Programming
Testing the Unit
If you have programmed the Axcess software, load the program into a PC connected to the control
system Master port. See Programming on page 4.
1. Push switches connected to the AXP-CPI16.
2. Look at the lower left of the Axcess screen to verify that the correct device and channel numbers are
displayed.
3. Check for the appropriate feedback (as provided by the Master Controller program).
10
AXP-CPI16 16-Channel Custom Panel Interface
