Page 7: Introduction
Introduction ® This manual describes the functional, mechanical and interface specifications for the following Seagate ® Momentus 5400 FDE drives: • ST9120826A • ST9100826A • ST980821A • ST960814A • ST940811A These drives provide the following key features: • Trusted Drive technology including: •... -
Page 8: About Momentus 5400 Fde Disc Drives
1.2.1 Drive state upon shipment Upon shipment from the Seagate factory, the ATA Security Interface is enabled and functioning. The following is the detailed state of the drive upon shipment. • Full Disc Encryption (FDE) is active and functioning. All user data is encrypted on write and decrypted on read. - Page 9 Momentus drive. The encryption key is enabled and operational when the drive leaves the Seagate factory. No user id is required to access the drive, so the data on the drive is accessible to anyone possessing the drive. The drive will encrypt data without a user id.
- Page 10 Momentus 5400 FDE Product Manual, Rev. C...
-
Page 11: Drive Specifications
Drive specifications Unless otherwise noted, all specifications are measured under ambient conditions, at 25°C, and nominal power. For convenience, the phrases the drive and this drive are used throughout this manual to indicate ST9120826A, ST9100826A, ST980821A, ST960814A, and ST940811A model drives. Specification summary The specifications listed in this table are for quick reference. - Page 12 Table 1: Specifications Drive specification ST9120826A ST9100826A ST980821A ST960814A ST940811A Average seek, write (msec typical) 14.5 Full-stroke seek (msec) 22 (typical); 24 (max) Seek power (typical) 2.0 watts Read/write power (typical) Read: 2.50 watts; Write: 2.50 watts Idle mode (typical, low power) 1.40 watts Standby mode 0.96 watts (typical)***...
-
Page 13: Formatted Capacity
To determine the warranty for a specific drive, use a web browser to access the following web page: Warranty www.seagate.com/support/service/ From this page, click on the “Verify Your Warranty” link. You will be asked to provide the drive serial number, model number (or part number) and country of purchase. The system will dis- play the warranty information for your drive. -
Page 14: Recording And Interface Technology
Recording and interface technology Technology Specification Interface Parallel ATA Recording method RLL 0,11 Recording density BPI (bits/inch typical) 778,000 Track density TPI (tracks/inch typical) 126,000 Areal density (Gbits/inch max) 98.2 Spindle speed (RPM) (± 0.2%) 5,400 Internal data-transfer rate OD (Mbytes/sec max) I/O data-transfer rate (Mbytes/sec max) 100 (Ultra DMA mode 5) Interleave... -
Page 15: Seek Time
Seek time Seek measurements are taken with nominal power at 25°C ambient temperature. All times are measured using drive diagnostics. The specifications below are defined as follows: • Track-to-track seek time is an average of all possible single-track seeks in both directions. •... -
Page 16: Power Specifications
Power specifications The drive receives DC power (+5V) through the interface connector. 2.9.1 Power consumption Power requirements for the drives are listed in the table on page 10. Typical power measurements are based on an average of drives tested, under nominal conditions, at 25°C ambient temperature. •... -
Page 17: Conducted Noise
2.9.1.1 Typical current profile Figure 5. Typical 5V startup and operation current profile 2.9.2 Conducted noise Input noise ripple is measured at the host system power supply across an equivalent 15-ohm resistive load on the +5 volt line. Using 5-volt power, the drive is expected to operate with a maximum of 100 mV peak-to-peak square-wave injected noise at up to 10 MHz. -
Page 18: Power-Management Modes
2.9.4 Power-management modes The drive provides programmable power management to provide greater energy efficiency. In most systems, you can control power management through the system setup program. The drive features the following power-management modes: Table 3: Power management modes Power modes Heads Spindle Buffer... -
Page 19: Environmental Specifications
2.10 Environmental specifications 2.10.1 Ambient temperature Ambient temperature is defined as the temperature of the environment immediately surrounding the drive. Actual drive case temperature should not exceed 65°C (149°F) within the operating ambient conditions. Above 1,000 feet (305 meters), the maximum temperature is derated linearly by 1°C every 1000 feet. Operating 5°... -
Page 20: Vibration
2.10.5.2 Nonoperating shock The nonoperating shock level that the drive can experience without incurring physical damage or degradation in performance when subsequently put into operation is 800 Gs based on a nonrepetitive half-sine shock pulse of 2 msec duration. The nonoperating shock level that the drive can experience without incurring physical damage or degradation in performance when subsequently put into operation is 900 Gs based on a nonrepetitive half-sine shock pulse of 1 msec duration. -
Page 21: Electromagnetic Immunity
2.12 Electromagnetic immunity When properly installed in a representative host system, the drive operates without errors or degradation in performance when subjected to the radio frequency (RF) environments defined in the following table: Table 5: Electromagnetic immunity Performance Reference Test Description level standard... -
Page 22: Reliability
Information Technology Equipment (ITE). Emission levels are defined by EN 55022, Class B and the immunity levels are defined by EN 55024. Seagate uses an independent laboratory to confirm compliance with the EC directives specified in the previous paragraph. Drives are tested in representative end-user systems. Although CE-marked Seagate drives comply with the directives when used in the test systems, we cannot guarantee that all systems will comply with the directives. -
Page 23: Fcc Verification
