AmeriLite 02-AZ-CTS07-PBC-P-G2-A Manual

Application: 2007-2008 Chevy Tahoe/Suburban/Avalanche
Tools needed: 10mm socket,
7mm socket, trim pin remover,
electrical tape, wire splicer.
Step 3: Pull back the wheel well
cover to expose the 10mm bolt
holding in the bottom bumper.
Step 6: Remove the two 10mm
bolts located on the top
headlight.
Description: Head lights
Step 1: Remove the six 10mm
screws located on the top grill.
Step 4: With the wheel well
cover pulled back remove the
two 10mm bolts holding the
Step 7: Remove the third 10mm
bolt located on the bottom
corner of the head light.
Read complete instructions
before installation!
Improper installation may
void warranty
Step 2: Remove the two top pins
with the trim pin remover and
then remove the 7mm screw.
Step 5: Remove the front
bumper from the vehicle.
Step 8: Remove the head light
from the vehicle.
