Summary of Contents for Seagate Cheetah 15K.7 SAS Series
- Page 1 Product Manual Cheetah 15K.7 SAS Standard models Self-Encrypting Drive models ST3600057SS ST3600957SS ST3450857SS ST3450757SS ST3300657SS ST3300557SS SED FIPS 140-2 models ST3600857SS ST3450657SS ST3300457SS 100516226 Rev. E July 2011...
- Page 2 NIST, the U.S., or Canadian governments. All other trademarks or registered trademarks are the property of their respective owners. No part of this publication may be reproduced in any form without written permission of Seagate Technology LLC. Call 877-PUB-TEK1 (877-782-8351) to request permission.
-
Page 3: Table Of Contents
Seagate Technology support services ........ - Page 4 7.4.1 Temperature ........... . 29 7.4.2 Relative humidity .
- Page 5 12.4.7 Power ............63 12.5 Signal characteristics.
- Page 6 Cheetah 15K.7 SAS Product Manual, Rev. E...
-
Page 7: Seagate Technology Support Services
Authorized Service Centers For information regarding Warranty Support, visit http://www.seagate.com/www/en-us/support/warranty_&_returns_assistance For information regarding Data Recovery Services, visit http://www.i365.com For Seagate OEM & Distribution partner portal, visit https://direct.seagate.com/portal/system For Seagate reseller portal, visit http://spp.seagate.com Cheetah 15K.7 SAS Product Manual, Rev. E... -
Page 8: Scope
Cheetah 15K.7 drives support the SAS Protocol specifications to the extent described in this manual. The SAS Interface Manual (part number 100293071) describes the general SAS characteristics of Cheetah 15K.7 and other Seagate SAS drives. The Self-Encrypting Drive (SED) Users Guide, part number 100515636 describes the interface, general operation and security features available on SED drives. -
Page 9: Standards, Compliance And Reference Documents
Section 11.3. Standards The Cheetah 15K.7 SAS family complies with Seagate standards as noted in the appropriate sections of this manual and the Seagate SAS Interface Manual, part number 100293071. The drives are recognized in accordance with UL 60950-1 and CSA 60950-1 as tested by UL and EN60950-1 as tested by TUV. -
Page 10: Compliance
Lead (Pb), in electronic products effective July 2006. A number of parts and materials in Seagate products are procured from external suppliers. We rely on the rep- resentations of our suppliers regarding the presence of RoHS substances in these parts and materials. Our... -
Page 11: Reference Documents
Seagate also has internal systems in place to ensure ongoing compliance with the RoHS Directive and all laws and regulations which restrict chemical content in electronic products. These systems include standard operat- ing procedures that ensure that restricted substances are not utilized in our manufacturing operations, labora- tory analytical validation testing, and an internal auditing process to ensure that all standard operating procedures are complied with. -
Page 12: General Description
General description Cheetah 15K.7 drives provide high performance, high capacity data storage for a variety of systems including engineering workstations, network servers, mainframes, and supercomputers. The Serial Attached SCSI inter- face is designed to meet next-generation computing demands for performance, scalability, flexibility and high- density storage requirements. -
Page 13: Standard Features
Standard features Cheetah 15K.7 drives have the following standard features: • 1.5 / 3 / 6 Gbit Serial Attached SCSI (SAS) interface • Integrated dual port SAS controller supporting the SCSI protocol • Support for SAS expanders and fanout adapters •... -
Page 14: Reliability
Seagate designs specify capacity points at certain block sizes that Seagate guarantees current and future products will meet. We recommend customers use this capacity in their project planning, as it ensures a stable operating point with backward and forward compatibility from generation to generation. -
Page 15: Performance Characteristics
Performance characteristics This section provides detailed information concerning performance-related characteristics and features of Cheetah 15K.7 drives. Internal drive characteristics ST3600057SS ST3450857SS ST3300657SS ST3600957SS ST3450757SS ST3300557SS ST3600857SS ST3450657SS ST3300457SS Drive capacity Gbytes (formatted, rounded off value) Read/write data heads Tracks per inch 165,000 165,000 165,000... -
Page 16: Format Command Execution Time (Minutes)