As a subassembly, no Federal Communications Commission verification or certification of the device is required. Seagate Technology LLC has tested this device in enclosures as described above to ensure that the total assembly (enclosure, disc drive, motherboard, power supply, etc.) does comply with the limits for a Class B computing device, pursuant to Subpart J, Part 15 of the FCC rules. -
Page 24: Environmental Protection
Lead (Pb), in electronic products effective July 2006. A number of parts and materials in Seagate products are procured from external suppliers. We rely on the rep- resentations of our suppliers regarding the presence of RoHS substances in these parts and materials. Our... -
Page 25: Configuring And Mounting The Drive
Seagate-supplied driver. The following operating systems support the required pass-through facilities: • Windows XP, Service Pack 2 (and later) • Windows 2003 Server, Service Pack 1 (and later). This OS has not been tested by Seagate. ® Momentus 5400 FDE drives may be used as boot drives when used with these operating systems. -
Page 26: Jumper Settings
Jumper settings 3.2.1 Master/slave configuration Use the options jumper block shown in Figure 6 to configure the drive for operation. This jumper block is the 4-pin header adjacent to pins 1 and 2 of the I/O signal pins. For additional information about using the Cable select option, see Section 3.2.2. - Page 27 3.945 +/-0.010 0.490 +/- .010 (100.2 +/-.25) (12.446 +/- .254) .157 (3.9878) .399 0.673 +/- .010 (10.135) (17.09 +/- .254) Breather Hole 2.750 +/- .010 Do not cover (69.85 +/- .25) or seal. 3.567 Recommended case temp. (90.60) .551 measurement location 2X M3 X 0.5-6H (13.99) Mounting holes...
-
Page 28: Drive Integration
FDE Momentus drive with one optional exception regarding the label. M omentus 5400 FDE X X X GB This drive is manufactured by Seagate for OEM Product of Singapore distribution. For product information or technical support, please contact your system OEM. -
Page 29: Drive Installation
3.4.1 Drive installation Upon receipt by the consumer, the drive’s user interface is identical to a Momentus 5400.2 drive. The normal ATA security commands are functioning and available for initialization of the password as follows: Per normal ATA Security Commands specifications, the drive is unlocked and all ATA security commands and all normal ATA commands may be issued. -
Page 30: Drive State After Security Erase
The drive may now be disposed of safely, or the drive may be returned to service for another consumer follow- ing the initialization procedure defined above. Drives returned to Seagate for warranty purposes have special requirements. See the warranty information in Section 2.13 for additional details. -
Page 31: Ata Interface
ATA interface These drives use the industry-standard ATA task file interface that supports 16-bit data transfers. It supports ATA programmed input/output (PIO) modes 0–4 and Ultra DMA modes 0–5. The drive also supports the use of the IORDY signal to provide reliable high-speed data transfers. For detailed information about the ATA interface, refer to the draft of AT Attachment with Packet Interface Extension (ATA/ATAPI-7), NCITS T13, subsequently referred to as the Draft ATA-7 Standard. -
Page 32: Ata Interface Specifications
4.1.1 ATA interface specifications The Momentus 5400 FDE is consistent with the ATA Interface implementation of the Momentus 5400.2 prod- ucts with the known exceptions listed within this section (Section 4.1.1 subordinate sections). 4.1.1.1 Legacy mode -- Multi-word DMA not supported If multi-word DMA model is selected, the drive response is indeterminate, and the ATA bus will hang. -
Page 33: Ata Security Policy Exceptions
4.1.1.4 Device 0 only configurations Per the ATA-ATAPI-7, Rev. 4B specification, Clause 5.16.1 (see italicized excerpt below), the specification expects Device 0 to return the Task File Register when Device 1 is selected as follows: In a single device configuration where Device 0 is the only device and the host selects Device 1, Device 0 shall respond as follows: If the device does not implement the PACKET Command feature set, a read of the Control Block or Command Block registers, other than the Status or Alternate Status registers, shall complete as if Device 0 was selected. -
Page 34: Additional Technical Notes
Cryptographic Erase. 4.1.3 Additional technical notes Additional notes are available on the following web site: http://www.seagate.com/support/fde This site shows technical notes about additional new commands for FDE drives and other FDE-related infor- mation. Momentus 5400 FDE Product Manual, Rev. C... -
Page 35: Drive Trust Mode Supported
4.1.4 Drive Trust Mode supported Identify Page - Word 150 decimal (0x96h)- Bit 12 Identifies Drive Trust Support. Value = 1 = Drive Trust is supported (this is a trusted drive) Table 9: Drive Trust Identify Page Ident Value BIT set Description Vendor specific Vendor specific... -
Page 36: Full Disc Encryption Support
4.1.5 Full Disc Encryption support Identify Page--Word 243 decimal (0xF3h)--bit 14 indicates Full Disc Encryption capability. 1 = Full Disc Encryption supported. Table 10: Full-disc Encryption Identify Page Ident Value BIT set Description Vendor specific Full-disc Encryption Vendor specific Vendor specific Vendor specific Vendor specific Vendor specific... -
Page 37: Supported Ata Commands
4.1.6 Supported ATA commands The following table lists ATA-standard commands that the drive supports. For a detailed description of the ATA commands, refer to the Draft ATA-7 Standard. Table 11: Supported commands ATA Security API Drive Trust Security API Secure Authenticated Code Command... - Page 38 Table 11: Supported commands ATA Security API Drive Trust Security API Secure Authenticated Code Command Locked Unlocked Frozen State State READ MULTIPLE EXT Aborted Executable Executable Aborted Executable READ NATIVE MAX Executable Executable Executable Executable Executable ADDRESS READ NATIVE MAX Executable Executable Executable...
