Section 1 - Product Overview
1
USB Port
2
LAN Ports (1-4)
3 Internet Port
4 Reset Button
5
Power Button
6
Power Receptor
D-Link DIR-865L User Manual

Hardware Overview

1
2
4
6
Connect a USB flash drive to share content throughout your network.
Connect 10/100/1000 Ethernet devices such as computers, switches, storage (NAS) devices and game consoles.
Using an Ethernet cable, connect your broadband modem to this port.
Press and hold for 6 seconds to reset the device back to the default factory settings.
Press the power button to power on and off.
Receptor for the supplied power adapter.

Connections

3
5
5
