C C D D - - P P 1 1 4 4 4 4 0 0 R R
Effective : April, 2002
SERVICE MANUAL
COMPACT DISC PLAYER
CONTENTS
1 SPECIFICATIONS
2 EXPLODED VIEWS AND PARTS LIST
3 PC BOARDS AND PARTS LIST
4 INCLUDED ACCESSORIES
●
PC boards shown are viewed from parts side.
●
The parts with no reference number or no parts number in the
exploded views are not supplied.
●
As regards the resistors and capacitors, refer to the circuit diagrams.
The circuit diagrams are same as CD-P1450.
●
£
Parts marked with this sign are safety critical components. They
must be replaced with identical components - refer to the appropriate
parts list and ensure exact replacement.
For U.S.A.
・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・
・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・
・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・
・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・
NOTES
2
3
7
11
S-0061A
Advertisement
Table of Contents
Related Manuals for Teac CD-P1440R
Summary of Contents for Teac CD-P1440R
- Page 1 SERVICE MANUAL C C D D - - P P 1 1 4 4 4 4 0 0 R R COMPACT DISC PLAYER For U.S.A. CONTENTS 1 SPECIFICATIONS ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ 2 EXPLODED VIEWS AND PARTS LIST ・...
-
Page 2: Specifications
1 SPECIFICATIONS CD PLAYER GENERAL Pickup: Power Requirements: 3-beam, semiconductor laser 120 V AC, 60Hz D/A Converter: Power Consumption: 1 bit DAC 12 Watts (AC) Digital filter: Dimensions (W x H x D): 8-times oversampling 435 x 104 x 305mm Frequency Response: Net Weight: 20 Hz ~ 20 kHz ±1.5dB... -
Page 3: Exploded Views And Parts List
2 EXPLODED VIEWS AND PARTS LIST EXPLODED VIEW-1 51SC2 51SC2 51SC2 51SC2 45-1 5142 5108 5116 5104 51SB3 5140 5118 45-4 −3−... - Page 4 EXPLODED VIEW-1 REF.NO. PARTS NO. DESCRIPTION REMARKS 31‑00 9A09092400 MECHA,CD93F8NDT CEC0991004800 45‑1 9A09157400 MAIN PCB ASSY CEC0B10032300 45‑2 9A09157500 DISPLAY PCB ASSY CEC0B10032400 45‑3 9A09187200 KEY SW PCB ASSY CEC0B10032410 45‑4 9A09187300 PITCH CON PCB ASSY CEC0B10032420 45‑5 9A09187400 H.P. PCB ASSY CEC0B10032900 45‑6 9A09187510 POWER PCB ASSY,120V CEC0B10032500 5101 9A09265000 ESCUTCHEON CEC2141003329 5102 9A07077400 PANEL,TRAY ...
- Page 5 EXPLODED VIEW-2 −5−...
- Page 6 EXPLODED VIEW-2 (CD93F8NDT) REF.NO. PARTS NO. DESCRIPTION REMARKS 1 9A07071300 SWITCH PCB ASSY 1EA0B10A98100 3 9A07072300 CHASSIS,FRAME 1EA2311A06600 4 9A07071400 PLATE,MAGNET 1EA2336A05300 5 9A07071500 LEFT RAIL ASSY 1EA0363A00100 6 9A07071600 RAIL,RIGHT 1EA2363A00300 8 9A07071800 SUPPORT,MAGNET 1EA2413A01700 9 9A08438700 CUSHION,RUBBER CEC2443000100 10 9A08438800 CUSHION,RUBBER CEC2443000101 11 9A07072100 HOLDER,MAGNET ...
-
Page 7: Pc Boards And Parts List
3 PC BOARDS AND PARTS LIST MAIN PCB −7−... - Page 8 DISPLAY PCB KEY SW PCB HP PCB PITCH CON PCB −8−...
- Page 9 POWER PCB −9−...
- Page 10 MAIN PCB ASSY DISPLAY PCB ASSY REF.NO. PARTS NO. DESCRIPTION REF.NO. PARTS NO. DESCRIPTION 9A09157400 MAIN PCB ASSY 9A09157500 DISPLAY PCB ASSY 9A09188400 MAIN PCB 9A09157600 DISPLAY PCB 9A09192100 HEAT SINK,AE338 9A07079700 PAD,FL 9A09192200 HEAT SINK,520‑R CN301 9A09192600 PLUG,11P 9A09192300 SCREW,MACHINE MS/PH 3X8 CN302 9A09192700 PLUG,16P 9A09192400 NUT,3MM HEAT SINK D303‑D308 9A06853400 DIODE,1SS133‑T‑77 C127‑C129 £ 9A07084600 C,ELECT 100UF/50V M FL301 ...
-
Page 11: Included Accessories
POWER PCB ASSY REF.NO. PARTS NO. DESCRIPTION 9A09187510 POWER PCB ASSY,120V 9A09193400 POWER PCB £ 9A08660100 POWER CORD C201 £ 9A07080700 CAPACITOR CN202 9A09195600 HOUSING,2P EC201,202 5760663000 EC TERMINAL,1P SW201 £ 9A07083100 SWITCH,PUSH,POWER T201 £ 9A09195500 TRANSFORMER 4 INCLUDED ACCESSORIES INCLUDED ACCESSORIES REF.NO. PARTS NO. DESCRIPTION REMARKS 9A09092900 OWNER'S MNL,E/S/P CEC6P10069832 9A09264000 REMOTE CONTROL UNIT ...
