TX6000
6 Channel Mic/Line Mixer

Description

The TX6000 is a high specification, single rack space, 6 channel mic/line mixer suitable for desk
or rack mounting. The mixer is designed to operate from both AC mains power as well as 24
volts DC.

Inputs

Six dual mic/line inputs are provided. The mic inputs are active balanced and feature 3 pin XLR
female sockets. Each channel also includes dual female RCA line/aux sockets.

Outputs

The TX6000 features a balanced line output via a 3 pin XLR male socket. A mono tape output
is also available via dual female RCA sockets. A 1/4" mono headphone socket is included on
the front panel.

Controls

Front panel controls include a master output level control plus overall bass and treble controls.
Individual channel level controls are provided for all six inputs.

Metering

A 7 segment LED meter is provided for the master output. A power "on" LED is also included.

Muting

Muting is available via the optional VOX operated plug-in TX3010 or TX3014 precedence
cards. The TX3010 provides priority from channel 1 over all other channels. The TX3014 pro-
vides two levels of priority. Channel 1 is the master mute channel and overrides channels 2-6,
whereas channels 2 will mute channels 3-6 only.

Tone Generators

The ATC5488 is an optional plug-in accessory providing 4 tones (Bell, Pre-Announce Chime,
Alert and Evacuate). The evacuate and alert tones comply with Australian Standard AS2220.1.
The ATC5488 plugs into the main board via a 7 pin connector. Activation wires can be fed
through a rear panel slot below the 24V DC connector. Each tone can be activated by a sim-
ple contact closure.

Phantom Power

Phantom power (18V DC) is provided on all mic inputs.