5.2.2 Format command execution time (minutes) When changing sector sizes, the format times shown below may need to be increased by 30 minutes. 600GB 450GB 300GB Maximum (with verify) Maximum (without verify) Note. There is approximately a 1.5 increase in time to format a SED drive versus a non-SED drive of the same capacity. Execution time measured from receipt of the last byte of the Command Descriptor Block (CDB) to the request for a Status Byte Transfer to the Initiator (excluding connect/disconnect). -
Page 17: Prefetch/Multi-Segmented Cache Control
If the drive receives a START STOP UNIT command with the START bit and IMMED bit equal to 1 and does not receive a NOTIFY (ENABLE SPINUP) primitive within 5 seconds, the drive fails the START STOP UNIT command. The START STOP UNIT command may be used to command the drive to stop the spindle. Stop time is 30 sec- onds (maximum) from removal of DC power. -
Page 18: Caching Write Data
5.5.1 Caching write data Write caching is a write operation by the drive that makes use of a drive buffer storage area where the data to be written to the medium is stored while the drive performs the Write command. If read caching is enabled (RCD=0), then data written to the medium is retained in the cache to be made avail- able for future read cache hits. -
Page 19: Reliability Specifications
Reliability specifications The following reliability specifications assume correct host and drive operational interface, including all inter- face timings, power supply voltages, environmental requirements and drive mounting constraints. Seek error rate: Less than 10 errors in 10 seeks Read Error Rates Recovered Data Less than 10 errors in 10 bits transferred (OEM default settings) -
Page 20: Seek Errors
6.1.3 Seek errors A seek error is defined as a failure of the drive to position the heads to the addressed track. After detecting an initial seek error, the drive automatically performs an error recovery process. If the error recovery process fails, a seek positioning error (Error code = 15h or 02h) will be reported with a Hardware error (04h) in the Sense Key. -
Page 21: S.m.a.r.t
6.2.4 S.M.A.R.T. S.M.A.R.T. is an acronym for Self-Monitoring Analysis and Reporting Technology. This technology is intended to recognize conditions that indicate imminent drive failure and is designed to provide sufficient warning of a failure to allow you to back up the data before an actual failure occurs. Note. -
Page 22: Thermal Monitor
Reporting control Reporting is controlled by the MRIE bits in the Informational Exceptions Control mode page (1Ch). Subject to the reporting method, the firmware will issue to the host an 01-5Dxx sense code. The error code is preserved through bus resets and power cycles. Determining rate S.M.A.R.T. -
Page 23: Drive Self Test (Dst)
DST. It is the responsibility of the host application to determine the “not ready” cause. While not technically part of DST, a Not Ready condition also qualifies the drive to be returned to Seagate as a failed drive. - Page 24 • Motor will not spin • Motor will not lock to speed • Servo will not lock on track • Drive cannot read configuration tables from the disk In these conditions, the drive responds to a Test Unit Ready command with an 02/04/00 or 02/04/03 code. 6.2.6.2.2 Invoking DST To invoke DST, submit the Send Diagnostic command with the appropriate Function Code (001b for the short...
-
Page 25: Product Warranty
Seagate’s option and at no charge to the customer, if returned by customer at customer’s expense to Seagate’s designated facility in accordance with Seagate’s warranty procedure. -
Page 26: Physical/Electrical Specifications
Physical/electrical specifications This section provides information relating to the physical and electrical characteristics of the drive. AC power requirements None. DC power requirements The voltage and current requirements for a single drive are shown below. Values indicated apply at the drive connector. - Page 27 Table 14: DC power requirements 600 GB 3 Gbit mode 6 Gbit mode Notes (Amps) (Amps) (Amps) (Amps) Voltage +12V [2] +12V [2] Regulation ±5% ±5% [2] ±5% ±5% [2] Avg idle current [1] [7] 0.37 0.81 0.38 0.81 Maximum starting current (peak DC) DC 3σ...
- Page 28 Table 15: DC power requirements 450 GB 3 Gbit mode 6 Gbit mode Notes (Amps) (Amps) (Amps) (Amps) Voltage +12V [2] +12V [2] Regulation ±5% ±5% [2] ±5% ±5% [2] Avg idle current [1] [7] 0.39 0.68 0.41 0.66 Maximum starting current (peak DC) DC 3σ...
- Page 29 Table 16: DC power requirements 300 GB 3 Gbit mode 6 Gbit mode Notes (Amps) (Amps) (Amps) (Amps) Voltage +12V [2] +12V [2] Regulation ±5% ±5% [2] ±5% ±5% [2] Avg idle current [1] [7] 0.34 0.58 0.35 0.58 Maximum starting current (peak DC) DC 3σ...
