PART# RU-TOTU07-B-INS
INSTALLATION INSTRUCTIONS
07-21 TOYOTA TUNDRA
(Excl. 18-21 TSS-P: Pre-collision system & Dynamic radar cruise control)
08-21 TOYOTA SEQUOIA
(Excl. 08-21 Platinum)
PART# RU-TOTU07-B
1-866-926-2867 | 39 St. Mary's Place, Freeport, NY 11520 | www.blackhorseoffroad.com
Advertisement
Related Manuals for Black Horse Off Road RU-TOTU07-B-INS
Summary of Contents for Black Horse Off Road RU-TOTU07-B-INS
- Page 1 PART# RU-TOTU07-B-INS INSTALLATION INSTRUCTIONS 07-21 TOYOTA TUNDRA (Excl. 18-21 TSS-P: Pre-collision system & Dynamic radar cruise control) 08-21 TOYOTA SEQUOIA (Excl. 08-21 Platinum) PART# RU-TOTU07-B 1-866-926-2867 | 39 St. Mary’s Place, Freeport, NY 11520 | www.blackhorseoffroad.com...
-
Page 2: Parts List
MODULAR RUGGED GRILLE GUARD 07-21 TOYOTA TUNDRA (EXCL. 18-21 TSS-P: PRE-COLLISION SYSTEM & DYNAMIC RADAR CRUISE CONTROL) PARTS LIST 08-21 SEQUOIA (EXCL. 08-21 PLATINUM) PARTS LIST: 10mm Cam Lever Quick Release Bolts with Main Body Special Pivot Washer Driver/Left Brush Guard 8mm x 24mm x 2mm Flat Washers Passenger/Right Brush Guard 8-1.25mm x 25mm Button Head Bolts... - Page 3 REMOVE CONTENTS FROM BOX. VERIFY ALL PARTS ARE PRESENT. READ INSTRUCTIONS CAREFULLY BEFORE STARTING INSTALLATION. Please Note： ： 1. Grill Guard may interfere with front mounted sensors, not recommended for vehicles with optional "active" laser guided cruise control systems. Some cutting may be required. 3.
-
Page 4: Installation
MODULAR RUGGED GRILLE GUARD 07-21 TOYOTA TUNDRA (EXCL. 18-21 TSS-P: PRE-COLLISION SYSTEM & DYNAMIC RADAR CRUISE CONTROL) 08-21 SEQUOIA (EXCL. 08-21 PLATINUM) INSTALLATION Installation Introduction The grill guard is mounted to the vehicle by two Upper Mounting Brackets and two Lower Frame Mounting Brackets. The 2 Upper Mounting Brackets each need an additional Adapter Plate to attach them to the frame, while the lower brackets bolt directly into the tow hook mounting points. - Page 5 Upper Mounting Brackets Installation UPPER MOUNTING BRACKET INSTALLATION Passenger side Upper Passenger Side Upper Mounting Mounting Bracket Bracket Adapter Plate Passenger Side Upper Mounting Bracket with Upper Mounting Bracket Adapter Plate First install the Upper Mounting Bracket Adapter Plates 07-13 Tundra, 08-14 Sequoia models: 2014-on Tundra models: Upper Mounting Bracket Adapter Plates must Upper Mounting Bracket Adapter Plates must be...
- Page 6 MODULAR RUGGED GRILLE GUARD 07-21 TOYOTA TUNDRA UPPER MOUNTING BRACKET INSTALLATION (EXCL. 18-21 TSS-P: PRE-COLLISION SYSTEM & DYNAMIC RADAR CRUISE CONTROL) 08-21 SEQUOIA (EXCL. 08-21 PLATINUM) If necessary, temporarily remove bumper Some models have an air deflector mounted cover hardware to access bumper bracket. on the driver’s side, it may be necessary to (passenger/right side pictured from below) remove the bumper cover to trim or remove...
- Page 7 GRILLE GUARD MOUNTING Grille Guard Mounting (Lower Frame Mounting Brackets) Lower Frame Mounting Brackets) Front Front (2) 12mm x 35mm Hex Bolts Insert a Plastic Washer between (2) 12mm Lock Washers the Grille Guard and the Frame (2) 12mm Flat Washers Mounting Bracket on each 12mm (2) 12mm Plastic Washers Hex Bolt...
- Page 8 Opening the hood using the tilt-forward mechanism for 2007-13 Tundra, 08-14 Sequoia models. Pull handle to "open" Quick Release. Loosen the Upper bolts (only if necessary) to open the hood. Pull Grille Guard to the "open" position. 1-866-926-2867 | 39 St. Mary’s Place, Freeport, NY 11520 | www.blackhorseoffroad.com...
- Page 9 Closing the hood using the tilt-forward mechanism for 2007-13 Tundra, 08-14 Sequoia models. Push Grille Guard back Quick Release in to the "closed" position. "closed" position. Front To protect your investment, wax this product after installing. Regular waxing is recommended to add a protective layer over the finish.
