Pioneer AVH-P4150DVD/XN/RC Service Manual
  1. Manuals
  2. Brands
  3. Pioneer Manuals
  4. Stereo Receiver
  5. AVH-P4150DVD/XN/RC
  6. Service manual
Pioneer AVH-P4150DVD/XN/RC Service Manual

Pioneer AVH-P4150DVD/XN/RC Service Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
DVD AV RECEIVER
AVH-P4150DVD
AVH-P4150DVD
AVH-P4150DVD
AVH-P4150DVD
This service manual should be used together with the following manual(s):
Model No.
Order No.
CX-3250
CRT4300
DTS and DTS Digital Out are registered trademartks and the DTS logos and Symbol are
trademarks of DTS, Inc.
Manufactured under license from Dolby Laboratories. Dolby, Pro Logic, and the double-D
symbol are trademarks of Dolby Laboratories.
For details, refer to "Important Check Points for Good Servicing".
PIONEER CORPORATION
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2009
Mech.Module
LS1
DVD Mech. Module : Circuit Descriptions, Mech. Descriptions, Disassembly
4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
AVH-P4150DVD/XN/RC
/XN/RD
/XN/RI
/XNCN5
Remarks
ORDER NO.
CRT4276
/XN/RC
K-ZZZ. JAN. 2009 Printed in Japan

Advertisement

loading
Need help?

Need help?

Do you have a question about the AVH-P4150DVD/XN/RC and is the answer not in the manual?

Questions and answers

Related Manuals for Pioneer AVH-P4150DVD/XN/RC

Summary of Contents for Pioneer AVH-P4150DVD/XN/RC

  • Page 1 PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A. PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936 PIONEER CORPORATION 2009 K-ZZZ.

  • Page 2: Safety Information

    CAUTION Danger of explosion if battery is incorrectly replaced. Replaced only with the same or equivalent type recommended by the manufacture. Discord used batteries according to the manufacture's instructions. AVH-P4150DVD/XN/RC...
  • Page 3 To protect products from damages or failures during transit, the shipping mode should be set or the shipping screws should be installed before shipment. Please be sure to follow this method especially if it is specified in this manual. AVH-P4150DVD/XN/RC...

  • Page 4: Table Of Contents

    11.1 MOTHER PCB ............................. 168 11.2 DVD CORE UNIT ..........................172 11.3 CONNECT PCB ........................... 174 11.4 KEYBOARD UNIT..........................176 11.5 MONITOR UNIT........................... 178 11.6 SERVICE PCB ASSY .......................... 182 11.7 IF PCB ..............................184 12. ELECTRICAL PARTS LIST ........................185 AVH-P4150DVD/XN/RC...

  • Page 5: Service Precautions

    14. If the gasket (CNN2782) on the FM/AM tuner unit was damaged or lost, then the reception sensitivity would be poor. So, replace it with the new one. NOTE: When you remove the top case Don't put tweezers or something into these holes to remove the top Use these holes to remove the top case case. AVH-P4150DVD/XN/RC...

  • Page 6: Notes On Soldering

    Compared with eutectic solders, lead-free solders have higher bond strengths but slower wetting times and higher melting temperatures (hard to melt/easy to harden). The following lead-free solders are available as service parts: Parts numbers of lead-free solder: GYP1006 1.0 in dia. GYP1007 0.6 in dia. GYP1008 0.3 in dia. AVH-P4150DVD/XN/RC...

  • Page 7: Specifications

    2. SPECIFICATIONS 2.1 SPECIFICATIONS AVH-P4150DVD/XNCN5 Backup current ....... 2.2 mA or less AVH-P4150DVD/XN/RC...
  • Page 8 AVH-P4150DVD/XN/RC, AVH-P4150DVD/XN/RD, AVH-P4150DVD/XN/RI General Slope ....... –12 dB/oct Subwoofer (mono): Power source ......14.4 V DC (12.0 V to 14.4 V Frequency ......50/63/80/100/125 Hz allowable) Slope ....... –18 dB/oct Grounding system....Negative type Gain ......... +6 dB to – 24 dB Max.
  • Page 9 Usable sensitivity....25 μV (S/N: 20 dB) Signal-to-noise ratio..... 62 dB (IEC-A network) Infrared remote control Wavelength ......945 nm Output ........typ; 10 mw/sr per Infrared Note Specifications and the design are subject to mod- ifications without notice due to improvements. AVH-P4150DVD/XN/RC...

  • Page 10: Disc/Content Format

    DVD player for an hour or so to allow it to dry out and wipe any damp discs with a soft cloth to remove the moisture. • Road shocks may interrupt disc playback. AVH-P4150DVD/XN/RC...
  • Page 11 DVD Format/Logo Licensing Corporation. AVH-P4150DVD/XN/RC...

  • Page 12: Panel Facilities

    Press and hold to turn the source off. +/ – (VOLUME) buttons Press to increase or decrease the volume. MUTE button Press to turn off the sound. To turn on the sound, press again. (eject) button Press to eject a disc from this unit. AVH-P4150DVD/XN/RC...
  • Page 13 Press to change the subtitle language during DVD playback while using the built-in SUBTITLE button DVD player. Press to change the viewing angle during DVD playback while using the built-in ANGLE button DVD player. RETURN button Press to display the PBC (playback control) menu during PBC playback. AVH-P4150DVD/XN/RC...
  • Page 14 Press to move ahead one frame at a time during DVD/VideoCD playback. Press and STEP( ) buttons hold for one second to activate slow playback while using the built-in DVD player. STOP( ) button Press to stop playback while using the built-in DVD player. AVH-P4150DVD/XN/RC...
  • Page 15 • When operating the PBC menu by using 0 to 10. TV mode operation TV operations available with a Pioneer TV tuner (e.g. GEX-P5750TV(P)) can be controled with AVH mode. TV mode is not used with this unit. • For details concerning operation, refer to the TV tuner’s operation manuals.

  • Page 16: Connection Diagram

    2.4 CONNECTION DIAGRAM AVH-P4150DVD/XN/RC...
  • Page 17 AVH-P4150DVD/XN/RC...
  • Page 18 AVH-P4150DVD/XN/RC...
  • Page 19 AVH-P4150DVD/XN/RC...

  • Page 20: Basic Items For Service

    Item to be checked regarding video Item to be checked regarding audio Block-noise Distortion Horizontal noise Noise Dot noise Volume too low Disturbed image (video jumpiness) Volume too high Too dark Volume fluctuating Too bright Sound interrupted Mottled color AVH-P4150DVD/XN/RC...

  • Page 21: Pcb Locations

    Mother PCB Unit Number YWX5007 IF PCB Unit Name DVD Core Unit Unit Number CWN3791(RC) Unit Number Unit Number CWN3792(RD) Unit Name Connect PCB Unit Number CWN3793(RI) Unit Number CWN3789(CN5) Unit Name Mother Unit Unit Number Unit Name Keyboard Unit AVH-P4150DVD/XN/RC...

  • Page 22: Jigs List

    Jig No. Remarks Grease GEM1024 DVD Mechanism Module Grease GEM1038 DVD Mechanism Module Grease GEM1045 DVD Mechanism Module Locking agents 1401M Skew adjustment (1401M:produced by THREE BOND) Bond GEM1033 Skew adjustment Bond 1530 Skew adjustment (1530:produced by THREE BOND) AVH-P4150DVD/XN/RC...

  • Page 23: Cleaning

    3.4 CLEANING Before shipping out the product, be sure to clean the following portions by using the prescribed cleaning tools: Portions to be cleaned Cleaning tools DVD pickup lenses Cleaning liquid : GEM1004 Cleaning paper : GED-008 AVH-P4150DVD/XN/RC...

  • Page 24: Block Diagram

    COMPOSIT VGND DGND MOTHER PCB(SYSTEM) DGND IECOUT DGND MOTHER PCB(POWER SUPPLY) CPRST DGND MOTV HALFSW HOMESW OPENSW MOT5V PULSE1 CN121 PULSE0 40FY-BMGB(LF)(SN) MOT1 MOT0 CN2002 IF PCB JA2003 JA2002 JA2001 CN2001 MINI JACK B.CAM INPUT WIRED REMOTE NAVI INTERFACE AVH-P4150DVD/XN/RC...
  • Page 25 LCD MODULE CWX3691 CN6001 ADVY ADVY ADVX ADVX PLXV PLXV PLYV PLYV TH_G CN5001 CN501 JA402 FM/AM ANT JA141 P.B. MUTE B.REM BGSENS B.UP JA101 JA102 CN522 JA951 VCR IN RCA OUT JA2004 IP BUS AVH-P4150DVD/XN/RC...