-
Page 30: Conducted Noise Immunity
Operating condition is defined as random 8 block reads at 375 I/Os per second for 600GB models, and 380 I/Os per second for 450GB and 300GB models. Current and power specified at nominal voltages. During idle, the drive heads are relocated every 60 seconds to a random location within the band from three-quarters to maximum track. - Page 31 Figure 1. Typical 600GB current profiles Figure 2. Typical 450GB current profiles Cheetah 15K.7 SAS Product Manual, Rev. E...
- Page 32 Figure 3. Typical 300GB current profiles Cheetah 15K.7 SAS Product Manual, Rev. E...
-
Page 33: Power Dissipation
Power dissipation model 600GB Typical power dissipation under idle conditions in 6Gb operation is 11.62 watts (39.65 BTUs per hour). To obtain operating power for typical random read operations, refer to the following I/O rate curve (see Figure 4). Locate the typical I/O rate for a drive in your system on the horizontal axis and read the corresponding +5 volt current, +12 volt current, and total watts on the vertical axis. - Page 34 model 450GB Typical power dissipation under idle conditions in 6Gb operation is 9.97 watts (34.02 BTUs per hour). To obtain operating power for typical random read operations, refer to the following I/O rate curve (see Figure 4). Locate the typical I/O rate for a drive in your system on the horizontal axis and read the corresponding +5 volt current, +12 volt current, and total watts on the vertical axis.
-
Page 35: Environmental Limits
300GB model Typical power dissipation under idle conditions in 6Gb operation is 8.71 watts (29.72 BTUs per hour). To obtain operating power for typical random read operations, refer to the following I/O rate curve (see Figure 4). Locate the typical I/O rate for a drive in your system on the horizontal axis and read the corresponding +5 volt current, +12 volt current, and total watts on the vertical axis. -
Page 36: Relative Humidity
Non-operating –40° to 158°F (–40° to 70°C) package ambient with a maximum gradient of 86°F (30°C) per hour. This specification assumes that the drive is packaged in the shipping container designed by Seagate for use with drive. HDA Temp. - Page 37 36 in (914 mm) Drives packaged in single or multipacks with a gross weight of 20 pounds (8.95 kg) or less by Seagate for general freight shipment shall withstand a drop test from 48 inches (1,070 mm) against a concrete floor or equivalent.
- Page 38 Figure 8. Recommended mounting 7.4.4.2 Vibration a. Operating—normal The drive as installed for normal operation, shall comply with the complete specified performance while subjected to continuous vibration not exceeding 10 – 300 Hz 1.0 G RMS (0 to peak) 301– 500 Hz 0.5 G RMS (0 to peak) Vibration may be applied in the X, Y, or Z axis.
-
Page 39: Acoustics
There will not be any discrete tones more than 10 dB above the masking noise on typical drives when mea- sured according to Seagate specification 30553-001. There will not be any tones more than 24 dB above the masking noise on any drive. -
Page 40: Electromagnetic Susceptibility
7.4.9 Electromagnetic susceptibility See Section 3.1.1.1. Mechanical specifications Refer to Figure 9 for detailed physical dimensions. See Section 11.3, “Drive mounting.” Height: 1.03 in 26.10 mm Width: 4.00 in 101.60 mm Depth: 5.79 in 147 mm Weight (max): 1.76 pounds 0.80 kilograms 26.11 MAX 2X 20.14... -
Page 41: About Fips
FIPS 140-2 Level 2 requirements. In order to operate in FIPS Approved Mode of Operation, these SEDs require security initialization. For more information, refer to 'Security Rules' section in the 'Security Policy' document uploaded on the NIST website - Cert# 1299: Seagate Secure® Enterprise Self-Encrypting Drives FIPS 140 Module: http://csrc.nist.gov/groups/STM/cmvp/documents/140-1/140val-all.htm... - Page 42 Figure 10. Example of FIPS tamper evidence labels. Note. Image is for reference only, may not represent actual drive.. Cheetah 15K.7 SAS Product Manual, Rev. E...
