- Page 1 TEL：1-866-XANATOS INSTALLATION INSTRUCTIONS MODULAR RUGGED GRILLE GUARD 2019-2021 GMC SIERRA 1500 PART# RU-GMSI19-B...
-
Page 2: Parts List
MODULAR RUGGED GRILLE GUARD 2019-2021 GMC SIERRA 1500 PARTS LIST: Main Body 12mm Lock Washers Passenger/Right Brush Guard 12mm Hex Nuts Driver/Left Brush Guard 12mm Plastic Retainers LED lamp Bracket 10-1.5mm x 30mm Hex Bolts Driver/Left Frame Bracket 10mm x 24mm OD x 2.2mm Flat Washers Passenger/Right Frame Bracket 10mm Nylon Lock Nuts Driver/Left Z-Bracket... - Page 3 MODULAR RUGGED GRILLE GUARD 2019-2021 GMC SIERRA 1500 Please Noted： 1. Before you install the Grille Guard on the vehicle, please install the Driver/Left Brush Guard and Passenger/Right Brush Guard on the main body first. 2. Before you install the LED Lamp on the main body please install the LED Lamp Bracket first. 3.
- Page 4 MODULAR RUGGED GRILLE GUARD 2019-2021 GMC SIERRA 1500 a. Select (1) 12mm Bolt Plate. Insert the Bolt Plate into the end of the frame, (Figure 4). Thread (1) 12mm Plastic Retainers onto the Bolt Plate to hole it in place, (Figure 5). b.
- Page 5 MODULAR RUGGED GRILLE GUARD 2019-2021 GMC SIERRA 1500 Driver/Left Side Installation Pictured (Fig 1) Passenger/Right tow hook pictured Front Area to cut out illustrated for example only (Fig 2) Remove the tow hook and the plastic cover Front (Fig 3) Example of model without tow hooks, passenger/right side pictured (Fig 4) Driver/Left side of frame and bumper pictured from behind bumper...
- Page 6 MODULAR RUGGED GRILLE GUARD 2019-2021 GMC SIERRA 1500 Driver/Left Side Installation Pictured 12mm Bolt Plate 12mm Plastic Retainer 8mm Hex Bolt (2) 8mm Flat Washers 8mm Lock Washer 8mm Hex Nut (Fig 5) Attach (1) 12mm Bolt Plate to the outer side of the frame 12mm Bolt Plate 12mm Plastic Retainer 12mmx 24mm Flat Washer...
- Page 7 MODULAR RUGGED GRILLE GUARD 2019-2021 GMC SIERRA 1500 Driver/Left Side Installation Pictured (2) 12mm Hex Bolts (4) 12mm x 32mm Flat Washers (2) 12mm Lock Washers (2) 12mm Hex Nuts Front (Fig 9) Attach the bottom of the Z-Bracket to the Frame Bracket (Fig 10) For models with tow hooks, reuse the factory hardware to attach the tow hook and Z-Bracket...
- Page 8 MODULAR RUGGED GRILLE GUARD 2019-2021 GMC SIERRA 1500 Driver/Left Side Installation Pictured Front (Fig 13) Apply Foam Tape to underside of Driver/left Support Bracket. Reuse Front the factory bolt to attach the Bracket to the top of the bumper 10mm Hex Bolt (2) 10mm Flat Washers 10mm Nylon Lock Nut (2) 12mm Hex Bolts...
