- Page 1 CK543000TX BELMAR COCKTAIL TABLE For assistance with assembly, contact. Southern Enterprises Inc. Assembly Instructions Customer Service 1-800-633-5096 service@seidal.com www.seidal.com PO: 13411 Top supports up to...
-
Page 2: Parts List
CK543000TX BELMAR COCKTAIL TABLE Parts List Please review all parts and hardware before disposing of any packaging. Call Customer Service if missing hardware. Carefully study the diagrams below. You may receive extra hardware with your unit. 2PCS 4PCS Stretcher (1) Stretcher (2) 2PCS 4PCS... - Page 3 CK543000TX BELMAR COCKTAIL TABLE Assembly Instructions Step 1 Screw Long Bolts (A) into corresponding holes on the bottom of Stretchers (1) as shown and tighten. Stopper Figure 1 Step 2 Insert attached Long Bolts (A) through the corresponding holes on Stretchers (4).
- Page 4 Step 3: Attach Connector Tubes (5) to each Long Bolt (A) and follow with Stretchers (2). Repeat step to add another level of Stretchers (2). Figure 3 Step 4: Attach Connector Tubes (5) to each Long Bolt (A) and add Stretchers (3).
- Page 5 Step 5: Attach Stretchers (4) to the frame using Bolts (B) as shown. Tighten nuts (C) to fix the frame using Open Wrench (E). Figure 5 Step 6: Turn the assembled frame upright and insert Glass Pads (D) into Stretchers (1) as shown, then place glass top (6).
-
Page 6: Parts Replacement Form
Parts Replacement Form Customer Information Name Address City/State/Zip Code Phone Number Please indicate where you purchased this item: Store/Website/Catalog Please indicate color/size/style number: Style No Parts Letter Parts Description Quantity Needed Please immediately examine this product carefully. Any request for missing parts or damage replacement must be received within 90 days of your receipt of the product.
