Dynalabs DYN-30 Series Product Manual

Can interface
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Model DYN-30XXXX-XX
Range [g]: 2, 4, 8, 10, 20, 40
CAN
Interface
Product Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DYN-30 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Dynalabs DYN-30 Series

Summary of Contents for Dynalabs DYN-30 Series

  • Page 1 Model DYN-30XXXX-XX Range [g]: 2, 4, 8, 10, 20, 40 Interface Product Manual...
  • Page 2 Our products are warranted against defective materials and workmanship for one year. Defects arising from user errors are not covered by the warranty. Copyright All copyrights of this manual belonging to Dynalabs products are reserved. It cannot be reproduced without written consent. Disclaimer Dynalabs Ltd.

  • Page 3: Table Of Contents

    All rights reserved. Reproduction or issue to third parties in any form whatsoever is not permitted without written authority from the proprietors. Table Of Contents 1. Introduction ..................... 4 Hardware General Information ............... 5 Unpacking and Inspection ............... 5 System Components ................5 Specifications ..................

  • Page 4: Introduction

    All rights reserved. Reproduction or issue to third parties in any form whatsoever is not permitted without written authority from the proprietors. 1. Introduction Capacitive accelerometers are based on proven micro-electro-mechanical systems (MEMS) technology. These capacitive accelerometers are reliable, long-term stable, and precise.

  • Page 5: Hardware General Information

    All rights reserved. Reproduction or issue to third parties in any form whatsoever is not permitted without written authority from the proprietors. Hardware General Information Unpacking and Inspection Dynalabs products provide adequate protection for undamaged products to be transported. Document the damage that occurred indirectly during transportation and contact the customer representative.

  • Page 6: Outline Drawing

    All rights reserved. Reproduction or issue to third parties in any form whatsoever is not permitted without written authority from the proprietors. Pin 1 Shielding Pin 2 5 - 16V Pin 3 Black Connector at Sensor (open ended) Pin 4 Yellow CAN-High Pin 5 Green...

  • Page 7: Operation And Installation

    All rights reserved. Reproduction or issue to third parties in any form whatsoever is not permitted without written authority from the proprietors. Operation and Installation General After connecting power to the sensor, it will be in initial setting mode and will start sending data via CAN bus.

  • Page 8: Choose A Dbc Creation Tool

    All rights reserved. Reproduction or issue to third parties in any form whatsoever is not permitted without written authority from the proprietors. 4.2.1.1 Choose a DBC Creation Tool There are several tools available for creating and editing DBC files. Some popular ones include: •...
  • Page 9 All rights reserved. Reproduction or issue to third parties in any form whatsoever is not permitted without written authority from the proprietors. NOTICE: The model that uses a 4000 Hz sampling rate does not incorporate temperature data. CAN Signals (Configuration 2) Name Signal Type Order...
  • Page 10 All rights reserved. Reproduction or issue to third parties in any form whatsoever is not permitted without written authority from the proprietors.

  • Page 11: Create Dbc File

    All rights reserved. Reproduction or issue to third parties in any form whatsoever is not permitted without written authority from the proprietors. 4.2.1.3 Create DBC file The resulting output will resemble the following when creating the CAN message and setting individual signals. You can create a DBC file to avoid making these settings again.

  • Page 12: Import Dbc File

    0.02 G. This number may change with the time and with usage. In any case, the device requires calibration, which can be performed by calibration companies or DynaLabs itself so that the measurement can be done with very high accuracy.
  • Page 13 All rights reserved. Reproduction or issue to third parties in any form whatsoever is not permitted without written authority from the proprietors. With these numbers, you can enter the special numbers for each signal in the Calibration window. If you want to find a and by yourself, by comparing the data of the device and a calibrated device, part FindEquation will help you calculate them.

  • Page 14: Declaration Of Conformity

    • MIL-STD-810-H-2019 (Test Methods: 501.7 - High Temperature, 502.7 - Low Temperature, 514.8 - Vibration, 516.8 – Shock) DYNALABS MÜHENDİSLİK SANAYİ TİCARET LİMİTED ŞİRKETİ declares that above mentioned products meet all the requirements of the above mentioned standards and regulations.
