AUSTRALIAN MONITOR AMIS1202P Operating Manual

2 x 120w power amplifier

Table of Contents

Download this manual

Clever Features, Contractor Friendly

AMIS1202P

2 x 120w Power Amplifier

Operating Manual

AMIS1202P, 2 x 120 Watt Power

Amplifier

Product Description

The AMIS1202P is a dual 120 watt power amplifier designed for commercial installations. The one unit

contains two independent 120 watt amplifiers for either stereo or dual zone applications. The AMIS1202P

can be used for either low impedance (4 or 8 ohm) or 70/100v line speaker systems per channel. The

amplifier can be mounted in a standard 19" equipment rack (rack ears supplied) or it can be used on a shelf

or table. The AMIS1202P features a line level input (with parallel output) per channel and is normally used

with mixers, mixer amplifiers or other power amplifiers.

Table of Contents

Do you have a question about the AMIS1202P and is the answer not in the manual?

Page 1: Product Description
19” equipment rack (rack ears supplied) or it can be used on a shelf or table. The AMIS1202P features a line level input (with parallel output) per channel and is normally used with mixers, mixer amplifiers or other power amplifiers.
Page 2: Front Panel Features
In 24vdc operation the LED will always be on. Signal LED The green “Signal” LED’s located next to the On LED indicate that the AMIS1202P is receiving audio signal via its line level inputs. One LED is provided per channel. The signal LED’s are a simple way of trouble-shooting installations especially in multi amplifier projects.
Page 3: Level Control
24 Volt DC Power Inlet The AMIS1202P feature optional 24VDC power to run off a battery back-up if required. This is connected via the rear terminal strip. The front panel Power Switch will not switch DC power ‘on’ or ‘off’ in DC operation.
Page 4: Important Safety Information
Fuse Sizes Mains, 230VAC: 4 Amperes Slow Blow. Notes: The DC fuse is located on the circuit board. This is a feature of the AMIS series amplifier, which is equipped with a current limiting circuit preventing excessive DC current, thus eliminating the risk of blowing high tensions fuses.
Page 5 Australian Monitor is not responsible for damage to loudspeakers for any reason. 18. Do not ground any red (“hot”) terminal. Never connect a “hot” (red) output to ground or to another “hot”...
