AmeriLite 03-CL07TLRC Manual

Tools needed: Phillips
screwdriver
Step 3: Use the phillips
screwdriver to remove the two
screws holding in the tail light.
Step 8: Test all functions
making sure all functions work
before driving.
Description: Tail Lights
Application: 2007.5-2009 Chevy Silverado
Step 2: unclip the wire from the
plastic clips.
Step 4: Remove the tail light.
Read complete instructions
before installation!
Improper installation may
void warranty
Step 1: Under the vehicle bed
unplug the wire harness for the
tail light.
Step 5: Pull the wire out from
under the bed and plug in
harness into circuit board.