  • Page 26: Block Diagram

    IC751 HA12241FP BUS- BUS- BUS- RXIE ROUT BUS- JA2001 WIREDAD WIREDAD WIREDAD WIRED WIRED WIRED WIRED REMOTE GNDD CN2001 Q601 Q771 TVON TVON TVON RGBON SYS+B SYS_TO_NAVI SYS_TO_NAVI SYS_TO_NAVI TXNADI NAVI_TO_SYS NAVI_TO_SYS NAVI_TO_SYS RXNAVI NAVI I/F CCSYNC CSYNC CSYNC AVH-P4150DVD/XN/RC...
  • Page 27 TO 2/2 M_SRX RXMON S_MTX TXMON MONRST MONIRST ILMB SWVDD33 ACC33 TO 2/2 PWRVI RGBON PWVI CN5001 TXNAVI PWRFL RXNAVI PWFL MONVBS RGB VIDEO ISOLATOR IC771 NJM2138V NAVI_R C_+IN C_OUT NAVI_G B_+IN B_OUT NAVI_B A_+IN A_OUT CSYNC D_+IN D_OUT AVH-P4150DVD/XN/RC...
  • Page 28 Q1341 P1341 MOTV BZ601 BEEP BUZZER PWFL XOUT Q1022 P1022 X601 PWFL 15MHz MFLPW TO 1/2 Q1021 CN801 OPENSW NC(OPENSW) MOT0 MOT0 MOT1 MOT1 PULSE0 PULSE0 PULSE1 DRIVE UNIT PULSE1 INTERFACE HALFSW HALFSW HOMESW HOMESW MOTV MOT5V TO 1/2 AVH-P4150DVD/XN/RC...
  • Page 29 AVH-P4150DVD/XN/RC...
  • Page 30 COIL W COIL_W CONT1 CTL1 CONT1 CONT2 CTL2 CONT2 HUP(HU+),HUM(HU-) HUP(HU+),HUM(HU-) FCO+ HVP(HV+),HVM(HV-) HVP(HV+),HVM(HV-) FCO- TKO- TKO+ HWP(HW+),HWM(HW-) HWP(HW+),HWM(HW-) HALL BIAS- HALL_BIAS- HALL BIAS+ HALL_BIAS+ VCC5 HOME S101 HOME HOME HOME S102 8SNS 08EJ 12cm S103 DSCSNS 12cm(DSCSNS) 12EJ AVH-P4150DVD/XN/RC...
  • Page 31 LDIN TEMP F+H_G+H F+H/G+H RFINP CONT1 E+G_E+F E+G/E+F CONT2 Q1102 Q1104 VREFH VREF LPCO2 78LD VIN1 VIN2 Q1101 Q1103 VIN4 LPCO1 65LD VIN3 VIN6 VIN5 PU (DP10) OSCO X1501 HOME CDMPD 78MD OSCI DVDMPD 65MD 08EJ TEMP VDSENS 12EJ AVH-P4150DVD/XN/RC...
  • Page 32 MVIPW (2/2) TOUCH PWCTL1 PVCC4 PLYV PNLYV PANEL SWVDD33 Q5403 OUT3 PWCTL2 (1/2) TOUCHAD PWCTL3 OUT4 Q5403 (2/2) ILMLD PLXV SWVDD33 Q5402 ILMCK Q5561 Q5504 (1/2) ILMDT PNLXV OUT5 Q5402 (2/2) REMIN CHARGE PUMP Q5503 REGULATOR KDT0 PWCTL2 KDT1 AVH-P4150DVD/XN/RC...
  • Page 33 LEDG2 Q5004 LEDB2 LEDB2 VCCM16V REMOTE CONTROL SENSOR SWVDD33 SWVDD33 U3001 OPT IN S3006 RS-470 EJECT KDT0 KDT0 Q5562 S3001 S3007 SOURCE MUTE KDT1 KDT1 S3002 S3009 FORWARD VOL+ S3003 S3004 REVERSE VOL- S3008 S3005 DISP,OFF RESET HDRST HDRST AVH-P4150DVD/XN/RC...

  • Page 34: Diagnosis

    ASENS = L? STANDBY : pin27 STANDBY = H? ASENBO : pin123 ASENBO <- H Standby VDCNT5 : pin25 VDCNT5,8 <- H VDCNT8 : pin26 Starts Communication with Display microcomputer Source keys operartive Source ON SYSPW : pin128 SYSPW <- H AVH-P4150DVD/XN/RC...

  • Page 35: Inspection Method Of Pickup Unit

    Perform lens Is it OK? cleaned? cleaning Replace the PICK UP Check point: Error rate check Error rate check PICK UP Perform lens Is it OK? cleaned? cleaning Replace the PICK UP Ckeck parts Finished other than PICK UP AVH-P4150DVD/XN/RC...
  • Page 36 60 - 390 (mV) 10 - 65 (mA) Expansion NO. Disc Check Point Threshold Remarks: LD current TCD-782 CDLD1-VCC5_3 60 - 360 (mV) 10 - 60 (mA) Expansion Notes: Please pay attention to the laser diode damage by static electricity. AVH-P4150DVD/XN/RC...
  • Page 37 GGV1025 ID: 40000 1.000E-03 less than GGV1025 ID: 200000 1.000E-03 less than TCD-782 ID: HOME Position 2.500E-03 Test mode display will not appear on the display of this product. Connect the rear monitor output to a monitor. AVH-P4150DVD/XN/RC...

