Leds - D-Link DIR-865L User Manual

Section 1 - Product Overview
1
Power LED
2
Internet LED
3
WPS Button
D-Link DIR-865L User Manual
Hardware Overview
1
3
A solid green light indicates a proper connection to the power supply. The light will blink green during
the WPS process. The light will blink orange during boot up.
A solid light indicates a good connection on the Internet port and to the Internet. If the LED is orange,
the connection is good but the router cannot connect to the Internet.
Press to start the WPS process. The Power LED will blink during this process.

LEDs

2
6
