- Page 1 MX81 8 CHANNEL MIC/LINE MIXER INSTALLATION AND OPERATION MANUAL...
- Page 2 Precautions should be taken so that the Australian Monitor Inc is not responsible for damage to means of grounding of a piece of equipment is not defeated. loudspeakers for any reason.
-
Page 3: Table Of Contents
INTRODUCTION AND CONTENTS The MX81 is an 8 channel audio mixer that operates from 110/230-240 INTRODUCTION VAC @ 50/60 Hz or 24 VDC via an external 24VDC supply. FRONT PANEL The MX81 offers high quality audio performance & a wide array of features in a standard 1 RU size. -
Page 4: Front Panel
CHANNEL TONE CONTROLS NOTE: When using the 24VDC Each input has a 2 band EQ. socket the unit is on regardless Bass – +/-12dB 100Hz shelving of switch position. Treble – +/-12dB 10kHz shelving PAGE 4 MX81 INSTALLATION & OPERATION MANUAL... -
Page 5: Rear Panel
This 2.1mm x 5.5mm barrel socket is provided for 24V emergency systems and is not switched by the front panel power switch. Note:The 24VDC socket does not provide trickle charge facility. Tip of the connector is positive. PAGE 5 MX81 INSTALLATION & OPERATION MANUAL... -
Page 6: Internal Adjustments
HEADPHONE ROUTING This switch is accessible through the lid of The headphone level can be routed so the MX81. 15V phantom power is available that it is affected by the master volume. for condenser or electret microphones on The default factory setting is pre master... -
Page 7: Installation & Troubleshooting
Volume turned down Check volume controls Tones and/or VCA control does not work Module not installed Purchase optional modules Condenser microphone does not work Phantom power not switched on Switch on phantom power PAGE 7 MX81 INSTALLATION & OPERATION MANUAL... -
Page 8: Basic Setup & Operation
Turn the amplifiers off. Connect the MX81 output to the amplifiers' Setting up correct gain structure through the whole system is line level input. Check that the MX81 is on, and then turn on the important to achieve optimal results. The following step by step amplifiers. -
Page 9: Dimensions
DIMENSIONS PAGE 9 MX81 INSTALLATION & OPERATION MANUAL... -
Page 10: Block Diagram
BLOCK DIAGRAM PAGE 10 MX81 INSTALLATION & OPERATION MANUAL... -
Page 11: Specifications
+21dBu 15V DC PHANTOM POWER OUTPUTS MASTER OUT Nominal Level 0dBu into 1kohm Imp 100ohm MONO HEADPHONE OUT Nom -6dB into 200ohm Imp 10ohm MONO REC OUT Nom -12dB into 10kohm Imp 10kohm PAGE 11 MX81 INSTALLATION & OPERATION MANUAL... - Page 12 AUSTRALIA AND NEW ZEALAND www.australianmonitor.com.au SYDNEY MELBOURNE BRISBANE ADELAIDE PERTH AUCKLAND (NSW & ACT SALES) (VIC & TAS SALES) (QLD SALES) (SA & NT SALES) (WA SALES) (NZ SALES) 149 Beaconsfield 22/277 42 Commercial Road 31 Walsh Street 299 Fitzgerald Street Unit B, 11 Piermark Street Silverwater Middleborough Road...