  • Page 38: Diagnosis Flowchart

    5.3 DIAGNOSIS FLOWCHART AVH-P4150DVD/XN/RC...
  • Page 39 <Check> Check the voltage at the “STANBY” test point while the power is on. Use the “DGND1” test point at the reference. Specification value Check point Module No. Unit VCC33 V- STANBY-DGND1 0.6 V or more Side A STANBY Fig 1.1: STANBY check point AVH-P4150DVD/XN/RC...
  • Page 40 Unit 1 VDD5_1 - DGND1 5.0 ± 0.4 2 VCC33_1 - DGND1 3.3 ± 0.15 3 VCC12_1 - DGND1 1.2 ± 0.12 Side A VCC33_ 1 VCC12_ 1 DGND1 VDD5_ 1 Fig 2.2: VDD5, VCC33, VCC12 voltage check points AVH-P4150DVD/XN/RC...
  • Page 41 <Check> Check the voltage at the “XRES” test point while the power is on. Use the “DGND1” test point at the reference. Check point Module No. Specification value Unit VCC33 × 1 XRES-DGND1 0.7 or more Side A DGND1 NRES Fig 3.1: RESET check point AVH-P4150DVD/XN/RC...
  • Page 42 <Check> Check the voltage at the “VSENS” test point while the power is on. Use the “DGND1” test point at the reference. Specification value Check point Module No. Unit 1 VSENS - DGND1 0.95 - 1.07 VD8 = 8.0 ± 0.4 V Side A VSENS DGND1 Fig 4.2: VSENS check point AVH-P4150DVD/XN/RC...
  • Page 43 Specification value Check point Module No. Unit 27 MHz 2 IC1501 169pin ± 50 ppm Specification value Fig 5.2: Clock specification value Side A IC1501 158pin DGND1 Fig 5.3: 27 MHz check point AVH-P4150DVD/XN/RC...
  • Page 44 Be careful as XCSM, XWE, XCAS and XRAS of IC1480 are called differently in IC1501, namely NCSM, NWE, NCAS, NRAS. IC1501 MA0 - 11 1480 DV5U MDQ0 - 15 SDRAM XWE(NWE) XCAS(NCAS) XRAS(NRAS) XCSM(NCSM) DQM0 DQM1 Fig 6.1: SDRAM I/F AVH-P4150DVD/XN/RC...
  • Page 45 56 ohm ± 5 % IC1480 15pin IC1501 179pin 56 ohm ± 5 % DQM0 DQM1 IC1480 39pin IC1501 180pin 56 ohm ± 5 % IC1480 20pin IC1501 193pin 56 ohm ± 5 % IC1501 197pin IC1480 21pin 56 ohm ± 5 % AVH-P4150DVD/XN/RC...
  • Page 46 Side B Check point 1 (IC1480) Side A Check point 2 (IC1501) Fig 6.2: SDRAM I/F check point AVH-P4150DVD/XN/RC...
  • Page 47 Check point Module No. Specification value Unit VD8_1 - PGND3 8.0 ± 0.4 VD - PGND3 8.0 ± 0.4 VCC5_1- AGND1 5.0 ± 0.1 Side A AGND3 VCC5_ 1 PGND1 VD8_ 1 PGND3 Fig 7.2: VD8, VCC5 voltage check points AVH-P4150DVD/XN/RC...
  • Page 48 Check with PGND and GNDAU being the reference. Check point Module No. Specification value Unit VD - PGND_3 8.0 ± 0.4 AVCC5 - GNDAU1 5.0 ± 0.1 Side A AVCC5 PGND3 GNDAU1 Fig 8.2: VD8, AVCC5 voltage check points AVH-P4150DVD/XN/RC...
  • Page 49 Specification value 3 36.864 0 MHz ± 300 ppm DACCK 2.0 V~VCC33 V DGND~0.8 V DACCK 2.0 V~VCC33 V DGND~0.8 V 33.868 8 MHz ± 300 ppm Specification value 1 Specification Specification value 2 value 3 Fig 9.2: Clock specification value AVH-P4150DVD/XN/RC...
  • Page 50 Side B Check point 1 (DACCK stylus) Side A Check point 2 (IC1501 148 pin) DGND2 Fig 9.3: 27 MHz, DACCLK check point AVH-P4150DVD/XN/RC...
  • Page 51 Waveform 1 SRCK VCC33 V-0.6 V or higher 0.4 V or lower Waveform 2 LRCK VCC33 V-0.6 V or higher 0.4 V or lower Waveform 3 Specification value 2 Specification value 1 Fig 10.2: Serial 3 lines specification value AVH-P4150DVD/XN/RC...
  • Page 52 Side A DGND2 ADOUT LRCK Side B SRCK Fig 10.3: Serial 3 lines check points AVH-P4150DVD/XN/RC...
  • Page 53 GNDAU1 Fig 10.5: Analog audio out check point Check with DGND being the reference. Specification value 2 Check point 1 (stylus) Specification value 1 Reference waveform 6 IEC VCC33 V-0.6 V or higher 0.4 V or lower Waveform 5 AVH-P4150DVD/XN/RC...
  • Page 54 Side A IEC DGND2 Fig 10.6: Digital audio signal (IECOUT) check point AVH-P4150DVD/XN/RC...
  • Page 55 In case of NG, check the applicable line, the periphery of the major components in the drawing above, soldering of the peripheral components and defective components. PEAK Reference COMPOSITE signal value Color burst Pedestal level BOTTOM Horizontal sync signal Fig 11.2: Waveform for the case of composite white 100% output AVH-P4150DVD/XN/RC...
  • Page 56 Side A COMPOSITE GNDV Fig 11.3: VIDEO signal check point AVH-P4150DVD/XN/RC...
  • Page 57 (Refer to the FE test mode for the method of displaying the LD energizing time.) 2.If the second digit from the left of the energizing time display is showing E, such as “ E ”, it means that the flash memory has reached its life. Example: 0E000BB8 AVH-P4150DVD/XN/RC...
  • Page 58 In case of NG, check the applicable line, periphery of IC1501, soldering of the peripheral components and defective components. Specification value Check point Module No. Unit 48 MHz 2 IC1501 50pin-DGND1 ± 50 ppm Specification value Fig 13.2: Clock specification value AVH-P4150DVD/XN/RC...
  • Page 59 Side A IC1501 50pin DGND1 Fig 13.3: 48 MHz check point AVH-P4150DVD/XN/RC...
  • Page 60 1.USB Memory: Play a song from USB memory and check D+ and D- with the DGND standards. 2.iPod: Connect iPod and check CP_RESET, SDA and SCL with the DGND standards until the pioneer log appears. Play a song from iPod and check D+/D- with the DGND standards.
  • Page 61 Side A SDATA CP_ RESET SCLOCK DGND2 AVH-P4150DVD/XN/RC...
  • Page 62 -> -> Waveform 1 Waveform 4 CH1:SRCK CH1:IECOUT Reference voltage: DGND2 1 V/div. 5 usec/div Reference voltage: DGND2 1 V/div. 500 nsec/div G-> G-> Waveform 2 Waveform 5 CH1:LRCK Reference voltage: DGND2 1 V/div. 5 usec/div G-> Waveform 3 AVH-P4150DVD/XN/RC...
  • Page 63 VIDEO [WHITE 100IRE] CH1:COMPO Reference voltage: GNDV1 200 mV/div. 10 usec/div Waveform 6 USB memory USB memory USB memory Reference voltage:DGND 1 ms/div 2 V/div Reference voltage:DGND 200 ns/div 2 V/div Waveform 7 Waveform 8 AVH-P4150DVD/XN/RC...
  • Page 64 Reference voltage:DGND 200 ns/div 2 V/div Waveform 9 Waveform 10 iPod iPod Reference voltage:DGND 2 ms/div 1 V/div Reference voltage:DGND 20 ms/div 1 V/div CP_RESET DGND NRES Waveform 11 Waveform 12 iPod Reference voltage:DGND 500 us/div 1 V/div Waveform 13 AVH-P4150DVD/XN/RC...

  • Page 65: Error Code List

    CBW and CSW forwarding error ERROR-02-D1 CBW and CSW forwarding error Audio class band securing failure ERROR-02-D8 Audio class band securing failure Audio class FS setting failure ERROR-02-D9 Audio class FS setting failure Undefined Error ERROR-FF-FF Undefined error AVH-P4150DVD/XN/RC...
  • Page 66 *5 AWM (Audio WaterMark): Electronic watermark. Information on the copyright owner or CCI (copy control information) are recorded so that illegally copied discs can be identified. *6 Notice as an error status will not be given *7 CPRM(Content Protection for Recordable Media) : A copyright protection technique for digital contents used for re-writable DVD or memory card. (DVD-VR model only) AVH-P4150DVD/XN/RC...
  • Page 67 AVH-P4150DVD/XN/RC...

  • Page 68: Connector Function Description

    6. DVDVBS 11. BUSL- 20. TVON 7. GNDDVD 8. YS 21. GION 9. NC 22. MONON 10. CCAUL 23. VSW5 11. CCAUR 24. SYS_TO_NAVI 12. GNDAU 25. NAVI_TO_SYS 26. GNDD 13. ONSEI+ 1. USB5V 2. D- 3. D+ 4. USBGND AVH-P4150DVD/XN/RC...

