Homelegance 9650NBE/DG-1 Assembly Instruction

Thank you for being our valued customer. Be sure to check all packing materials carefully for small parts which
have come loose inside the carton during shipment. Identify and count all items and compare them with the parts list
below.
CAUTION: Read the Instructions carefully before assembly.
1. We recommend that you should assemble this product with the assistance of another person; this will make
assembly easier, and will help to eliminate damage the product or injury to persons during assembly.
2. When you want to reposition the product, please always "LIFT & MOVE".
NOTE: Do not use power tools for assembly. Power tools increase the risk of over tightening which leads to splitting
or cracking the wood.
NO. DESCRIPTION
LSF ARM WITH USB
1
CHARGING PORT
RSF ARM
2
SEAT CUSHION FRAME
3
FRONT BASE
4
5
BACK REST
BACK CUSHION
6
PLASTIC LEG
7
L BRACKET
8
A
BOLT 5/16" X 2"
B
SPRING WASHER 5/16"
FLAT WASHER
C
5/16" X 22MM"
D
ALLEN KEY
E
SCREW M8x15mm
Note: Back rest: 1pc; back cushion 1pc; plastic leg: 4pcs; front base: 1pc and assemble hardware were stored in arm storage,
please take them out for assembly.
ASSEMBLY INSTRUCTION
ITEM NO: 9650NBE/DG-1
CHAIR WITH STORAGE POUCHES
& CHARGING PORTS
PART LIST
PART NAME
HARDWARE
Q'TY (PC)
1
1
1
1
1
1
4
2
9
9
9
1
4
PAGE 1 OF 4
