Specifications; Indoor Unit - Daikin 3MXM-R Series Engineering Data

EDAR122202

3. Specifications

3.1

Indoor Unit

Wall Mounted Type
Model
Capacity 
Front Panel Colour
H
M
Airflow Rate
L
SL
Type
Fan Motor Output
Speed
Air Direction Control
Air Filter
Running Current (Rated)
Power Consumption (Rated)
Power Factor (Rated)
Temperature Control
Dimensions (H × W × D)
Packaged Dimensions (H × W × D)
Weight (Mass)
Gross Weight (Gross Mass)
Sound
Pressure H / M / L / SL
Level
Sound Power
H
Level
Heat Insulation
Liquid
Piping
Gas
Connections
Drain
Drawing No.
Model
Capacity 
Front Panel Colour
H
M
Airflow Rate
L
SL
Type
Fan Motor Output
Speed
Air Direction Control
Air Filter
Running Current (Rated)
Power Consumption (Rated)
Power Factor (Rated)
Temperature Control
Dimensions (H × W × D)
Packaged Dimensions (H × W × D)
Weight (Mass)
Gross Weight (Gross Mass)
Sound
Pressure H / M / L / SL
Level
Sound Power
H
Level
Heat Insulation
Liquid
Piping
Gas
Connections
Drain
Drawing No.
Notes:
1.  See Page 13 ~ 26 "Combination Capacity".
2. SL: The Quiet fan level of the airflow rate setting.
Multi-Split Type Air Conditioners 3/4/5MXM-R Series
CTXM20RVM2
Cooling
2.0 kW Class
White
9.3 (328)
7.2 (254)
m³/min
(cfm)
5.7 (201)
4.3 (152)
Cross Flow Fan
W 27
Steps 5 Steps, Quiet, Auto
Right, Left, Horizontal, Downwards
Removable, Washable, Mildew Proof
0.20 - 0.19 - 0.19 /
A
0.20 - 0.19
W 18.0
40.9 - 41.2 - 39.5 /
%
40.9 - 41.2
Microcomputer Control
mm 285 × 770 × 223
mm 320 × 830 × 360
kg 9
kg 11
dB(A) 38 / 32 / 25 / 19
dB 52
Both Liquid and Gas Pipes
 6.4
mm
 9.5
mm
mm  16.0
3D138522
CTXM35RVM2
Cooling
3.5 kW Class
White
11.3 (399)
7.9 (279)
m³/min
(cfm)
5.9 (208)
4.3 (152)
Cross Flow Fan
W 27
Steps 5 Steps, Quiet, Auto
Right, Left, Horizontal, Downwards
Removable, Washable, Mildew Proof
0.29 - 0.28 - 0.27 /
A
0.29 - 0.28
W 27.0
42.3 - 41.9 - 41.7 /
%
42.3 - 41.9
Microcomputer Control
mm 285 × 770 × 223
mm 320 × 830 × 360
kg 9
kg 11
dB(A) 42 / 34 / 26 / 19
dB 56
Both Liquid and Gas Pipes
 6.4
mm
 9.5
mm
 16.0
mm
3D138524
50 Hz, 220 - 230 - 240 V / 60 Hz, 220 - 230 V
Heating Cooling
9.6 (339) 10.4 (367)
8.0 (282) 7.2 (254)
5.8 (205) 5.7 (201)
4.2 (148) 4.3 (152)
Right, Left, Horizontal, Downwards
Removable, Washable, Mildew Proof
0.21 - 0.20 - 0.19 / 0.25 - 0.24 - 0.23 /
0.21 - 0.20 0.25 - 0.24
20.0 23.0
43.3 - 43.5 - 43.9 / 41.8 - 41.7 - 41.7 /
43.3 - 43.5 41.8 - 41.7
39 / 34 / 28 / 20 40 / 32 / 25 / 19
53 54
Heating Cooling
11.3 (399) 16.9 (597)
8.5 (300) 14.2 (501)
6.1 (215) 11.7 (413)
4.2 (148) 9.4 (332)
Right, Left, Horizontal, Downwards
Removable, Washable, Mildew Proof
0.29 - 0.28 - 0.27 / 0.35 - 0.34 - 0.33 /
0.29 - 0.28 0.35 - 0.34
27.0 42.0
42.3 - 41.9 - 41.7 / 54.5 - 53.7 - 53.0 /
42.3 - 41.9 54.5 - 53.7
42 / 36 / 29 / 20 45 / 40 / 35 / 28
56 59
Specifications
CTXM25RVM2
Heating
2.5 kW Class
White
10.4 (367)
8.0 (282)
5.8 (205)
4.2 (148)
Cross Flow Fan
27
5 Steps, Quiet, Auto
0.25 - 0.24 - 0.23 /
0.25 - 0.24
23.0
41.8 - 41.7 - 41.7 /
41.8 - 41.7
Microcomputer Control
285 × 770 × 223
320 × 830 × 360
9
11
40 / 34 / 28 / 20
54
Both Liquid and Gas Pipes
 6.4
 9.5
 16.0
3D138523
CTXM50RVM2
Heating
5.0 kW Class
White
17.2 (607)
14.3 (505)
11.4 (403)
9.2 (325)
Cross Flow Fan
58
5 Steps, Quiet, Auto
0.37 - 0.36 - 0.35 /
0.37 - 0.36
44.0
54.1 - 53.1 - 52.4 /
54.1 - 53.1
Microcomputer Control
295 × 990 × 263
386 × 1,102 × 389
13
16
45 / 39 / 33 / 28
59
Both Liquid and Gas Pipes
 6.4
 12.7
 16.0
3D138525
Conversion Formulae
kcal/h = kW × 860
Btu/h = kW × 3412
cfm = m³/min × 35.3