  • Page 69: Service Mode

    Choose "Version Check" among the monitor test mode menu screen. [Display specifications] When 4 digits of read number is strange, "---" is displayed. ex) ---1x34 "CONNECT" is indicated at the time of the Navigation connection. [Operation specification] Operational description Remote controller key Return to test mode mene AVH-P4150DVD/XN/RC...
  • Page 70 In case the EEPROM initialization has been performed. In case the adjustment value has been initialized. 16 points adjustment : In case the 16 points adjustment has never been performed. In case the EEPROM initialization has been performed. In case the adjustment value has been initialized. AVH-P4150DVD/XN/RC...
  • Page 71 X/Y information of [MIN] and [MAX] of the outermost circumference are displayed. [BEFOR] indicates the value stored in the EEPROM. [AFTER] indicates MIN/MAX of the A/D value currently captured. [Operation specification] Operational description Remote controller key Return to top mene AVH-P4150DVD/XN/RC...
  • Page 72 Order of display of the locations to be pressed. This point is intended to end the calibration inspection, and therefore, the corrected value of this point is not obtained. [Operation specification] Operational description Remote controller key Return to top mene AVH-P4150DVD/XN/RC...
  • Page 73 : The coordinate (X direction, Y direction) which is the result of adding the correction by calibration to the normalized coordinate is displayed. Movable "+" cursor is displayed in red. 16 calibration points are displayed in white. [Operation specification] Operational description Remote controller key Return to top mene AVH-P4150DVD/XN/RC...
  • Page 74 The incorrect touch will make the characters of cursor turn red. Repeat this for 4 points, and “OK” is displayed upon the last press of 4th point. [Display specifications] confirming The pushing order [Operation specification] Operational description Remote controller key Return to top mene AVH-P4150DVD/XN/RC...
  • Page 75 In case the outermost circumference inspection of the calibration for line or the 16-point adjustment is normally terminated after normal termination of the outermost circumference inspection for user calibration. When the adjusted value has been initialized (Data initialize). When the EEPROM has been initialized. [Operation specification] Refer to [Menu types in the mode]. AVH-P4150DVD/XN/RC...
  • Page 76 Dimmer external light point (high) : 255 Dimmer external light point (medium) : 135 Dimmer external light point (low) : 0 Dimmer backlight point (high) : 196 Dimmer backlight point (medium) : 196 Dimmer backlight point (low) : 87 AVH-P4150DVD/XN/RC...
  • Page 77 Target arrival time : 1 LCD protection value at High temperature (8) Temperature value : 0 LCD protection value at High temperature (8) Dimmer output : 63 LCD protection value at High temperature (8) Target arrival time : 1 AVH-P4150DVD/XN/RC...
  • Page 78 RGB gamma correction setting B polygonal line position setting arrangement [3] : 31 RGB gamma correction setting B polygonal line position setting arrangement [4] : 39 RGB gamma correction setting B polygonal line position setting arrangement [5] : 47 AVH-P4150DVD/XN/RC...
  • Page 79 G drive adjustment +1 : 28 B drive adjustment +1 : 28 G drive adjustment +1 : 31 B drive adjustment +2 : 25 G drive adjustment +2 : 29 B drive adjustment +3 : 20 G drive adjustment +3 : 28 AVH-P4150DVD/XN/RC...
  • Page 80 Correction gain : 16 YUV DC transmission quantity correction setting DC transmission quantity correction polarity : 0 Brightness outline correction adjustment Correction tap select : 0 Brightness outline correction adjustment Correction gain : 2 Brightness outline correction adjustment Coring quantity : 10 AVH-P4150DVD/XN/RC...
  • Page 81 : 39 Synchronous separation Top curl adjustment (Weak electric field, Besides TV) Dmv2_ilgain1 Synchronous separation Top curl adjustment (Weak electric field, Besides TV) Dcs2_ilgain23 : 39 Synchronous separation Top curl adjustment (Weak electric field, Besides TV) Dmv2_ilgain23 : 39 AVH-P4150DVD/XN/RC...
  • Page 82 Top curl adjustment (Super-weak electric field, Besides TV) Dcs3_ilgain1 : 71 Synchronous separation Top curl adjustment (Super-weak electric field, Besides TV) Dmv3_ilgain1 Synchronous separation Top curl adjustment (Super-weak electric field, Besides TV) Dcs3_ilgain23 : 71 Synchronous separation Top curl adjustment (Super-weak electric field, Besides TV) Dmv3_ilgain23 AVH-P4150DVD/XN/RC...
  • Page 83 IVMODE setting : 10 Com part Brightness gain (ulNT358_CMB1_20) : 221 Com part Brightness gain (ulPALBG_CMB1_20) : 218 Com part Brightness gain (ulPALBG_CMB1_21) : 216 Com part Brightness gain (ulPALBG_CMB1_22) : 208 Com part Brightness gain (ulPALBG_CMB1_23) : 211 AVH-P4150DVD/XN/RC...
  • Page 84 AV input picture indication movement : 0 [Operation specification] Operational description Remote controller key Selection cursor up movement Selection cursor down movement Item content value up Item content value down Next menu page Former menu page Return to test mode mene AVH-P4150DVD/XN/RC...
  • Page 85 When normally ends, "success" is displayed. When will not end in four seconds, judged to be abnormal, "failure" is displayed. [Operation specification] Operational description Remote controller key Selection cursor left movement Selection cursor right movement Return to test mode mene Menu enter AVH-P4150DVD/XN/RC...
  • Page 86 [MONOCHROME STRIPE] Display of monochrome stripe signal (1dot Width) [Operation specification] Operational description Remote controller key Return to test mode mene [COLOR BAR] Display of color bar signal [Operation specification] Operational description Remote controller key Return to test mode mene AVH-P4150DVD/XN/RC...
  • Page 87 A white vertical line indicates the signal which moves from the right to the left. Drift to the left Cycle1 : 1 seconds Cycle2 : 2 seconds Cycle3 : 3 seconds [Operation specification] Operational description Remote controller key Return to test mode mene Cycle1 -> 2 -> 3 -> stop -> 1 AVH-P4150DVD/XN/RC...
  • Page 88 Display of Black/White signal [Operation specification] Operational description Remote controller key Return to test mode mene Next signal [CENTER MARKER] Display of signal for screen central location setting. [Operation specification] Operational description Remote controller key Return to test mode mene AVH-P4150DVD/XN/RC...

  • Page 89: Dvd Test Mode

    In order to F close after focus search (S character measurement mode), set to Power_OFF first then power on again FEMIN level before F close. ASMAX level ENVMAX level FE normalization coefficient Spindle gain coefficient TEMAX level indication TEMIN level indication AVH-P4150DVD/XN/RC...
  • Page 90 Designation of digit by command (1) and (2). UP/DOWN of numbers by command (3) and (4). Fix by command (5). Error occurrence at Power_OFF [Note] If an error occurs at Power_OFF, reset cannot be made. In such a case, it is necessary to turn the power off and start the test mode once again. Error display AVH-P4150DVD/XN/RC...
  • Page 91 [Note] If the power on time is 999999 hours or more, it is always reported as 999999 hours. [Note] If the power on time is “*E** ****”, the value may not be correct due to the life of the flash memory. AVH-P4150DVD/XN/RC...
  • Page 92 2: DVD Dual Layer Completion 3: CD 5 Return select 4: CD-RW CRG moves 5: Return to the most outer <Error> ERROR 1: Power OFF select Code : 00000000 Please Input Number <Error : Power OFF> ERROR Code : 00000000 Please Reset AVH-P4150DVD/XN/RC...

  • Page 93: Dvd Touch Panel Test Mode

    ->To clarify the true button position enables to judge the disc cause. 2.Display a cross-shape on the position that MS5AVcode2 thinks was pressed actually. ->To detect a gap in perception between HOST and mecha enables to judge the HOST cause. AVH-P4150DVD/XN/RC...

  • Page 94: Disassembly

    Case Unit.(Fig.4, 5) when it is difficult to remove the hook. Fig.5 Monitor Unit LCD Assy Disconnect the two cables and then remove the LCD Assy.(Fig.6) Disconnect the two cables.(Fig.6) Remove the five screws and then remove the Monitor Unit. Fig.6 AVH-P4150DVD/XN/RC...
  • Page 95 Because the Holder may be deformed.(Fig.10) Case Holder Remove the four hooks with Tweezers and then remove the Case.(Fig.11) Fig.11 Removing the Panel Unit (Fig.12) Panel Unit Remove the six screws. Remove the two hooks and then remove the Panel Unit. Fig.12 AVH-P4150DVD/XN/RC...
  • Page 96 Heat Sink. (Fig.14) Heat Sink Remove the Holder. (Fig.14) Fig.14 Remove the four screws and then remove Chassis(Upper) while holding both edges of the gasket. (Fig.15) *If the gasket was damaged or lost, replace it with the new one. Chassis(Upper) Fig.15 AVH-P4150DVD/XN/RC...
  • Page 97 Mother Unit. Fig.16 NOTE: When you remove the top case Don't put tweezers or something into these holes to remove the top Use these holes to remove the top case case. REASON: The rear panel may be deformed. AVH-P4150DVD/XN/RC...
  • Page 98 How to have it 1.Have a specified part. Handling OK Handling NG AVH-P4150DVD/XN/RC...
  • Page 99 (Precaution) If the PU goes to the outer most periphery, it idles. It is not a problem, but please try not to let it idle as much as possible. GND the brown line 4V to the gray line Fig. 1 Fig. 2 Connector (relay FFC) Relay FFC AVH-P4150DVD/XN/RC...
  • Page 100 Fig. 1 T-case washer Drive gear Fig. 2 c.Clamp state with no disc loaded a.Ejecting state b.Open-lock state There is a There is space no space AVH-P4150DVD/XN/RC...
  • Page 101 6.As in the Figures, while supporting the location A with your fingers, Fig. 6 screw the relay PCB. (Fig. 7 / Fig. 8) 7.Solder the lead for the CRG motor. 8.Fit the relay FFC to the connector. Fig. 7 Fig. 8 AVH-P4150DVD/XN/RC...
  • Page 102 (Precaution) The relay FFC must be removed for certainty in order to prevent the IC damage. 2.Apply 1.5V to the CRG motor and then transfer the PU to the outer periphery. (Precaution) Do not forget to reinstall the relay FFC after sending the PU to the outer periphery and take the necessary measures. AVH-P4150DVD/XN/RC...

