Bose Bluetooth Owner's Manual

Owner's guide
Hide thumbs Also See for Bluetooth:
Table of Contents

Advertisement

Quick Links

B
H
®
LUETOOTH
EADSET
Owner's Guide | Guía de usuario | Notice d'utilisation

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Bluetooth and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Bose Bluetooth

Summary of Contents for Bose Bluetooth

  • Page 1 ® LUETOOTH EADSET Owner’s Guide | Guía de usuario | Notice d’utilisation...

  • Page 2: Safety Information

    Tab 6, 12 Tab 5, 11 Tab 4, 10, 16 Tab 3, 9, 15 Tab 2, 8, 14 English Safety Information Please read this guide WARNINGS: • Contains small parts, which may be Please take the time to follow the a choking hazard.

  • Page 3: Important Safety Information

    This product conforms to all EU Directive requirements as applicable Clean only as directed by Bose by law. The complete Declaration of Corporation. Unplug this product Conformity can be found at from the wall outlet before cleaning.
  • Page 4 – Do not attempt to service this product yourself. Opening or removing covers may expose you to dangerous voltages or other hazards. Please call Bose to be referred to an authorized service center near you.
  • Page 5 This equipment generates, Changes or modifications not expressly uses, and can radiate radio frequency approved by Bose Corporation could energy and, if not installed and used in void the user’s authority to operate accordance with the instructions, may this equipment.
  • Page 6 Tab 4, 10, 16 Tab 3, 9, 15 Tab 2, 8, 14 English Attribution The Bluetooth word mark and logos are registered trademarks of Bluetooth SIG, Inc. and any use of such marks by Bose Corporation is under license. Other agency markings FCC ID: A94BT1R FCC ID: A94BT1L...

  • Page 7: Table Of Contents

    English Tab 2, 8, 14 Tab 3, 9, 15 Tab 4, 10, 16 Tab 5, 11 Tab 6, 12 ONTENTS Preparing your headset Thank you ........Headset features .

  • Page 8: Preparing Your Headset

    Tab 4, 10, 16 Tab 3, 9, 15 Tab 2, 8, 14 English Preparing your headset Thank you ® ® We appreciate your choice of the Bose Bluetooth headset, which lets you hear and be heard, even as the noise levels around you change. Headset features Small size, advanced fit, and a few basic buttons and indicators make the headset easy to wear and easy to use.
  • Page 9 English Tab 2, 8, 14 Tab 3, 9, 15 Tab 4, 10, 16 Tab 5, 11 Tab 6, 12 Included with the headset: Power supply Additional StayHear™ USB cable tips (small and large) Power supply adapters Carry case (included where needed only)

  • Page 10: Charging The Headset

    Tab 6, 12 Tab 5, 11 Tab 4, 10, 16 Tab 3, 9, 15 Tab 2, 8, 14 English Charging the headset Before you use the headset, it is important to bring the power up to full charge for maximum talk time. Be sure the room temperature is between 40°F (5°C) and 95°F (35°C) and the product is at room temperature.
  • Page 11 3. To remove an adapter as needed, press back on the release (a) and lift the adapter up and off (b). Note: Bose recommends using a safety agency-approved surge protector on all electronic equipment.Voltage variations and spikes can damage electronic components in any system. A quality sup- pressor can eliminate the vast majority of failures attributed to surges and can be purchased at electronics stores.
  • Page 12 Tab 6, 12 Tab 5, 11 Tab 4, 10, 16 Tab 3, 9, 15 Tab 2, 8, 14 English 4. Plug the power supply into an AC (mains) wall outlet. Or, if you are using a computer to charge the headset, you may need to turn on the computer.

  • Page 13: Pairing Your Headset And Mobile Phone

    The first time you turn on your Bose Bluetooth headset, it is discoverable and ready for pairing. Your Bluetooth mobile phone can pair and connect to discoverable devices like the headset. On the phone, there is a list of these devices under Tools, Bluetooth Devices, or a similar menu title.
  • Page 14 Note: If the Bose headset does not appear in the list, press and hold the Call button on the headset until the Bluetooth light blinks (in about 5 seconds). This makes the headset manually discoverable so it shows up in the list for selection.

  • Page 15: Using The Headset

    Tab 6, 12 Using the headset When you wear the headset properly, it provides the comfort you expect from Bose. Fitting the headset to your ear The soft StayHear™ tip allows the headset to rest comfortably along the bowl of your ear. The wing part of the tip fits just under the ear ridge.
  • Page 16 Tab 6, 12 Tab 5, 11 Tab 4, 10, 16 Tab 3, 9, 15 Tab 2, 8, 14 English 2. Insert the tip into Ear ridge your ear canal just enough for the headset to rest in wing position. 3. Tilt the headset back (a) and press the tip wing (b) wing...

