- Page 1 Lively 300V/ 500V/ 3AP Power Supply Instruction manual Catalog No. MP-310 MP-320 MP-510 www.majorsci.com service@majorsci.com Version 06A Revised on: 2019/03/29...
-
Page 2: Packing List
1x Instruction Manual Signed by: Date: Major Science is liable for all missing or damaged parts / accessories within 7 days after customer received this instrument package. Please contact Major Science immediately regarding this issue. If no response within such time period from consignee party, that will be consignee... -
Page 3: Table Of Contents
Table of Contents PACKING LIST ....................2 WARNING ......................4 ................8 ECTION NTRODUCTION ......................... 8 VERVIEW ................... 9 & F RODUCT ESCRIPTION EATURE ............10 ECTION ECHNICAL PECIFICATION ............11 ECTION NSTALLATION NSTRUCTIONS ............11 ECTION PERATION NSTRUCTIONS ...................... 11 ONTROL INTERFACE ....................... -
Page 4: Warning
Warning Major Science Lively Power Supply has been tested and found to comply with the limits for the CE regulation. Also, it is RoHS compliant to deliver confident product which meets the environmental directive. These limits are designed to provide reasonable protection against harmful interference when the instrument series is operated in a commercial environment. - Page 5 Follow the guidelines below to ensure safe operation of the unit. The Lively Power Supply has been designed to utilize shielded wires thus minimizing any potential shock hazard to the user. Major Science recommends against the use of unshielded wires.
- Page 6 Avoiding Damage to the Instrument 1. Do not attempt to operate the device if damage is suspected. 2. Protect this unit from physical damage, corrosive agents and extreme temperatures (direct sunlight, etc.). 3. For proper ventilation and safety concerns, keep at least 10 cm of space behind the instrument, and at least 5 cm of space on each side.
- Page 7 Caution/ Warning: Indicates a hazardous situation which, if not avoided, could result in death or serious injury. MP-310 Max. voltage: 300 V Max. current: 700 mA Max. watt: 150 W MP-320 Max. voltage: 300 V Max. current: 3000 mA Max. watt: 300 W MP-510 Max.
-
Page 8: Section 1 Introduction
Introduction Section 1 2.1 Overview Major Science Lively Power Supplies are recognized as unique power supplies equipped with very powerful specifications to cover the majority of electrophoresis applications on the market. Sufficient and accurate output voltages, four terminal pairs, and its compacted size can deliver accurate and reliable experimental results from one experiment to another. -
Page 9: Product Description & Feature
Furthermore, the powerful specifications plus four terminal pairs can be used for multi electrophoresis units simultaneously. Major Science Lively Power Supply provides Constant Voltage or Constant Current or Constant Power to instruments used in electrophoresis. 4 terminal pairs and the powerful specification equipped enable the maximum capability of Lively Power Supply compared to other existing similar product on the market. -
Page 10: Section 2 Technical Specification
Technical Specification Section 2 MP-310 MP-320 MP-510 Output Voltage / 5 - 300V / 1V 5 – 300 / 1V 5 – 500 / 1V Output Current / 1 - 700mA / 1mA 10 – 3,000mA / 1 – 800mA / 1mA 10mA Max. -
Page 11: Section 3 Installation Instructions
Regulatory CE, ETL Operating 4℃~ 40℃ Temperature Construction Flame retardant ABS faceplate Material Unit Dimension 215 x 335 x 104 mm (W x L x H) Weight approx. 2.1 kg Installation Instructions Section 3 Lively Power Supply is actually a pre-installed instrument. As long as it is placed on a sturdy and level surface in a safe, dry place, and further connects with well-prepared electrophoresis system, it is ready for operation. -
Page 12: Getting Start
Press to temporarily interrupt power to an operation in progress; resume power after pausing without resetting the timer Press to go back previous page 1. Press to enter the next page 2. Press to enable numeric value set up Press to move cursor left forward between parameters Press to move cursor right forward between parameters... -
Page 13: General Operating Instructions
3. Connect the DC output jacks from the electrophoresis unit; insert the red lead (+) into the red output jack, and the black lead (-) into the blue output jack. 4. Power on the unit by pressing the ON/OFF switch on the back. 5. -
Page 14: Constant Mode
4.4 Constant Mode Use the Constant Mode for applications that require only one specific limit: voltage/ current/ power during the entire operation of electrophoresis. a. Setting Key and Key to select Constant Mode, and then press to enter the next page. ... - Page 15 b. Start an Run Press Key to start operation. The LED is lit, and the screen will show present real-time parameter values. When parameter reaches the set value, its color would turn orange. Press to switch pages between real-time value display and value set up page.
- Page 16 c. Pause/ Terminate a Run Press Key to temporarily pause the on-going electrophoresis without terminating the timer. The LED is flashing. Press Key to resume the run. Press the Key again to stop electrophoresis and to terminate a timed run.
-
Page 17: Program Mode
4.5 Program Mode Instructions for operating Lively Power Supply in the programming operation are provided in this section. The Program Mode allows you to vary levels in voltage (V), current (mA), and power (W) during specified time periods for up to 6 Steps, depending upon your electrophoresis needs. - Page 18 b. Start a Run Press Key to start electrophoresis. The LED is lit, and the screen will show present real-time parameter values. When parameters reach the set value, the color would turn orange. Press to switch pages between real-time value display and value set up page.
- Page 19 c. Pause/ Terminate a Run Press Key to temporarily interrupt power to ongoing electrophoresis without terminating the operation. The LED is flashing. Press Key to resume the run. Press the Key again to stop electrophoresis and to terminate a timed run.
-
Page 20: Typical Running Condition
4.6 Typical Running Condition Besides Constant Mode and Program Mode, Lively Power Supply provides a third option, Typical Running Condition. It is helpful for those beginners who are not familiar with the parameter setting and is convenient for quick start. ... -
Page 21: Section 5 Trouble Shooting And Maintenance
Use the correct cords. The fuse has blown Replace the fuse. Contact Major Science service Repeated fuse broken Hardware failure department Operation stops and It is recommended to send the Communication wires on... - Page 22 High voltage application DISABLE No Load alarm on the is set to run on a very low Display Screen current Operation stops with Bad connections for Check all the connections to alarm. Display shows terminal connectors or terminators, cables, wires, and gel damaged wires or tanks damaged platinum wires...
-
Page 23: Encountering Problems
2. Call Technical Service or e-mail to service@majorsci.com 3. If the unit must be shipped back for repair, contact Major Science or the distributor for a Return Material Authorization number and shipping instructions. The unit will be repaired and returned to you as quickly as... -
Page 24: Replacing The Fuse
(see figure below). 4. Place the fuse holder back into the compartment. 5. Snap the cover closed. Double Fuse Holder Fuse in Use For additional fuses, contact Major Science co. ltd. Model Type of Fuse Ordering Number MP-310 2.5A/250V... -
Page 25: Section 6 Ordering Information
Ordering Information Section 6 Cat. No. Description MP-310 Lively 300V Power Supply MP-320 Lively 3AP Power Supply MP-510 Lively 500V Power Supply... -
Page 26: Section 7 Warranty
All claims made under this warranty must be presented to Major Science within one year following the date of delivery of the product to the customer.
