- Page 1 Model DYN-C-1000-SI Range [g]: 3, 5 Product Manual...
- Page 2 Our products are warranted against defective materials and workmanship for one year. Defects arising from user errors are not covered by the warranty. Copyright All copyrights of this manual belonging to Dynalabs products are reserved. It cannot be reproduced without written consent. Disclaimer Dynalabs Ltd.
-
Page 3: Table Of Contents
All rights reserved. Reproduction or issue to third parties in any form whatsoever is not permitted without written authority from the proprietors. Table of Contents 1) Introduction ....................... 4 2) General Information ..................4 2.1) Unpacking and Inspection ................4 2.2) System Components ................... -
Page 4: Introduction
These sensors have a reliable aluminum housing with IP68 protection class. Dynalabs 1000SI series uniaxial accelerometers provide an ultra-low noise performance from 0.7 to 1.2 μg/√Hz. These accelerometers provide excellent bias and scale factor stability and a wide frequency range (±3dB) from 550 Hz to 700 DYN-C-1000-SI sensors offer the following options;... -
Page 5: Specifications
All rights reserved. Reproduction or issue to third parties in any form whatsoever is not permitted without written authority from the proprietors. 2.3) Specifications Table 1: Specifications datasheet 1003SI 1005SI Full-scale acceleration ± 3 ± 5 (μg/√Hz) White Noise Noise (Integrated over 0.1Hz to 100Hz) (μg) Dynamic range (0.1Hz to 100Hz) (dB) -
Page 6: Outline Drawing
All rights reserved. Reproduction or issue to third parties in any form whatsoever is not permitted without written authority from the proprietors. Physical Table 3 Physical specifications datasheet Sensing Element MEMS Capacitive Housing Material Aluminum or Steel Connector (Optional) D-Sub 9 or 15 pin, Lemo, Binder Mounting Adhesive or screw mount Base plate (Optional) -
Page 7: Operation And Installation
Using gravity, voltage values are measured in the + and – gravity directions, providing a value of ±1 g. The measurement should be made as follows; When the sensitivity value of 1000SI series sensors is used with the data acquisition system, the sensor shows +1 g with the effect of gravity in the direction of the arrow sign. -
Page 8: Declaration Of Conformity
• EN ISO 12100:2010 • MIL-STD-810-H-2019 (Test Methods: 501.7- High Temperature, 502.7- Low Temperature, 514.8- Vibration, 516.8 – Shock) DYNALABS MÜHENDİSLİK SANAYİ TİCARET LİMİTED ŞİRKETİ declares that above mentioned products meet all the requirements of the above mentioned standards and regulations.
