- Page 1 U S E R G U IDE Plantronics VoYaGEr ™ 510-UsB BLUETOOTH HEADSET SySTEm ®...
-
Page 2: Table Of Contents
T ABLE OF CONTENTS PACKAGE CONTENTS Headset PerSonoCall ® Package Contents (Front and Side View) Software CD Features Charging Powering Pairing Installing PerSonoCall Software Adjusting Fit Using Your Headset Indicator Lights Troubleshooting 3 Ear Tips Headset AC Charger (Small, Medium, Large) Technical Assistance Warranty And Service Regulatory Notices Headset USB Charging Cable Charging Stand REGISTER YOUR PRODUCT ONLINE USB Extension Cable (3') Visit www.plantronics.com/productregistration to register your product online so we can provide you with the best possible service and technical support. Travel Pouch USB Bluetooth Adapter... -
Page 3: Features
FEA TURES CHARGING Horizontal Boom Adjustment Call Control Button Charge Connection Noise-Canceling Microphone with WindSmart Technology ® AC Charging USB Charging Power/Mute Button Listen Volume Adjust Button +/- Ear Tip Pairing/Connect Button AC Charging USB Charging with Charging Stand with Charging Stand Indicator Light Before using, you must first charge your headset. The indicator light flashes red while charging and turns solid blue when the headset is fully charged. 20 minutes = minimum charge 3 hours = full charge NOTE: Do not use headset while charging and do not connect the charger while headset is in use. -
Page 4: Powering
Powering USB Bluetooth Adapter Turn on both devices. 1. Simultaneously press the listen volume 2. While the headset is flashing red and adjust button marked + (volume up) blue, use the phone menu to search and the call control button. Release the for Bluetooth devices and select “510 Plantronics” . buttons when the indicator light begins to flash red then blue. 3. When prompted for passkey enter 0000. The headset will flash blue when paired successfully. The USB Bluetooth adapter is automatically powered on upon inserting into the USB port of the computer. If your USB port on the computer is hard to access, you can use the USB extension cable. NOTE: The USB Bluetooth adapter is automatically active with the current paired headset upon... - Page 5 PAIRING INSTALLING PERSONOCALL ® SOFTWARE Pairing Headset with USB Bluetooth Adapter Plantronics PerSonoCall software provides the link between your Bluetooth headset and ® the softphone application on your computer. PerSonoCall software provides the ability to remotely detect and answer/end a call from your softphone application via the headset call control button. In addition PerSonoCall provides some basic configuration and status information about 2 sec. the system. See page 10 for more details. 1. With the CD inserted, go to the PerSonoCall main screen and click on “Install the PerSonoCall Software.” 2. Your softphone may require you to choose which audio device you wish to use. Please refer to softphone documentation for details. NOTE: The headset and USB Bluetooth adapter are paired to each other at the factory. However, if you have purchased a USB Bluetooth adapter separately, or if you wish to use a replacement headset with your existing adapter, the units must be paired.
-
Page 6: Installing Personocall Software
INST ALLING PERSONOCALL SOFTW ARE Right click on the headset system tray icon and choose “Options” . This will bring up the PerSonoCall Basic Options and Current Status Screens. Basic Options Screen Current Status Screen NOTE: Some PerSonoCall features are grayed and not applicable to the Voyager 510-USB system. NOTE: Some PerSonoCall features are grayed and not applicable to the Voyager 510-USB system. Launch PerSonoCall Whenever Windows Starts ... -
Page 7: Adjusting Fit
ADJUSTING FIT Inserting a New Ear Tip Wearing the Headset Rotate the microphone horizontally and vertically as illustrated, to select for left or right ear wearing. The illustration shows conversion from right to left ear wearing. Reverse the procedure to convert from left to right ear wearing. Replacing the Ear Tip Slide the headset over and behind your ear. Press gently towards your ear for a snug fit. Adjust the microphone position so that it is directed towards your mouth. -
Page 8: Using Your Headset
Switching a Call From Headset to Phone been redialed. For Softphones Not Compatible with PerSonoCall To switch an active call from your headset Rejecting a Call to your phone, press and hold the call Check the PerSonoCall compatibility list at www.plantronics.com/personocall for the most control button until you hear a tone. current information on softphone compatibility. When receiving an incoming call, press When you hear a second tone, the transfer and hold the call control button. You will If your softphone is not currently supported by PerSonoCall, remote detection and answer/ has been completed and you can release hear a tone. When you hear a second end via the headset does not function. Pressing the call control button on the headset the button. -
Page 9: Indicator Lights
USING YOUR HEADSET INDICA TOR LIGHTS Adjusting Volume Headset Indicator Lights Headset Status Light Power Flashes Blue Charging Flashes Red Fully Charged Solid Blue Battery Low Flashes Red Pairing Flashes Red and Blue To increase listening volume, press the upper end (+) of the volume button. To decrease listening volume, press the lower end (-). Bluetooth Device To adjust the listen or speak volume of the softphone, please refer to the softphone Flashes Blue Connected to Headset user documentation. To adjust the listen or speak volume of the audio device on the computer, use the Sound and Audio Device section on the control panel. Bluetooth USB Adapter Indicator Lights Muting a Call Action Light Disconnected from the Headset ... -
Page 10: Troubleshooting
TROUBLESHOOTING FOR VOY AGER 510-USB Problem Solution Problem Solution My Voyager headset does not work • Check compatibility list on www.plantronics.com/ Sound in headset is distorted. • Lower the listen volume on your softphone until with the softphone I am using on my personocall to ensure your softphone is I can hear echo in headset. the distortion disappears. PC. (I cannot answer or disconnect compatible for remote answer and disconnect. -
Page 11: Technical Assistance
• This warranty lasts for one year from the date of purchase of the Products. advance in order for you to make necessary modifications to maintain uninterrupted service. If trouble is experienced with this unit, for repair or warranty information, please contact • This warranty extends to you only if you are the end user with the original purchase customer service at (800) 544-4660. If the equipment is causing harm to the network, the receipt. telephone company may request that you disconnect the equipment until the problem is resolved. DO NOT DISASSEMBLE THIS EQUIPMENT: It does not contain any user serviceable components. • We will, at our option, repair or replace the Products that do not conform to We recommend the installation of an AC surge arrester in the AC outlet to which this equipment the warranty. We may use functionally equivalent reconditioned/refurbished/ is connected. Telephone companies report that electrical surges, typically lighting transients, are remanufactured/pre-owned or new Products or parts. very destructive to customer terminal equipment connected to AC power sources. • To obtain service, contact Plantronics in the United States at (866) 363-BLUE (2583) EXPOSURE TO RF RADIATION and in Canada at (800) 540-8363. If you need additional information, please contact our service centers at the numbers provided. The internal wireless radio operates within the guidelines found in radio frequency safety standards and recommendations, which reflect the consensus of the scientific community. • THIS IS PLANTRONICS’ COMPLETE WARRANTY FOR THE PRODUCTS. Independent studies have shown that the internal wireless radio is safe for use by consumers. Visit www.plantronics.com for more information. • This warranty gives you specific legal rights, and you may also have other rights which vary from state to state or province to province. Please contact your dealer or our INDUSTRY CANADA NOTICE service center for the full details of our limited warranty, including items not covered by Radio Equipment this limited warranty.
