Clever Features, Contractor Friendly
TX6000
6 Channel Mic/Line Mixer
Operating Manual
TX6000, 6 Channel Mic/Line Mixer
Product Description
The TX6000 is a 6 channel audio mixer that operates from 115 VAC @ 60 Hz or 24 VDC via an external
battery supply. The TX6000 is 1 standard rack unit high (44mm) and has a standard rack width of 482mm.
For table mounting, rubber feet are supplied but these can be removed if rack mounting is intended. Six
dual purpose inputs consisting of XLR balanced mic inputs and dual RCA aux/line level inputs are
included. Channel 6 has a less sensitive aux/line level input to enable it to accept a CD player or similar
high level inputs. The TX6000 also features a remote VCA for the Master Volume.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for AUSTRALIAN MONITOR TX6000
Summary of Contents for AUSTRALIAN MONITOR TX6000
-
Page 1: Product Description
Product Description The TX6000 is a 6 channel audio mixer that operates from 115 VAC @ 60 Hz or 24 VDC via an external battery supply. The TX6000 is 1 standard rack unit high (44mm) and has a standard rack width of 482mm. -
Page 2: Front Panel Features
(0) position. Master Control The master control sets the overall output level of the TX6000. It is used in conjunction with the input level controls. When setting up levels, please ensure that proper gain structure practices are followed. In other words, it is not advisable to run the input channels at 10 and the output level at 1. -
Page 3: Rear Panel Features
Channel 6 has been designed to accept higher level line inputs such as CD players. When using a CD player with the TX6000, please ensure it is plugged into the channel 6 line input. Dual RCA connectors are provided to allow for the simple connection of domestic stereo devices such as tape... -
Page 4: Phantom Power
‘on’ position, shorting the centre pin and the pin closest to the rear of the TX6000. To turn phantom power off, move the link to short the centre pin and the pin closest to the front of the TX6000. -
Page 5: Important Safety Information
Fuse Sizes TX6000 Mixer Mains 115 VAC: 1.25 Amperes Slow Blow Important Safety Information 1. Save the carton and packing material even if the equipment has arrived in good condition. Should you ever need to ship the unit, use only the original factory packing. - Page 6 Australian Monitor Audio Inc is not responsible for damage to loudspeakers for any reason. 18. Do not ground any red (“hot”) terminal. Never connect a “hot” (red) output to ground or to another “hot”...
