Tecnoalarm SIRTEC BUS Quick Manual

SIRTEC BUS - Self-powered indoor siren
General features
• RSC siren connectable via Siren Bus
• Programmable alarm sound type
• Free association to the programs
• Acoustic system status signaling
• Self-powered
• Protection against reverse polarity
• Programmable maximum sound time
• Protection against opening and detachment
• Guaranteed battery recharge with 10.5V
• Self test function for power supply voltage, battery and horn
Programming
The programming can be executed, locally or remotly, using a PC with the Tecnoalarm
software.
1
1 - Opening of the casing
Unscrew the locking screw
it to the right.
2
2 - Cable position
Insert the connection cable into the casing through the cable lead-in
C
groove .
3
D
D
3 - Wall fi xing
Fix the casing on a solid surface level with the ears
the anti-detachment protection
4
4 - Connection
Make the electrical connection of the siren using the terminals
INSTALLATION
A
A
with a 3mm Allen wrench, then lift the cover turning
A - +
B
JP1
SW1
1 2 3 4
C
A - +
B
SW1
1 2 3 4 1 2 3 4
E
E .
A - +
B
JP1
SW1
1 2 3 4
F
1 B
2 A
3 -
4 +
B
B
D
D
D
and the mounting hole for
Channel B serial bus
Channel A serial bus
Negative power supply
Positive power supply
B
or the
F
.
