AUSTRALIAN MONITOR AMIS1202P Specification

AMIS1202P
120W + 120W
Dual Channel Power Amplifier

Description

The AMIS1202P is a dual channel 120W + 120W power amplifier designed to deliver continuous
full range performance in a compact and reliable package. The AMIS1202P is two independent
amplifiers in the one chassis making it the perfect choice for multi-zone or multi-channel applica-
tions.
Inputs and Outputs
The AMIS1202P provides dual balanced XLR inputs (male and female) per channel. These two
inputs are wired in parallel enabling a line level "split" to be taken from the second input of each
channel.
70 volt line and 4/8 ohm outputs are available via the rear panel barrier strip.
Controls and Metering
A recessed input attenuation control for each channel is included on the rear panel. These pots are
accessible using a screwdriver.
The AMIS1202P features a signal-present LED per channel and power-on LED.
Protection
The AMIS1202P features "slow start" and dual AC and DC fuse protection. Also featured is auto-
matic speaker protection. The AMIS1202P includes generous heat sinking for reliable operation in
even the most extreme conditions.
Australian Monitor Installation Series amplifiers feature a protection network that provides greater
stability and performance. Our amplifiers are recognised worldwide for their
reliability and this is due to the extensive levels of current limiting which pro-
tect the amplifiers from both overload and overdrive conditions.