  • Page 103: Each Setting And Adjustment

    Laser didoes may be damaged, if the volume switch for the minus side of the probe, the body frame of the the laser power adjustment of the pick up unit, is turned. measurement device should be set to floating ground. AVH-P4150DVD/XN/RC...
  • Page 104 Oscilloscope Symptom in case the adjustment is not adequate: Worsening of the error rate 10 (Normally 10 or less.) Large RF jitter RF waveform distortion Tracking drawing/Unstable servo * Caution: Do not look into the laser light during adjustment. AVH-P4150DVD/XN/RC...
  • Page 105 Next, slightly turn the skew adjusting screw B so the level would reach its maximum. Slightly turn the skew adjusting screw A again so the level would reach its maximum. (Make adjustment in the order of A->B->A and in the end complete adjustment by turning each screw in the clockwise direction.) AVH-P4150DVD/XN/RC...
  • Page 106 5: CRG Move Outer 6: Eject Please Input Number 12. In order to produce the clamping state with no disc loaded, slightly move the disc detection arm in the counterclockwise direction while moving the switch arms outward. Switch arms AVH-P4150DVD/XN/RC...
  • Page 107 1: Power OFF CRG Move Outer 1: Power OFF Please Input Number 15. TEST MODE Select “6: Eject.” TEST MODE 1: LD ON 2: ASMAX 3: Skew Adjustment 4: Error Rate 5: CRG Move Outer 6: Eject Please Input Number AVH-P4150DVD/XN/RC...
  • Page 108 Locations to make SKEW adjustment Locations to adhere the SKEW 1,2,3: BOND QUICK MENDER AVH-P4150DVD/XN/RC...
  • Page 109 Bond for resonance 4:Three Bond 1530 adhesive Bond for locking the screw 5,6 : Three Bond 1401M Bond for locking the screw AVH-P4150DVD/XN/RC...
  • Page 110 Precautions on handling the PU *Precaution: Do not touch those shaded areas in the following figures. Hologram (Beware of the static) Do not touch the optical part RF level adjusting part Do not touch the spring AVH-P4150DVD/XN/RC...

  • Page 111: Monitor Unit Adjustment

    8.2 MONITOR UNIT ADJUSTMENT MONITOR UNIT(SIDE B) - Adjustment Point VCC33 PWRVI -16V MONVBS COMDC AVH-P4150DVD/XN/RC...
  • Page 112 AVH-P4150DVD/XN/RC...
  • Page 113 AVH-P4150DVD/XN/RC...

  • Page 114: Pcl Output Confirmation

    The frequency of the clock signal is 625 000 Hz that is one 32th of the fundamental frequency. The clock signal should be 625 000 Hz (- 10 Hz, + 15 Hz). If the clock signal out of the range, the X’tal (X601) should be replaced with new one. AVH-P4150DVD/XN/RC...

  • Page 115: Exploded Views And Parts List

    Therefore, when replacing, be sure to use parts of identical designation. Screw adjacent to mark on the product are used for disassembly. For the applying amount of lubricants or glue, follow the instructions in this manual. (In the case of no amount instructions,apply as you think it appropriate.) AVH-P4150DVD/XN/RC...

  • Page 116: Packing

    9.1 PACKING AVH-P4150DVD/XN/RC...
  • Page 117 CXE1475 Contain Box See Contrast table(2) Protector CHP3709 Sheet CNN3089 CNV8969 (2) CONTRAST TABLE AVH-P4150DVD/XN/RC, AVH-P4150DVD/XN/RD, AVH-P4150DVD/XN/RI and AVH-P4150DVD/XNCN5 are con- structed the same except for the following: Mark Description AVH-P4150DVD/XN/RC AVH-P4150DVD/XN/RD AVH-P4150DVD/XN/RI AVH-P4150DVD/XNCN5 Unit Box CHG6731 CHG6732 CHG6733 CHG6734...

  • Page 118: Exterior(1)

    9.2 EXTERIOR(1) AVH-P4150DVD/XN/RC...
  • Page 119 CKM1376 IC(IC1061) NJM2388F84 Jack(JA951) CKN1042 Sheet See Contrast table(2) Jack(JA2002) CKN1077 (2) CONTRAST TABLE AVH-P4150DVD/XN/RC, AVH-P4150DVD/XN/RD, AVH-P4150DVD/XN/RI and AVH-P4150DVD/XNCN5 are con- structed the same except for the following: Mark Description AVH-P4150DVD/XN/RC AVH-P4150DVD/XN/RD AVH-P4150DVD/XN/RI AVH-P4150DVD/XNCN5 Mother Unit CWN3791 CWN3792 CWN3793 CWN3789...

  • Page 120: Exterior(2)

    9.3 EXTERIOR(2) AVH-P4150DVD/XN/RC...
  • Page 121 CKS5561 Connector(CN6101) CKS5561 Connector(CN5003) CKS5629 Connector(CN6001) CKS5773 Connector(CN5001) CKS5957 CWX3691 Case Unit CXE1249 Cushion CNN1325 Screw IMS20P030FTC Cord Assy CDP1166 CNS1472 Resistor RS1/2PMF102J Button Unit CXE1271 Remote Control Unit CXE1475 Cover CZN7062 Spacer CNN2602 Spacer CNN3066 Keyboard Unit CWN3799 AVH-P4150DVD/XN/RC...

  • Page 122: Exterior(3)

    9.4 EXTERIOR(3) Spreads it on the entire gear GEM1024 GEM1043 GEM1048 AVH-P4150DVD/XN/RC...
  • Page 123 Bracket ENC1586 Insulator ENM1048 Spacer ENM1049 Insulator ENM1051 Arm(White) ENV1615 Gear ENV1616 Gear ENV1617 Gear ENV1618 Roller ENV1619 Rack ENV1620 Arm(Black) ENV1623 Frame Unit EXA1669 Motor Unit EXA1674 Chassis Unit EXA1687 Service PCB Assy EXX1058 Cord(White) EDC1024 Cord(Orange) EDC1025 AVH-P4150DVD/XN/RC...

  • Page 124: Dvd Mechanism Module

    ( A ) ( C ) ( A ) ( A ) ( C ) ( A ) ( C ) ( C ) ( C ) ( C ) (A) : GEM1045 (B) : GEM1038 (C) : GEM1024 AVH-P4150DVD/XN/RC...
  • Page 125 CNW1170 Guide CNW1171 Roller CNW1172 CNW1173 CNW1174 Roller CNW1175 Lever CNW1176 CNW1177 CNW1178 Gear CNW1180 Gear CNW1181 Gear CNW1182 Gear CNW1183 Rack CNW1184 Gear CNW1185 Gear CNW1186 Gear CNW1187 Gear CNW1188 Clamper CNW1190 CNW1191 CNW1192 Holder CNW1193 Holder CNW1194 AVH-P4150DVD/XN/RC...
  • Page 126 ( C ) ( C ) ( C ) ( C ) ( C ) ( C ) ( C ) ( A ) ( A ) ( A ) (A) : GEM1045 (B) : GEM1038 (C) : GEM1024 AVH-P4150DVD/XN/RC...
  • Page 127 AVH-P4150DVD/XN/RC...

  • Page 128: Schematic Diagram

    LOUT2 C321 R310 GNDV mini mini C332 VCR_L R307 GNDA L2-1 ROUT2 C323 R312 1u/10 VCR_LGND L2-2 LOUT1 1u/10 VCC2 ROUT1 B.CAM BIAS2 R5-2 C307 0.1u/10 GNDV GND2 R5-1 C308 0.1u/10 R319 GNDA R320 R321 R314 GNDA GNDA ANALOGBUS AVH-P4150DVD/XN/RC...
  • Page 129 AUX:+35.3 dBs CTF1295-A USB(AUX):+34.0 dBs USB(LS1):+35.2 dBs VCR:+35.3 dBs uCOMBUS DVD/CD:+35.2 dBs GNDD RCAOUT MUTE&VCRIN IP-BUS&NAVI&WIRED PW CONNECTOR CHIP SIZE LEGEND SENS E.VOL CAPTAIN6 1608 MOTHER UNIT AV SELECTER 2125 Consists of MONITOR VBS ADJUST 3216 MOTHER PCB IF PCB AVH-P4150DVD/XN/RC...

  • Page 130: Mother Pcb(Tuner)

    TUNDI R432 TUNCK S_TTUN R412 R433 TUNCE1 TUNCK R413 TUNCE R414 R434 TUNCE2 TUNCE2 R415 R435 TUNSL TUNSL R416 L402 TUN8V SYS+B 8.4V MAX.140mA FM_ANT RF_GND L401 AM_ANT GNDRF JA402 GNDRF MOTHER UNIT Consists of MOTHER PCB IF PCB AVH-P4150DVD/XN/RC...
  • Page 131 AVH-P4150DVD/XN/RC...

