Summary of Contents for Dynalabs DYN-C-3000-LN
- Page 1 Model DYN-C-3000-LN Range [g]: 2, 5, 10, 30, 50, 100, 200 Product Manual...
- Page 2 All rights reserved. Reproduction or issue to third parties in any form whatsoever is not permitted without written authority from the proprietors. Product Support If at any time you have questions or problems with the DYN-C-3000-LN sensors, please contact a Dynalabs engineer at: Phone: +90 312 386 21 89 (9 a.m.
-
Page 3: Table Of Contents
All rights reserved. Reproduction or issue to third parties in any form whatsoever is not permitted without written authority from the proprietors. Table of Contents 1) Introduction ..................... 4 2) General Information ..................4 2.1) Unpacking and Inspection ................4 2.2) System Components ................... -
Page 4: Introduction
These sensors feature standard reliable aluminum housing with protection class IP68. Steel housing is also possible. Dynalabs 3000LN series triaxial accelerometers provide Low noise – high resolution with an outstanding noise performance from 9 to 680 μg/√Hz. These accelerometers provide a wide frequency range (±5%) from 700 Hz to 2,500 Hz... -
Page 5: Specifications
All rights reserved. Reproduction or issue to third parties in any form whatsoever is not permitted without written authority from the proprietors. 2.3) Specifications Table 1: Specifications datasheet 3002LN 3005LN 3010LN 3030LN 3050LN 3100LN 3200LN Full scale ±2 ±5 ±10 ±30 ±50 ±100... -
Page 6: Outline Drawing
Connector (Optional) D-Sub 9 or 15 pin, Lemo, Binder Mounting Adhesive or screw mount Base plate (Optional) Aluminum or Steel 21g (aluminum) Weight (without cable) 45 g (steel) 2.4) Outline Drawing The dimensional properties of DYN-C-3000-LN sensors are given below;... -
Page 7: Operation And Installation
All rights reserved. Reproduction or issue to third parties in any form whatsoever is not permitted without written authority from the proprietors. 3) Operation and Installation 3.1) General The general sensor connector configuration is given below; Cable Code/Pin Configuration: • Red : V + Power supply voltage +6 to +40 VDC •... -
Page 8: Declaration Of Conformity
• MIL-STD-810-H-2019 (Test Methods: 501.7 - High Temperature, 502.7 - Low Temperature, 514.8 - Vibration, 516.8 – Shock) DYNALABS MÜHENDİSLİK SANAYİ TİCARET LİMİTED ŞİRKETİ declares that above mentioned products meet all the requirements of the above mentioned standards and regulations.