- Page 39 Table 11: Supported commands ATA Security API Drive Trust Security API Secure Authenticated Code Command Locked Unlocked Frozen State State / 03 SET MAX UNLOCK Aborted Executable Executable Aborted Executable SET MULTIPLE MODE Executable Executable Executable Executable Executable SLEEP Executable Executable Executable Executable...
- Page 40 Table 11: Supported commands ATA Security API Drive Trust Security API Secure Authenticated Code Command Locked Unlocked Frozen State State WRITE STREAM DMA EXT Aborted Executable Executable Aborted Executable WRITE STREAM EXT Aborted Executable Executable Aborted Executable Momentus 5400 FDE Product Manual, Rev. C...
-
Page 41: Identify Device Command
4.1.7 Identify Device command The Identify Device command (command code EC ) transfers information about the drive to the host following power up. The data is organized as a single 512-byte block of data. All reserved bits or words should be set to zero. - Page 42 Advanced power management value 8080 Master password revision code FFFE Hardware reset value (see description following this table) xxxx Auto acoustic management setting xxxx 95–127 ATA-reserved 0000 Security status 0001 129–149 Seagate-reserved xxxx Momentus 5400 FDE Product Manual, Rev. C...
- Page 43 Word Description Value Drive Trust Identify 5098 151–159 Seagate-reserved xxxx 160–242 ATA-reserved 0000 Disk Encryption Supported 4000 244–254 ATA-reserved 0000 Integrity word xxA5 Note. See the bit descriptions below for words 63, 88, 93 and 94 of the Identify Drive data.
-
Page 44: Set Features Command
4.1.8 Set Features command This command controls the implementation of various features that the drive supports. When the drive receives this command, it sets BSY, checks the contents of the Features register, clears BSY and generates an inter- rupt. If the value in the register does not represent a feature that the drive supports, the command is aborted. Power-on default has the read look-ahead and write caching features enabled. -
Page 45: Compatibility Summary
Special training or tools may be needed to service some mobile computers. In some cases, opening the case may void your warranty. Consult your system documentation. Seagate recommends taking your system to an authorized service technician to replace your hard drive. -
Page 46: Bios Versions Tested
HP D530 USDT BIOS versions tested The following list indicates the types of BIOS Seagate tested during the compatibility testing process. The list highlights the major BIOS manufacturers. Individual systems contain variations of these BIOS versions and were tested with regard to their implementation in the individual systems. -
Page 47: Operating System Versions Tested
Notes exceptions to the specifications for the Momentus 5400 FDE are listed in the ATA Interface Section above. Software utilities The following is a brief overview of a some of the Seagate utilities used during the Seagate competitive analy- sis process. The Seagate SeaTools application is an exclusive disc drive diagnostic software designed to troubleshoot most hard drive issues. -
Page 48: Third Party Software Support
5.5.1 Third party software support Seagate does not supply password management software. Third party software support for security features is available. For the latest list of available software, please refer to the following web site: http://www.seagate.com/support/fde Momentus 5400 FDE Product Manual, Rev. C... -
Page 49: Seagate Technology Support Services
Seagate Service Centers Presales Support Our Presales Support staff can help you determine which Seagate products are best suited for your specific application or computer system, as well as product availability and compatibility. Technical Support Seagate technical support is available to assist you online at support.seagate.com... - Page 50 Seagate Customer Service Operations (CSO) representative for warranty- related issues. Resellers or end users of drive products should contact their place of purchase or Seagate warranty service for assistance. Have your serial number and model or part number available.
