Delta FORCE-GT DRF-240W Series Technical Data Sheet

TECHNICAL DATASHEET
Force-GT DIN Rail Power Supply
DRF-240W series / DRF-V240W1GA
General Description
The Force-GT Series DIN rail industrial power supply features high power density and high efficiency. The Series offers overcurrent
protection in constant current mode, making it suitable for charging applications. Conformal coating is applied on the PCBAs to protect
against dust and pollutants often found in harsh industrial environments. The Series' electromagnetic radiated and conducted emissions
are compliant with heavy industrial Class B Emission standard and Immunity standard, and complies with environmental protection
standards RoHS Directive.
Model Information
Force-GT DIN Rail Power Supply
Model Number
DRF-12V240W1GA
DRF-24V240W1GA
DRF-48V240W1GA
Model Numbering
DR F –
DIN Rail Product Series
F – Force
All parameters are specified at 25°C ambient and AC input unless otherwise indicated.
1
www.DeltaPSU.com (June 2022, Rev. 01)
Input Voltage Range
90-264 Vac
240W
V
Output Voltage Output
Power
12 – 12 V
24 – 24 V
48 – 48 V
Highlights & Features
Universal AC input voltage range
•
• Built-in constant current circuit for charging applications
Full load operating temperature up to 60°C
•
• Cold start at -40°C
Ultra-Slim design
•
• Long life electrolytic capacitor
Built-in DC OK relay and LED indicator
•
• Conformal coating on PCBAs to protect against common dust
and pollutants
Safety Standards
CB Certified for worldwide use
Model Number:
Unit Weight:
Dimensions (H x W x D):
Rated Output Voltage
12 Vdc
24 Vdc
48 Vdc
1 G
Single G – General Type B – Screw terminal
Phase
DRF-V240W1GA
0.64 kg (1.41 lb)
123.6 x 40 x 116.8 mm
(4.87 x 1.57 x 4.60 inch)
Rated Output Current
20.0 A
10.0 A
5.0 A

A
Delta Standard
