- Page 1 C O N F I D E N T I A L C O N F I D E N T I A L Disassembly and Reassembly Chromebook Plus (XE520QAB, XE521QAB) Samsung...
- Page 2 CONFIDENTIAL Disassembly (1) ※ Turn off the power before disassembling the system. (Turn Off : Press the power button during 8 seconds.) Samsung...
- Page 3 1. Check uSD card and S-Pen insert - If there is uSD Card and Pen, Remove them S-Pen Micro SD card 2. Remove 4 Rubbers on CASE-REAR - Remove 4 points of Rubber from CASE-REAR. - Rubber : BA98-01441A Samsung...
- Page 4 CONFIDENTIAL Disassembly (3) 3. Remove 4screws under Rubbers on Rear Case - Screw : 6001-003312 4. Disassemble the CASE-REAR with Jig Samsung...
- Page 5 CONFIDENTIAL Disassembly (4) 5. Disconnect Battery Cable first. - Pull up the battery cable from main board and remove 6 screws - Screws : 6001-003164 6. Remove screw and battery pack. - Remove battery pack from system Samsung...
-
Page 6: Disconnect All Cables
: LCD, Antenna , Speakers, Pen Detect 7. Remove the screws on the board - Side Bracket 5points : 6001-003312 - Main board 4points : 6001-003312 - Sub board 1points : 6001-003312 - BTN Assy 2points : 6001-001650 - Camera 1point : 6001-001650 Samsung... - Page 7 CONFIDENTIAL Disassembly (6) 8. Remove the side brackets, Main and Sub B’d * Caution : It can be damaged when you pick the mainboard up from front Ass’y. Pay attention on Audio jack and Type-C 9. Remove Speakers Samsung...
- Page 8 CONFIDENTIAL Disassembly (7) 10. Remove the Touchpad FFC and WLAN FFC. 11. Remove WLAN PBA and Antennas Samsung...
- Page 9 CONFIDENTIAL Disassembly (8) 12. Release Touchpad screws : 3points - Screw : 6001-001925 13. Slide up the touchpad module Pull Push Samsung...
- Page 10 CONFIDENTIAL Reassembly Follow sequence 13 to 2 Samsung...
