Plantronics Voyager 510S Setup Manual

Plantronics Voyager 510S Setup Manual

Office headset system
Hide thumbs Also See for Voyager 510S:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Instructions, User Manual
5 Easy Steps
The fastest way to set up your Plantronics
Voyager
510S Office Headset System with
™
your desk phone and Bluetooth
Base Power
Adapter
Voyager 510S
Headset Base
HL10
Automatic
Handset Lifter*
Voyager 510S
Headset
Plantronics Voyager 510S

mobile phone

®
*Not included in all configurations
S
G
e t u p
u i d e

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Voyager 510S and is the answer not in the manual?

Questions and answers

Related Manuals for Plantronics Voyager 510S

Summary of Contents for Plantronics Voyager 510S

  • Page 1: Mobile Phone

    5 Easy Steps The fastest way to set up your Plantronics Voyager 510S Office Headset System with ™ your desk phone and Bluetooth Base Power Adapter Voyager 510S Headset Base HL10 Automatic Handset Lifter* Voyager 510S Headset Plantronics Voyager 510S mobile phone ®...

  • Page 2: P Lantronics V Oyager

    Please refer to the separate Safety Instructions for important product safety information prior to installation or use of the product. Voyager 510SL With Automatic Handset Lifter* Adds: HL10 Automatic Handset Lifter *Automatic Handset Lifter is bundled with certain Voyager 510S configurations and also available separately. Voyager 510SL+ Adds: Online Indicator Light Accessories are available separately.
  • Page 3 & a nstall artiP Fit the Headset Slide the headset over and behind your ear, then press gently toward your ear. Rotate the microphone boom until it is pointed toward your mouth. If the eartip is uncomfortable, install a different eartip. See below. For your safety and comfort, the eartip should never be inserted into the ear canal.
  • Page 4 You will use the Automatic Handset Lifter or… Your phone does NOT have built-in headset functionality (no Headset button). Configuration A Handset Coil Cord Plantronics Voyager 510 ase to hone Unplug the handset coil cord from the desk phone handset port [A], then plug it into the handset port [B] on the Headset Base.
  • Page 5 Use Configuration B if: You will NOT use the Automatic Handset Lifter and… Your phone has built-in headset functionality (a Headset button). Configuration B 1. Plug the short BLACK Phone Cable that is pre-installed on the Headset Base into the Headset port [C] on the desk phone.
  • Page 6 The indicator light will flash while the headset battery is charging. The light will change to solid Plantronics Voyager 510 ower and harge Insert into...
  • Page 7 It lets you answer and end calls without being near your phone. The HL10™ Automatic Handset Lifter is included with certain Voyager 510S configurations and is also available separately. See www.plantronics.com/Voyager510S for a complete list of accessories.
  • Page 8 . Slide the Handset Lifter Arm under the handset until the lifter base touches the side of the phone. Slide the Lifter up to where it nearly touches the handset earpiece and hold. Plantronics Voyager 510 Handset Lifter Arm Setup Guide...
  • Page 9 . With the other hand, press the Call Control Button on the headset. This will activate the Handset Lifter and lift the handset from the phone. If you hear a dial tone, the lifter height is set correctly and needs no adjustment. Press the Call Control Button to return the handset to the cradle.
  • Page 10 Test the Lifter to verify positioning by pressing the Call Control Button on your headset to activate the Lifter and listen for a dial tone. . Press to adhere the Lifter to the desk phone. firmly Plantronics Voyager 510 Peel back mounting tape protective strips (3 places)

  • Page 11: Powering The Headset On And Off

    For your safety, do not use headset at high volumes for extended periods of time. Doing so can cause hearing loss. Always listen at moderate levels. For more information on headsets and hearing visit: www.plantronics.com/healthandsafety If your desk phone has a volume control, set it to mid-range.
  • Page 12 You will be able to make minor adjustments to speaking volume while on a call using the Speaking Volume Control on the back of the base. Plantronics Voyager 510 Listening Volume Switch Position 1 = Loudest...
  • Page 13 See page 9. Set the IntelliStand Feature The Voyager 510S IntelliStand feature allows you to choose how to activate your headset when answering or making a call. Consider how you’ll use your headset to determine the best setting for you.
  • Page 14 Pairing Headset and Base Your Voyager 510S Bluetooth Headset System comes from the factory with the headset and base already paired. However, if you have purchased a base unit separately, or if you wish to use a replacement headset with your existing base unit, the units must be paired as follows: Note: Make sure your headset is not connected to any other Bluetooth device when attempting to pair.
  • Page 15 For your safety, do not use headset at high volumes for extended periods of time. Doing so can cause hearing loss. Always listen at moderate levels. For more information on headsets and hearing visit: www.plantronics.com/healthandsafety To Place, Answer, or End Calls on your Bluetooth Mobile Phone...
  • Page 16 Note: This process only disables online and standby indicator lights when headset is connected to a Bluetooth device, such as a mobile phone or base. All other indicator lights, such as low battery, will continue to function. Plantronics Voyager 510 Setup Guide . To...

  • Page 17: Indicator Lights

    510s l oyager Indicator Lights Base Status Base Light Headset and base unit are Solid red on and a wireless connection is established Headset charging Flashes yellow Headset fully charged Solid yellow Bluetooth link active Solid blue Headset in talk mode Flashes blue Red flashes slowly, then quickly Headset out of range or...

  • Page 18: Common Questions

    Listening Volume Switch on the Headset Base. I hear static. • Make sure there is at least 12” between your Voyager 510S base and your computer, and 6” between your base and your telephone. If adjusting the distance doesn’t help, your headset is going out of range, move closer to base or cell phone.

  • Page 19: Additional Information And Support

    • Do not use solvents or other cleaning agents. Battery replacement The custom battery supplied in your headset should last 2–3 years. When talk time decreases signifi- cantly, the battery may need replacing. Please call Plantronics at 800-544-4660 Ext. 5538 and ask for service. Still having problems? Given the hundreds of different types of phones, it’s possible a trick or two may...
  • Page 20 © 2007 Plantronics, Inc. All rights reserved. Plantronics, the logo design, HL10, IntelliStand, Plantronics Voyager, and Sound Innovation are trademarks or registered trademarks of Plantronics, Inc. The Bluetooth® word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by Plantronics, Inc.
