- Page 1 C O N F I D E N T I A L Disassembly and Reassembly Terra-Q 13 (XE530QDA) Mobile Biz. Division...
- Page 2 CONFIDENTIAL Turn-off the system ※ Turn off power before disassembling. (Turn Off : Press the power button for 8 seconds.) Mobile Biz. Division...
- Page 3 CONFIDENTIAL Remove CASE-REAR (1) 1. Check uSD card - If there is uSD Card, Remove Micro SD card 2. 1)Remove 4 rubbers on CASE-REAR Mobile Biz. Division...
- Page 4 CONFIDENTIAL Remove CASE-REAR (2) 2)Remove 4 Screws on Case-Rear 3) Disassemble the CASE-REAR from the gaps between the hinges and frame. - Open the CASE-REAR from the gaps between the hinges and frame. - Jig can be a good tool for disassembly Caution : Use glove.
- Page 5 CONFIDENTIAL Remove Battery 3. 1)Remove battery bracket - Pull the connector carefully 3. 2)Disconnect battery connector and remove 4 screws - Use caution! It can be easily broken. - All service should be performed after disconnecting battery connector Mobile Biz. Division...
- Page 6 CONFIDENTIAL LCD Disassembly 4. 1)Remove 6 screws and disconnect LCD connector 4. 2)Open with Hinge and separate system and LCD part Mobile Biz. Division...
- Page 7 CONFIDENTIAL System part Disassembly (1) 5. 1)Remove Brackets and FAN - Remove 2 screws for sub Bracket - Remove 3 screws for main Bracket - Remove 3 screws for FAN 5. 2)Disconnect all Cables - 2 spk Cables, Main2Sub FPC, TP FFC, 2Antenna Cables, KBD FFC, - We can replace Antennas and SPK, TP FFC, Main2Sub FPC without further disassembly.
- Page 8 CONFIDENTIAL System part Disassembly (2) 5. 3)Remove Main, Sub Board and Touchpad - Remove 1 screw for sub board - Remove 6 screw for main board - Remove 4 screw and AL tape for Touchpad 5. 4)Touchpad should be pulled to upper side Mobile Biz.
- Page 9 CONFIDENTIAL Re-Assembly Follow disassembly in reverse order Mobile Biz. Division...
