AmeriLite 03-CL03TLEDJMSM-C Instructions

Tools Needed:
Phillips Screw Driver
Step 3: Remove the taillight
by pulling straight out.
Step 6: Place the resistor in
a safe location in the housing.
Step 8: Connect the resistor
to the taillight housing.
Description: LED Taillight
Application: 03-06 Chevy Silverado
Step 1: Lower the tail gate
exposing the two screws.
Step 4: Remove all 4 sockets
from the taillight housing.
Step 7: Connect the pigtails
to the stock sockets.
Step 9: Place the LED taillight
into the truck housing, secure
with screws.
Read complete instructions
before installation!
Improper installation may
void warranty
Step 2; Remove the upper
and lower screws
Step 5: Remove the bulbs
from the two black sockets.
Make sure the wires match:
Black to Black
Make sure all functions are
working properly before
driving.
