AUSTRALIAN MONITOR AMIS120P Specification

AMIS120P
120W Power Amplifier

Description

The AMIS120P is a 120 watt power amplifier with outputs for 4 and 8 ohms, 70 and 100 volt
line. It may be desk or rack mounted. The AMIS120P features a flat screwdriver accessible gain
control on the rear panel. This amplifier features a status LED. The amplifier may operate from
mains power or 24V DC.
Inputs and Outputs
The AMIS120P features a balanced line level XLR input with a parallel output to feed additional
power amplifiers. The unit has industry standard 3 pin XLR microphone sockets. The AMIS120P
features 100 volt, 70 volt, 8 and 4 ohm isolated transformer outputs via a rear panel barrier strip.
Protection
Internal current limiting protects the amplifier from both overload and overdrive conditions.
Should the amplifier be overdriven, a current limiter will protect the unit, and in a worst case
scenario the amplifier will shut down until the problem is resolved. Once the problem is fixed
(shorted speaker line, or overdriven input), the amplifier will automatically reset and continue
operation. The AMIS120P features generous heatsinking.
Australian Monitor Installation Series amplifiers feature a protection network that provides
greater stability and performance. Our amplifiers are recognised
worldwide for their reliability and this is due to the extensive levels of
current limiting which protect the amplifiers from both overload and
overdrive conditions.
