- Page 1 Model DYN-C-3000-DE Range [g]: 2, 4, 8, 10, 20, 40, 50, 100, 200, 500 Product Manual...
- Page 2 All rights reserved. Reproduction or issue to third parties in any form whatsoever is not permitted without written authority from the proprietors. Product Support If at any time you have questions or problems with the DYN-C-3000-DE sensors, please contact a Dynalabs engineer at: Phone: +90 312 386 21 89 (9 a.m.
-
Page 3: Table Of Contents
All rights reserved. Reproduction or issue to third parties in any form whatsoever is not permitted without written authority from the proprietors. Table of Contents 1) Introduction ....................... 4 2) General Information ..................4 2.1) Unpacking and Inspection ................4 2.2) System Components ................... -
Page 4: Introduction
• Custom Connector • Base plate (Optional) 2) General Information 2.1) Unpacking and Inspection Dynalabs products provide adequate protection for undamaged products to be transported. Document the damages that occur indirectly during the transport and contact the customer representative. 2.2) System Components... -
Page 5: Specifications
All rights reserved. Reproduction or issue to third parties in any form whatsoever is not permitted without written authority from the proprietors. 2.3) Specifications Table 1: Specifications datasheet 3002DE 3004DE 3008DE 3010DE 3020DE 3040DE 3050DE 3100DE 3200DE 3500DE Full scale ±2 ±4 ±8... -
Page 6: Outline Drawing
Connector (Optional) D-Sub 9 or 15 pin, Lemo, Binder Mounting Adhesive or screw mount Base plate (Optional) Aluminum or Steel 19g (aluminum) Weight (without cable) 44 g (steel) 2.4) Outline Drawing The dimensional properties of DYN-C-3000-DE sensors are given below. -
Page 7: Operation And Installation
All rights reserved. Reproduction or issue to third parties in any form whatsoever is not permitted without written authority from the proprietors. 3) Operation and Installation 3.1) General The general sensor connector configuration is given below; Cable Code/Pin Configuration: • Red : V + Power supply voltage +6 to +40 VDC •... -
Page 8: Declaration Of Conformity
• MIL-STD-810-H-2019 (Test Methods: 501.7 - High Temperature, 502.7 - Low Temperature, 514.8 - Vibration, 516.8 – Shock) DYNALABS MÜHENDİSLİK SANAYİ TİCARET LİMİTED ŞİRKETİ declares that above mentioned products meet all the requirements of the above mentioned standards and regulations.
