- Page 1 INSTALLATION AND OPERATION MANUAL ES SERIES RACKMOUNT MIXER ESMIX...
-
Page 2: Important Safety Information
Assurez-vous que l’appareil est hors tension avant de connecter les hauts parleurs. Veri ez que la sortie des enceintes soit protégées contre un contact physique. Respecter les polarités des terminaux ainsi que le câblage des enceintes pendant le fonctionnement afin d’assurer une utilisation sécurisee. ES SERIES INSTALLATION AND OPERATION MANUAL... - Page 3 INTRODUCTION & CONTENTS ES SERIES Congratulations on choosing Australian Monitor for your Introduction professional audio requirements. Features & Protection Features The design of our ESMIX embraces all the aspects of a well-designed commercial mixer. The visual design, mechanical, electrical and sonic...
- Page 4 Bass and Treble Tone Controls • Record Output • Line Output • Integrated 5 Tone Generator with volume control ° Evac ° Alert ° Intruder ° Bell ° Chime • 1 Rack Unit Size ES MIXER BLOCK DIAGRAM ES SERIES INSTALLATION AND OPERATION MANUAL...
-
Page 5: Front Panel
This LED indicates the unit is outputting a signal. POWER This LED indicates the unit is on. POWER SWITCH This switches the power to the unit on and off. The up position is on. ES SERIES INSTALLATION AND OPERATION MANUAL... -
Page 6: Rear Panel
5.5/2.1mm plug with tip positive and ring negative connection. PHANTOM POWER 12V phantom power is available for condenser or electret microphones on the XLR input when this switch is pushed down. ES SERIES INSTALLATION AND OPERATION MANUAL... - Page 7 Please note: ‘CHIME’ tone must play to completion before it may be retriggered. NOTES • To activate a tone trigger input, short the relevant input to GND. The selection must be stable for longer than 150ms. • Each tone is played to completion even if the trigger selection is removed during playback. • A higher priority tone trigger will interrupt a lower priority tone being played. EVAC - Highest to CHIME - Lowest • After deselection and completion of playing a higher priority tone, any selected lower priority tone will be played. Exceptions are BELL and CHIME tones which will not be played. ES SERIES INSTALLATION AND OPERATION MANUAL...
-
Page 8: Installation
Balanced input wiring (shielded pair cable) is recommended. Unbalanced RCA wiring should be keep as short as possible. Female XLR Pin1 Gnd Pin3 Cold - Pin2 Hot + Male XLR Pin2 Hot + Pin3 Cold - Pin1 Gnd Tip: Hot + Shield: Gnd ES SERIES INSTALLATION AND OPERATION MANUAL... -
Page 9: Troubleshooting
1 and 2 Disable priority function using DIP switches on the rear panel. Tones do not sound when triggered Tone generator volume too low Increase the volume by turning the tone volume clockwise ES SERIES INSTALLATION AND OPERATION MANUAL... - Page 10 DIMENSIONS ES SERIES INSTALLATION AND OPERATION MANUAL...
-
Page 11: Specifications
FINISH Powder Coated Steel COLOUR Black 24VDC Power pack, Rubber Feet x 4, ACCESSORIES 1 label sticker sheet, 1 Manual APPROVALS CE, IEC, RCM Due to continuous improvements, all specifications are subject to change ES SERIES INSTALLATION AND OPERATION MANUAL... - Page 12 ENGINEERED BY AUSTRALIAN MONITOR Address: 1 Clyde St, Silverwater NSW 2128 Australia. Website: www.australianmonitor.com.au International enquiries email: international@australianmonitor.com.au ABN 35 007 573 417...
