Service and Maintenance Instructions
NOTE: Read the entire instruction manual before starting the
installation.
This symbol → indicates a change since the last issue.
TABLE OF CONTENTS
SAFETY CONSIDERATIONS .....................................................1
INTRODUCTION ..........................................................................2
CEDURE ........................................................................................2
CARE AND MAINTENANCE.....................................................2
Cleaning And/Or Replacing Air Filter.....................................2
Blower Motor and Wheel.........................................................4
Cleaning Heat Exchanger .........................................................5
Electrical Controls and Wiring.................................................6
WIRING DIAGRAMS.................................................................10
TROUBLESHOOTING ...............................................................10
REGISTERED QUALITY SYSTEM
Fig. 1-Model 58TMA Horizontal
SAFETY CONSIDERATIONS
Installing and servicing heating equipment can be hazardous due to
gas and electrical components. Only trained and qualified person-
nel should install, repair, or service heating equipment.
Untrained personnel can perform basic maintenance functions
such as cleaning and replacing air filters. All other operations must
Manufacturer reserves the right to discontinue, or change at any time, specifications or designs without notice and without incurring obligations.
Book 1 4
PC 101
Catalog No. 535-796
Tab 6a 8a
For Sizes 040-135, Series 120 or 130
EFFICIENCY
RATING
CERTIFIED
CERTIFIED
®
A94087
Printed in U.S.A.
Deluxe 2-Speed Gas-Fired
Induced-Combustion Gas Furnaces
Fig. 2-Model 58TMA Downflow
Fig. 3-Model 58TUA Upflow
be performed by trained service personnel. When working on
heating equipment, observe precautions in the literature, tags, and
labels attached to or shipped with the unit and other safety
precautions that may apply.
Follow all safety codes. In the United States, follow all safety
codes including the National Fuel Gas Code (NFGC) NFPA No.
Form 58T-6SM
58TMA, 58TUA
Pg 1
10-00
Replaces: 58T-5SM
A94086
A94085