  • Page 132: Mother Pcb(System)(Guide Page)

    MS_SRX NC(OPENSW) 100k GNDD S_MSTX TXLS1 R671 MOT0 MOT0 R670 MOT1 MOT1 PULSE0 R657 PULSE0 PULSE1 RXIE HALFSW R656 PULSE1 TXIE VDD33 IP-BUS DRIVER R753 5.1V IC751 CN601 R755 STBY DIN1 GNDD ROUT BUS+ DIN2 R754 BUS- HA12241FP GNDD AVH-P4150DVD/XN/RC...
  • Page 133 NC10 MONITOR BUS 11 12 13 14 15 CHIP SIZE LEGEND 1608 MONITOR UNIT USB I/F 2125 ipod CP 3216 SYSTEM MICOM IP-BUS DRIVER RGB VIDEO ISOLATOR DRIVE UNIT S/PDIF OUT MOTHER UNIT Consists of MOTHER PCB IF PCB AVH-P4150DVD/XN/RC...
  • Page 134 AVH-P4150DVD/XN/RC...
  • Page 135 AVH-P4150DVD/XN/RC...
  • Page 136 AVH-P4150DVD/XN/RC...
  • Page 137 AVH-P4150DVD/XN/RC...

  • Page 138: Mother Pcb(Power Supply)

    E1 1 6 C1 (1.0A) Q1121 TP1142 BR/CTL R1148 TK11840L GNDDD GNDHI DTC143EUA Q1143 370kHz/416kHz HIOUTCLK GNDHI VDCNT5 VDCNT8 R1382 MOT5V & MOTV > MOTV Q1341 8.1V CTH1358-A-T 2SD2153(VW) > TP1207 L1209 MOT5V P1203 L1381 CEK1285-A Q1381 (2.5A) GNDDDC AVH-P4150DVD/XN/RC...
  • Page 139 370kHz/416kHz GNDDDC The > mark found on some component parts indicates MOTHER UNIT the importance of the safety factor of the part. Consists of Therefore, when replacing, be sure to use parts of MOTHER PCB identical designation. IF PCB AVH-P4150DVD/XN/RC...

  • Page 140: If Pcb

    R2008 TP2030 ONSEI+ CCAUL ONSEI- CCAUR TP2020 GNDAU TVON TP2021 GUIDEON ONSEI+ TP2022 SYS_TO_NAVI ONSEI- NAVI_TO_SYS REAUR GNDD REAUL GNDRAU CCREM TP2023 R2002 DSEN R2010 TP2024 TVON GION MONON VSW5 R2005 TP2025 SYS_TO_NAVI R2009 TP2026 NAVI_TO_SYS GNDD GNDD GNDD AVH-P4150DVD/XN/RC...
  • Page 141 GNDAU NAVI I/F WIRED REMOTE ONSEI+ ONSEI- TP2001 TP2002 R2012 REAUR WIREDAD JA2001 WIRED REAUL R2011 GNDD GNDRAU CCREM DSEN C2005 TVON 0.1u/50 GION GNDD GNDD MONON VSW5 SYS_TO_NAVI NAVI_TO_SYS GNDD MOTHER UNIT Consists of MOTHER PCB IF PCB AVH-P4150DVD/XN/RC...

  • Page 142: Dvd Core Unit(Guide Page)

    LDIN LDIN TKO+ PGND R1204 TOP2 CRGDRV R1203 SLOPOUT CRGDRV TKO- 37 SLIN 3 FCIN PREVcc 2 TKIN C1207 PREGND VHALF VHALF SUBGND Vss1 R1406 Vss1 100K IC1201 PGND2 PGND1 BD8231EFV GNDD XCSF2 XCSF1 CWW1754 PGND CWW1753 R1409 GNDD AVH-P4150DVD/XN/RC...
  • Page 143 TEMP R1217 TEMP R1300 DVDLD1 HALL_V+ <TC7SZ126FU> IC1006 VCC33 R1111 R1116 TEMP GND R1218 HALL_V- TOP1 HALL_U+ Q1103 2SB1132 HALL_U- LPCO1 Q1101 HALL_BIAS- X:Don’t Care FOP1 2SC4081 Z:High Impedance CRG/LE- CRG/LE+ PGND GNDA GNDD PU(DP10) GNDD GNDA MOTOR DRIVER AVH-P4150DVD/XN/RC...
  • Page 144 AVH-P4150DVD/XN/RC...
  • Page 145 PICKUP UNIT (SERVICE) AVH-P4150DVD/XN/RC...
  • Page 146 AVH-P4150DVD/XN/RC...
  • Page 147 AVH-P4150DVD/XN/RC...

  • Page 148: Connect Pcb

    COIL U CSN1068-A COIL V CN1201 DSCSNS HALL W+ DSCSNS1 DSCSNS1_B DSCSNS0 DSCSNS0_B CSN1068-A HALL W- R103 HALL V+ S102 HALL V- HALL U+ HALL U- HALL BIAS- CRGP CRG+ CRGM LOAD/CRG MOTOR CRG- CXC4026 SPINDLE MOTOR EXM1050 CN101 AVH-P4150DVD/XN/RC...
  • Page 149 AVH-P4150DVD/XN/RC...

  • Page 150: Keyboard Unit

    RS-470 HDRST LEDB1 LEDB1 LEDG1 LEDG1 LEDR1 LEDR1 LEDB2 LEDB2 CN5003 LEDG2 LEDG2 LEDR2 LEDR2 KDT0 KDT1 ILMB ILMB SWVDD33 GNDKEY 8.0V D3005 GNDKEY NSSM038A-6430 0.1u/16 C3012 0.1u/16 C3013 0.1u/16 C3014 D3002 NSSM038A-6430 C3006 0.1u/16 C3007 0.1u/16 0.1u/16 C3008 AVH-P4150DVD/XN/RC...
  • Page 151 3.0~3.3V RS-470 GNDKEY KDT0 EJECT MUTE VOL+ VOL- DISP.OFF KDT1 SOURCE FORWARD REVERSE R3010 R3008 R3009 R3006 R3007 R3011 1.8k 3.9k 1.8k 3.9k EJECT MUTE VOL+ VOL- RESET SOURCE FORWARD REVERSE DISP.OFF GNDKEY CHIP SIZE LEGEND 1608 2125 3216 AVH-P4150DVD/XN/RC...

  • Page 152: Monitor Unit(Ucom)(Guide Page)

    LEDR2 GNDD GNDD GNDD Q5001 Q5003 Q5002 GNDD UMX1N UMX1N 2SC4081(QR) Q5004 GNDD 2SC4081(QR) PWRFL R5004 R5014 R5024 R5009 R5019 R5029 PWRFL PWRFL PWRFL PWRFL (RED) (GREEN) (BLUE) (GREEN) (BLUE) (RED) GNDFL GNDFL GNDFL GNDFL GNDFL GNDILM GNDILM GNDOSD AVH-P4150DVD/XN/RC...
  • Page 153 3 ILMB BR/CTL TH_G R6113 HDRST SWVDD33 GNDFL R6106 TK11840L CPH6424 LEDB1 GNDKEY LEDG1 GNDILM LEDR1 DIMMER Q6101 GNDOSD DTC143EUA ILMB GNDILM2 GNDFL GNDFL DTC143EUA GNDILM Q6103 GNDFL Basic oscillation frequency 360kHz GNDFL PWM (CONVERSION 478/528kHz) BLSYNC BLERR1 TEMPSEN AVH-P4150DVD/XN/RC...
  • Page 154 AVH-P4150DVD/XN/RC...
  • Page 155 TO BACKLIGHT AVH-P4150DVD/XN/RC...
  • Page 156 AVH-P4150DVD/XN/RC...
  • Page 157 AVH-P4150DVD/XN/RC...

