Burcam 300508P Installation Instructions Manual

Sump pumps

Advertisement

Quick Links

www.burcam.com
2190 Dagenais Blvd. West
LAVAL (QUEBEC)
CANADA
H7L 5X9
Your pump has been carefully packaged at the
factory to prevent damage during shipping.
However, occasional damage may occur due to
rough handling. Carefully inspect your pump
for damages that could cause failures. Report any
damage to your carrier or your point of purchase.
© 2014 BURCAM Printed in Canada 310726
TEL. : 514-337-4415
FAX : 514-337-4029
info@burcam.com
300508P
300500
300600P
300700P
INSTALLATION
INSTRUCTIONS
VERSION H
300508P 300601
300500 300600P 300610
300700P 300710
SUMP PUMPS
300601
300610
300710
MODELS
Please read these
instructions
carefully. Failure
to comply to
instructions
and designed
operation of
this system,
may void
the warranty.

Advertisement

loading
Need help?

Need help?

Do you have a question about the 300508P and is the answer not in the manual?

Questions and answers

Summary of Contents for Burcam 300508P

  • Page 1 Report any operation of damage to your carrier or your point of purchase. this system, may void the warranty. 300508P 300500 300601 300600P 300610 300700P 300710 © 2014 BURCAM Printed in Canada 310726...
  • Page 2: Safety Instructions

    SAFETY INSTRUCTIONS: This fine pump that you have just purchased is designed from the latest in material and workmanship. Before installation and operation, we recommend the following procedures: CHECK WITH YOUR LOCAL ELECTRICAL AND PLUMBING CODES TO ENSURE YOU COMPLY WITH THE REGULATIONS. THESE CODES HAVE BEEN DESIGNED WITH YOUR SAFETY IN MIND.
  • Page 3 • Burcam alarm system model 450454 has to be installed to advise you of any malfunctions. • As sump pumps are electrically powered and activated so to prevent flooding, a Burcam battery powered back up pump model 300403 has to be installed to evacuate the water.
  • Page 4: Maintenance

    SUMP PUMP APPLICATION (SEE DIAGRAM ON PAGE 5) At this step, you have the opportunity to install a 1 1/2” or a 1 1/4” discharge. We recommend STEP 3 a 1 1/2” ABS/DWV discharge. Install a check valve (350362 in-line 1 1/2” or 350353 1 1/4” MNPT inlet and 1 1/4”...
  • Page 5: Repair Parts

    350132 Switch bracket 310438 Rotor (1/4HP) 450453 Mechanical switch ; 350340 Lower bearing (300508P, 300600P, 300700P) 310435 Oil seal 310692 Mechanical switch ; (300500) (not shown) Repair parts may be ordered from your authorized point of sale or from BUR-CAM PUMPS...
  • Page 6 TROUBLE SHOOTING GUIDE CHECKLIST NEVER MAKE ADJUSTMENTS TO ANY ELECTRICAL APPLIANCE OR PRODUCT WITH THE POWER CONNECTED. DON’T JUST UNSCREW THE FUSE OR TRIP THE BREAKER, REMOVE THE POWER FROM THE RECEPTACLE. TROUBLE PROBABLE CAUSE ACTION Motor Switch is off position Turn switch to on position Blown fuse Replace...