  • Page 17: Recognizing The Lights And Tones

    When you first turn on the headset, both indicator lights glow. • The battery indicator glows to show there is power. ® • The Bluetooth indicator glows blue to show the state of connection. In addition to these indicators, the headset emits tones in response to actions.
  • Page 18 Tab 6, 12 Tab 5, 11 Tab 4, 10, 16 Tab 3, 9, 15 Tab 2, 8, 14 English Battery light Bluetooth light status status While using the headset: Blue light: Green, solid - Up to 4.5 Slow flashing - The headset is hours of talk time or 150 discoverable for pairing.

  • Page 19: Using The Headset For Calls

    English Tab 2, 8, 14 Tab 3, 9, 15 Tab 4, 10, 16 Tab 5, 11 Tab 6, 12 Using the headset for calls You can respond to an incoming call or initiate a call with one press of the Call button. You may notice a brief tone when the headset reacts to each new action.

  • Page 20: Using The Multi-Point Feature

    Using the multi-point feature ® ® Multi-point enables your Bose Bluetooth headset to maintain an active connection with two mobile phones. So the headset is ready when you make or take calls on both a personal and a work...

  • Page 21: Pairing Another Mobile Phone

    3. Complete the pairing procedure specific to this phone. 4. Turn the headset off and then on again to allow the headset to connect to the two phones you want to use. Be sure to enable Bluetooth on the two phones you want connected.

  • Page 22: Connection Priority For Multiple Phones

    • To give priority to a third mobile phone that has been less recently used, you need to re-activate the connection. Do this by re-selecting the Bose BT1 in the device list on this phone. Multi-point call options When your headset is connected to two mobile phones, you can: Put an active call on hold and answer the other phone by pressing the Call button.

  • Page 23: Reference

    English Tab 2, 8, 14 Tab 3, 9, 15 Tab 4, 10, 16 Tab 5, 11 Tab 6, 12 Reference Troubleshooting Problem What to do The headset • Make sure both ends of the USB cable are firmly does not inserted.
  • Page 24 • Try the larger or smaller tip. The mobile • Make sure both the headset and mobile phone ® phone and the are turned on and the Bluetooth feature on your headset do not phone is activated. Refer to your phone instruc- pair.
  • Page 25 ® • Check the Bluetooth device list on your phone to be sure Bose BT1 is selected. – If it is selected, delete it from the list (refer to your phone instruction manual for details). – If it is no longer listed, repeat “Pairing your headset and mobile phone”...
  • Page 26 Tab 6, 12 Tab 5, 11 Tab 4, 10, 16 Tab 3, 9, 15 Tab 2, 8, 14 English What the other • Move closer to your mobile phone. person hears is • Make sure the phone is not near other wireless not clear.

  • Page 27: Customer Service

    Or for online support visit: • owners.Bose.com in the U.S. • global.Bose.com outside the U.S. To contact Bose by phone, refer to the address list on the inside back cover of this guide. Maintenance You can clean your headset, the StayHear™ tip, and wire mesh under the tip.

  • Page 28: Limited Warranty

    What you must do to obtain Limited Warranty service Return the product, with proof of purchase from an authorized Bose dealer, using the following procedures: 1. Contact the Bose organization in your country/region (visit Global.Bose.com for contact information in your country/ region) for specific return and shipping instructions.

  • Page 29: Technical Information

    English Tab 2, 8, 14 Tab 3, 9, 15 Tab 4, 10, 16 Tab 5, 11 Tab 6, 12 Technical information Weight: 0.42 ounces (12 grams) Power supply rating: Input: 100 VAC to 240 VAC, 0.15A Output: 5V, 1A Temperature ranges: Operate this product within the temperature range of -4°F to 140°F (-20°C to 60°C) only.

  • Page 30: Accessories

    Bose Customer Service. • To purchase an optional headset charger for your vehicle, contact your Bose dealer or Bose Customer Service. To contact Bose by phone, refer to the address list on the inside back cover of this guide.
  • Page 31 ORPORATION Denmark Italia The Mountain, 2605 Brondby Via della Magliana 876 Framingham, MA, 01701 04343-7777 Roma, 00148 877-335-2073 www.Bose.dk 06.60.292.555 owners.Bose.com www.Bose.it Deutschland Canada Japan D-61381 Friedrichsdorf 9133 Leslie Street, 06172-71040 Karakida Center bldg., Suite 120, L4B 4N1 www.Bose.de 1-53-9 Karakida,...
  • Page 32 Norge Hong Kong N-2213 Kongsvinger Suite 1203, Midas Plaza, 1 62-82-15-60 Tai Yau Street, San Po www.Bose.no Kong, Kowloon, Hong Kong Österreich (852) 21239000 Wienerbergstrasse 7 support_hk@Bose.com (10.OG) Finland 01-60404340 www.Bose.at Kornetintie 6b Helsinki, 380 +358 10 778 6900 Schweiz www.Bose.fi...
  • Page 33 ©2010 Bose Corporation, The Mountain, Framingham, MA 01701-9168 USA AM328784 Rev.00...