  • Page 158: Monitor Unit(Monitor)(Guide Page)

    0.1u/10 VIDEO_AD GOUT0 GOUT1 VADSCL R5621 2.2k DVG_0 GOUT2 VADSDA DVG_1 GOUT3 C5606 0.1u/10 DVG_2 BYPASS GOUT4 R5622 R5607 AVDD7 GOUT5 2.2k DVG_3 AVSS11 GOUT6 MONVBS DVG_4 GNDV C5610 0.1u/10 GNDRGB 2.2k CSYNC R5623 NAVI_B VADRES NAVI_G NAVI_R GNDD AVH-P4150DVD/XN/RC...
  • Page 159 5401 A:+IN B:-IN 3225 R6153 R6154 C.VIDEO PART 5451 3.9k B:+IN DD-CON PART 5501 VIDEOA/D IC PART 5601 NJM082BV GNDD GERDA IC PART 5701 6001 GNDD LCD PANELPART 6151 BACKLIGHT PART 6101 GNDD R6158 COMDC VCCM16V COMDC VCOM PART AVH-P4150DVD/XN/RC...
  • Page 160 TO LCD MO AVH-P4150DVD/XN/RC...
  • Page 161 TO LCD MODULE AVH-P4150DVD/XN/RC...
  • Page 162 AVH-P4150DVD/XN/RC...
  • Page 163 AVH-P4150DVD/XN/RC...

  • Page 164: Service Pcb Assy

    10.11 SERVICE PCB ASSY AVH-P4150DVD/XN/RC...
  • Page 165 SERVICE PCB ASSY CN801 AVH-P4150DVD/XN/RC...

  • Page 166: Waveforms

    DVDRF(BD1mm) Interval FWD(DVD) Interval REV(DVD) 2.2 V-> VHALF VHALF TD1 0.2 V/div 500 us/div TD1 0.2 V/div 500 us/div CH1:TD1 0.5 V/div 10 ms/div Multi 32FWD(DVD) Multi 32REV(DVD) CH2:COP-COM 2.0 V/div 10 ms/div Traverse 1001FWD(short)(DVD) VHALF VHALF VHALF 0-> AVH-P4150DVD/XN/RC...
  • Page 167 Play TD (DVD) Focus Close (DVD) 0-> VHALF VHALF FD1 0.5 V/div 500 us/div FD1 0.5 V/div 500 us/div FD1 0.5 V/div 20 ms/div Play FD(DVD) Focus Jump L0 -> L1 Focus Jump L1 -> L0 VHALF VHALF VHALF AVH-P4150DVD/XN/RC...

  • Page 168: Pcb Connection Diagram

    R904 C1201 CN1901 C1203 C903 R1211 L1206 C904 C901 Q1202 C1229 L1209 P1203 CN101 R524 L1204 D1204 L1205 R568 R529 R530 R1381 IC561 C564 P1341 D1341 R562 C563 C561 R1343 C1381 C1341 CN801 C1343 L1381 CN521 Q1341 C1342 FRONT AVH-P4150DVD/XN/RC...
  • Page 169 C609 C371 Q561 R627 R668 R372 R371 C618 Q371 R568 C1025 C1082 R377 R375 IC561 IC602 R374 R373 R570 R620 R376 D601 R562 L1022 BZ601 C563 Q372 C561 CN5001 R501 C1021 Q801 R378 C1024 CN501 CN601 C802 C801 D801 AVH-P4150DVD/XN/RC...
  • Page 170 Q402 R643 C612 R603 R639 C409 R401 R429 R409 C608 R649 Q404 C605 R617 C619 R638 R642 R653 Q403 R625 D1021 D1081 P1021 R1024 R1025 C1085 L1021 P1022 C1083 Q1022 IC1081 Q1021 R803 R1027 C1022 R801 R804 R1026 R802 AVH-P4150DVD/XN/RC...
  • Page 171 C1234 R913 R914 R1219 R1220 R911 C1235 IC1201 R902 R1202 C1212 R903 Q901 R1212 R906 R915 R909 C1217 C1221 R905 Q902 C1220 R1213 C1219 R1218 R907 D1206 IC521 R1201 C522 R908 C523 IC522 R523 L521 R532 D522 D523 C524 AVH-P4150DVD/XN/RC...

  • Page 172: Dvd Core Unit

    C1522 R1524 R1509 R1538 C1503 C1622 C1624 C1620 C1619 C1621 L1512 C1625 C1618 C1615 C1616 C1614 C1612 C1611 C1610 R1605 C1623 C1601 C1603 C1608 R1102 C1607 R1110 C1604 R1104 R1675 R1679 R1101 R1673 R1008 C1018 R1204 R1202 R1201 C1208 AVH-P4150DVD/XN/RC...
  • Page 173 DVD CORE UNIT SIDE B C1950 C1486 C1485 R1489 C1407 C1493 C1408 C1480 C1490 C1301 AVH-P4150DVD/XN/RC...

  • Page 174: Connect Pcb

    11.3 CONNECT PCB CONNECT PCB SIDE A CN1201 CN701 LOAD/CRG MOTOR AVH-P4150DVD/XN/RC...
  • Page 175 CONNECT PCB SIDE B SPINDLE MOTOR S101 HOME CN101 DSCSNS R102 S102 R101 C101 8SNS R103 S103 AVH-P4150DVD/XN/RC...

  • Page 176: Keyboard Unit

    11.4 KEYBOARD UNIT KEYBOARD UNIT SIDE A C3006 R3008 C3014 C3015 R3001 C3012 AVH-P4150DVD/XN/RC...
  • Page 177 KEYBOARD UNIT SIDE B CN5003 AVH-P4150DVD/XN/RC...

  • Page 178: Monitor Unit

    R6158 C6153 R6021 R6155 C6154 R6020 R6156 C6151 L5454 R6013 C6156 R6017 C6106 C5460 Q6103 IC6151 R6016 R6104 R6012 R6022 C6155 R6112 R6160 R6152 R6151 R6014 R5033 R6010 R6011 L6004 L6001 C6102 C6103 R6101 L6101 C6101 P6101 LCD MODULE AVH-P4150DVD/XN/RC...
  • Page 179 C5401 R5605 C5460 R5401 R5604 D5401 D5403 Q5401 IC5001 R5607 R5606 R6022 R5406 R5405 C5408 C5006 D5001 C5017 C5011 C5402 D5405 R5403 CN5003 C5407 D5402 R5033 CN5401 CN5001 R5402 C5403 D5404 R5407 L6001 R5404 R6101 P6101 TOUCH PANEL CN501 AVH-P4150DVD/XN/RC...
  • Page 180 R5004 L5451 R5031 R5011 R5459 Q5402 C5456 R5015 C5001 Q5001 C5454 Q5451 C6010 R5005 C5455 C5003 R5463 IC5451 R5410 R5462 R5413 R5030 R5460 R5025 R5021 R5024 R5029 R5455 MONVBS C5009 R5026 R5458 Q5002 R5453 R5027 Q5004 R5454 R5028 R5452 AVH-P4150DVD/XN/RC...
  • Page 181 R6049 5467 Q6001 C5701 L5706 R5469 C5703 R5466 R6027 5457 R6039 C5458 R6008 R6029 L5453 R6025 C6158 R5468 C6012 L5452 Q6151 R6154 C5456 R6157 R6161 5451 C6010 R6159 C5455 C6152 R5463 R6153 R5462 R5460 R5455 IC6005 R5458 COMDC R6001 AVH-P4150DVD/XN/RC...

  • Page 182: Service Pcb Assy

    11.6 SERVICE PCB ASSY SERVICE PCB ASSY SIDE A CN801 AVH-P4150DVD/XN/RC...
  • Page 183 SERVICE PCB ASSY SIDE B AVH-P4150DVD/XN/RC...

  • Page 184: If Pcb

    11.7 IF PCB SIDE B SIDE A IF PCB IF PCB D2011 R2021 R2020 R2013 R2014 D2003 C2004 R2002 R2010 R2005 R2009 AVH-P4150DVD/XN/RC...

