Tools needed: 7mm socket, 10mm
socket, pliers, electrical tape, wire
splicer, phillips screwdriver.
Step 2: Remove the parking
lights from the vehicle.
Step 5: Two 7mm screws are
located at the top corners of
the grill.
Description: Head lights
Application: 1988-1998 Chevy Fullsize Truck
Step 3: Twist off the parking
light bulb sockets.
Step 6: The next two 7mm
screws are located right
above the mesh grill.
Read complete instructions
before installation!
Improper installation may
void warranty
Step 1: Remove the four
phillips screw to remove the
parking lights.
Step 4: Remove the four
7mm screws holding in the
grill.
Step 7: Pull the tabs up to
release the grill from the
frame.
Advertisement
Related Manuals for AmeriLite 02-AZ-CF88-C-G2
Summary of Contents for AmeriLite 02-AZ-CF88-C-G2
- Page 1 Read complete instructions before installation! Improper installation may void warranty Description: Head lights Application: 1988-1998 Chevy Fullsize Truck Tools needed: 7mm socket, 10mm Step 1: Remove the four socket, pliers, electrical tape, wire phillips screw to remove the splicer, phillips screwdriver. parking lights.
- Page 2 Step 10: Remove the four Step 8: Pull the grill away Step 9: Twist off the corner 10mm screws holding in the from the vehicle. light socket from the grill. headlight assembly. Step 13: Plug in the wire Step 11: Pull the headlight Step 12: Unplug the wire harness socket for the new away from the vehicle.
