adjustment The HC68 has a spotlight/floodlight adjustment function. The output ratio of the...
-
Page 5: Power Indication
Low power Full power 1×18650 battery: 3.5V 3.7V 3.9V 4.2V Low power Full power 2×CR123 batteries: 4.8V 5.6V 6.0V 6.4V Note: When using two CR123/RCR123 in series, the indicator will show the average voltage between the two batteries. • When the light is off, short press the "+" / "-"button and the power indicator will flash to indicate the remaining power: 1. Flashing three times indicates that the power is above 50%. 2. Flashing twice indicates that the power is below 50%. 3. Flashing once indicates that the power is below 10%. ATR (Advanced Temperature Regulation) The integrated ATR technology regulates the output of the HC68 according to the working condition and ambient environment to maintain the optimal performance. Changing Batteries The batteries should be replaced when the output appears to be dim or the headlamp becomes unresponsive due to low power. Maintenance Every 6 months, threads should be wiped with a clean cloth followed by a thin coating of silicon-based lubricant. -
Page 6: Warranty Service
® local NITECORE distributor or send an email to service@nitecore.com ® ※ All images, text and statements specified herein this user manual are for reference purpose only. Should any discrepancy occur between this manual and information specified on www.nitecore.com, Sysmax Innovations Co., Ltd. reserves the rights to interpret and amend the content of this document at any time without prior notice. SYSMAX Innovations Co., Ltd. TEL: +86-20-83862000 FAX: +86-20-83882723 E-mail: info@nitecore.com Web: www.nitecore.com Address： Rm 2601-06, Central Tower, No.5 Xiancun Road, Tianhe District, Guangzhou,510623, Made in China Guangdong, China Please find us on facebook : NITECORE Flashlight Thanks for purchasing NITECORE! HC07016822...
