Summarization of Contents
Safety Information
Correct Disposal of Product
Proper disposal of electrical and electronic equipment according to regulations.
Model vs. Toy Warning
This is a model, not a toy; handle with care due to sharp edges.
Approved Transformer Usage
Specifies approved transformer types and voltage ratings for operation.
Operation and Maintenance
Wheelset Lubrication
Apply resin- and acid-free oil to wheelsets for smooth running.
Break-in Procedure
Run locomotive in for 25 minutes in each direction without load for optimal performance.
Traction Tyre Replacement
Instructions for changing traction tyres.
PluX Interface Configuration
Headlight Functions (F0f/F0r)
Assignment for white headlights at the front and rear.
Train End Lighting (AUX1/AUX2)
Assignment for red train end lights at the rear and front.
Internal Lighting (AUX3/AUX5)
Assignment for engine room lighting and driver cab lighting.
Signal Functions (AUX4, AUX6, AUX7)
Assignment for wrong signal (Pc2) and shunting signals (Tb1).
Radio Interference Suppression
Capacitor Specification
Track connection capacitor must have at least 680 nF for radio interference suppression.