  • Page 185: Electrical Parts List

    : Mother Unit Q 1001 (B,30,83) Transistor 2SD1664 Q 1002 (B,25,74) Chip Transistor 2SB1132 MISCELLANEOUS Q 1021 (B,129,10) Transistor 2SC4081 Q 1022 (B,133,13) Chip Transistor 2SB1132 IC 181 (A,80,120) IC PA2030A Q 1141 (A,34,76) Transistor 2SC4081 IC 201 (B,134,92) IC PML018A AVH-P4150DVD/XN/RC...
  • Page 186 (A,36,84) Inductor LCTAW2R2J2520 R 126 (A,97,87) RS1/16SS223J L 162 (A,39,87) Inductor LCTAW2R2J2520 R 127 (A,94,87) RS1/16SS223J L 163 (B,49,76) Inductor CTF1295 R 128 (A,96,87) RS1/16SS102J L 201 (A,144,79) Inductor LCTAW2R2J2520 R 129 (A,93,87) RS1/16SS102J L 401 (B,152,84) Inductor LCTAW220J2520 AVH-P4150DVD/XN/RC...
  • Page 187 (A,141,36) (RC,RI) RS1/16SS104J R 317 (A,108,59) RS1/16SS680J R 632 (A,142,36) (RD,RI) RS1/16SS104J R 318 (A,108,61) RS1/16SS4R7J R 634 (A,140,33) (RC,RD,RI) RS1/16SS104J R 322 (B,87,57) RS1/16SS101J R 635 (A,141,33) (RD,CN5) RS1/16SS104J R 325 (B,97,51) RS1/16SS221J R 636 (A,142,33) (RC,CN5)) RS1/16SS104J AVH-P4150DVD/XN/RC...
  • Page 188 R 784 (B,57,85) RS1/16SS512J R 1203 (B,40,51) RS1/16SS2R2J R 785 (B,55,85) RS1/16SS681J R 1204 (B,46,52) RS1/16SS0R0J R 786 (B,61,85) RS1/16SS822J R 1205 (B,44,51) RS1/16SS151J R 787 (A,63,86) RS1/16SS472J R 1206 (B,43,52) RS1/16SS4702D R 788 (A,70,87) RS1/16SS472J R 1207 (B,43,50) RS1/16SS6801D AVH-P4150DVD/XN/RC...
  • Page 189 CKSRYB104K50 C 342 (B,90,55) CKSRYB105K10 C 165 (A,41,86) CKSRYB103K50 C 343 (B,90,53) CKSRYB105K10 C 166 (A,37,88) CKSRYB104K50 C 345 (A,98,50) CEVW221M4 C 167 (B,46,78) CKSRYB104K50 C 346 (A,106,50) CEVW101M6R3 C 181 (B,98,106) 10 uF DCH1201 C 347 (A,103,70) CEVW220M16 AVH-P4150DVD/XN/RC...
  • Page 190 Chip LED NSSM038A-6430 C 1023 (B,137,13) CKSYB475K16 S 3001 Switch(SOURCE) VSG1020 C 1024 (A,118,8) CEAT102M10(P30) S 3002 Switch(FORWARD) VSG1020 C 1025 (A,138,20) CEVW220M16 S 3003 Switch(REVERSE) VSG1020 C 1061 (A,11,91) CKSYB105K35 S 3004 Switch(VOL-) VSG1020 C 1081 (A,20,95) CEVW101M10 AVH-P4150DVD/XN/RC...
  • Page 191 Q 5502 (A,110,68) FET RSQ035P03 L 5714 (A,45,42) Inductor CTF1748 Q 5503 (A,98,53) Transistor 2SA1577 L 5715 (A,45,37) Inductor CTF1748 Q 5504 (A,98,56) Transistor 2SC4097 L 5716 (A,44,41) Inductor CTF1748 Q 5505 (A,96,67) Transistor IMZ4 L 5717 (A,43,38) Inductor CTF1748 AVH-P4150DVD/XN/RC...
  • Page 192 R 5102 (A,98,34) RS1/16SS471J R 5212 (A,53,60) RS1/16SS220J R 5103 (A,98,33) RS1/16SS471J R 5213 (A,52,69) RS1/16SS0R0J R 5104 (A,99,40) RS1/16SS0R0J R 5214 (A,50,60) RS1/16SS102J R 5105 (A,99,39) RS1/16SS0R0J R 5215 (A,52,68) RS1/16SS0R0J R 5106 (A,99,37) RS1/16SS471J R 5216 (A,50,67) RS1/16SS0R0J AVH-P4150DVD/XN/RC...
  • Page 193 R 5328 (A,23,67) RS1/16SS0R0J R 5517 (B,117,61) RS1/16SS512J R 5329 (A,24,66) RS1/16SS0R0J R 5518 (B,113,68) RS1/16SS223J R 5330 (A,25,66) RS1/16SS0R0J R 5519 (A,117,67) RS1/16SS150J R 5331 (A,26,66) RS1/16SS0R0J R 5520 (A,109,65) RS1/16SS150J R 5332 (A,26,68) RS1/16SS0R0J R 5521 (B,106,70) RS1/16SS563J AVH-P4150DVD/XN/RC...
  • Page 194 R 5709 (A,53,41) RS1/16SS0R0J R 5793 (B,90,33) RS1/16SS151J R 5710 (A,52,41) RS1/16SS103J R 5794 (B,34,47) RS1/16SS680J R 5795 (A,85,44) RS1/16SS151J R 5711 (A,52,39) RS1/16SS103J R 5712 (A,51,41) RS1/16SS103J R 5796 (B,30,47) RS1/16SS680J R 5713 (A,49,41) RS1/16SS0R0J R 5797 (A,86,45) RS1/16SS151J AVH-P4150DVD/XN/RC...
  • Page 195 R 5862 (B,71,66) RS1/16SS102J R 6012 (A,61,21) RS1/16SS18R0F R 5863 (B,32,66) RS1/16S0R0J R 6013 (A,61,24) RS1/16S1600D R 5865 (B,70,66) RS1/16S0R0J R 6014 (A,61,17) RS1/16SS15R0F R 5866 (B,33,66) RS1/16SS680J R 6015 (A,61,19) RS1/16SS82R0D R 5867 (B,34,66) RS1/16SS680J R 6016 (A,62,21) RS1/16SS12R0F AVH-P4150DVD/XN/RC...
  • Page 196 C 5519 (A,114,59) CKSRYB103K50 C 5101 (A,102,28) CKSQYB106K6R3 C 5520 (B,115,68) CKSRYB104K50 C 5102 (A,100,30) CKSSYB104K10 C 5521 (A,119,60) 10 uF CCG1223 C 5103 (A,99,35) CKSSYB104K10 C 5522 (A,116,60) 10 uF CCG1223 C 5104 (A,100,32) CKSSYB104K10 C 5525 (B,111,69) CKSRYB105K16 AVH-P4150DVD/XN/RC...
  • Page 197 C 5702 (A,53,47) CSZSR470M10 C 5763 (B,47,72) CKSSYB105K6R3 C 5703 (B,45,27) CCSSCH120J50 C 5764 (B,40,70) CKSSYB105K6R3 C 5704 (B,56,29) CCSSCH6R0D50 C 5765 (B,60,70) CKSSYB104K10 C 5705 (B,54,29) CCSSCH6R0D50 C 5766 (B,54,70) CKSSYB104K10 C 5707 (B,43,34) CKSSYB104K10 C 5767 (B,54,72) CKSSYB104K10 AVH-P4150DVD/XN/RC...
  • Page 198 (A,45,49) Transistor 2SB1132 R 1487 (B,64,5) RAB4CQ560J R 1488 (B,68,5) RAB4CQ560J L 1003 (B,22,26) Inductor CTF1677 R 1489 (B,59,5) RS1/16SS560J L 1004 (B,14,17) Inductor CTF1678 L 1512 (A,57,5) Inductor CTF1743 R 1490 (B,50,21) RS1/16SS560J L 1902 (B,5,8) Inductor CTF1487 AVH-P4150DVD/XN/RC...
  • Page 199 C 1503 (A,60,4) CKSSYB104K10 R 1952 (B,78,34) RS1/16SS105J C 1504 (A,51,5) CKSSYB104K10 R 1953 (B,74,34) RS1/16SS681J C 1505 (A,53,5) CKSSYB104K10 R 1954 (A,35,17) RS1/16SS153J C 1506 (A,55,5) CKSSYB104K10 R 1955 (A,40,14) RS1/16SS153J C 1507 (A,62,5) CKSSYB104K10 R 1956 (A,40,18) RS1/16SS0R0J AVH-P4150DVD/XN/RC...
  • Page 200 CKSQYB475K6R3 C 1803 (B,36,8) CCSRCH182J50 C 1804 (B,31,7) CCSRCH182J50 C 1805 (B,32,19) CKSSYB104K10 C 1806 (B,39,9) 10 uF DCH1201 C 1809 (B,43,16) CKSSYB104K10 C 1934 (B,42,29) CCSRCH680J50 C 1950 (B,73,33) CKSSYB104K10 C 1951 (B,74,36) CCSSCH100D50 C 1952 (B,78,36) CCSSCH100D50 AVH-P4150DVD/XN/RC...

This manual is also suitable for:

Avh-p4150dvd/xn/rdAvh-p4150dvd/xn/riAvh-p4150dvd/xncn5