-
Page 43: About Self-Encrypting Drives
(TCG) Enterprise Storage Specifications as detailed in Section 3.4. The Trusted Computing Group (TCG) is an organization sponsored and operated by companies in the com- puter, storage and digital communications industry. Seagate’s SED models comply with the standards pub- lished by the TCG. -
Page 44: Default Password
Authenticated firmware download In addition to providing a locking mechanism to prevent unwanted firmware download attempts, the drive also only accepts download files which have been cryptographically signed by the appropriate Seagate Design Center. Three conditions must be met before the drive will allow the download operation: 1. -
Page 45: Power Requirements
2. The download file must be signed and authenticated. 3. As with a non-SED drive, the download file must pass the acceptance criteria for the drive. For example it must be applicable to the correct drive model, and have compatible revision and customer status. Power requirements The standard drive models and the SED drive models have identical hardware, however the security and encryption portion of the drive controller ASIC is enabled and functional in the SED models. -
Page 46: Defect And Error Management
10.0 Defect and error management Seagate continues to use innovative technologies to manage defects and errors. These technologies are designed to increase data integrity, perform drive self-maintenance, and validate proper drive operation. SCSI defect and error management involves drive internal defect/error management and SAS system error considerations (errors in communications between the initiator and the drive). - Page 47 Table 17 equates the read and write retry count with the maximum possible recovery time for read and write recovery of individual LBAs. The times given do not include time taken to perform reallocations. Reallocations are performed when the ARRE bit (for reads) or AWRE bit (for writes) is one, the RC bit is zero, and the recov- ery time limit for the command has not yet been met.
-
Page 48: Sas System Errors
Table 17: Read and write retry count maximum recovery times [1] Read retry Maximum recovery time per LBA Write retry Maximum recovery time per LBA count (cumulative, msec) count (cumulative, msec) 51.87 23.94 59.85 35.91 203.49 39.9 231.42 51.87 295.26 79.8 327.18 5 (default) -
Page 49: Media Pre-Scan
DAR is most effective when AWRE and ARRE are enabled—this is the default setting from the Seagate factory. With AWRE and ARRE disabled DAR is unable to reallocate the failing location and will report an error sense code indicating that a write command is being attempted to a previously failing location. -
Page 50: Installation
11.0 Installation Cheetah 15K.7 disk drive installation is a plug-and-play process. There are no jumpers, switches, or termina- tors on the drive. SAS drives are designed to be used in a host system that provides a SAS-compatible backplane with bays designed to accommodate the drive. -
Page 51: Drive Mounting
If forced air is determined to be necessary, possible air-flow patterns are shown in Figure 11. The air-flow pat- terns are created by one or more fans, either forcing or drawing air as shown in the illustrations. Conduction, convection, or other forced air-flow patterns are acceptable as long as the temperature measurement guide- lines of Section 7.4.1 are met. -
Page 52: Interface Requirements
12.0 Interface requirements This section partially describes the interface requirements as implemented on Cheetah 15K.7 drives. Addi- tional information is provided in the SAS Interface Manual (part number 100293071). 12.1 SAS features This section lists the SAS-specific features supported by Cheetah 15K.7 drives. 12.1.1 task management functions Table 18 lists the SAS task management functions supported. -
Page 53: Dual Port Support
12.2 Dual port support Cheetah 15K.7 SAS drives have two independent ports. These ports may be connected in the same or differ- ent SCSI domains. Each drive port has a unique SAS address. The two ports have the capability of independent port clocking (e.g. both ports can run at 6Gbit/sec or the first port can run at 6Gbit/sec while the second port runs at 3Gbit/sec.) The supported link rates are 1.5, 3.0, or 6.0 Gbits/sec. - Page 54 Table 20: Commands supported by Cheetah 15K.7 SAS family drives (continued) Command name Command code Supported TSD bit ETC bit TMC bit LP bit Log Sense Application Client Log page (0Fh) Buffer Over-run/Under-run page (01h) Cache Statistics page (37h) Factory Log page (3Eh) Last n Deferred Errors or Asynchronous Events page (0Bh) Last n Error Events page (07h) Non-medium Error page (06h)
- Page 55 Table 20: Commands supported by Cheetah 15K.7 SAS family drives (continued) Command name Command code Supported Mode Sense (10) (same pages as Mode Sense 1Ah) Prefetch Read Read Buffer (modes 0, 2, 3, Ah and Bh supported) Read Capacity Read Defect Data (10) Read Defect Data (12) Read Extended DPO bit supported...
- Page 56 Table 20: Commands supported by Cheetah 15K.7 SAS family drives (continued) Command name Command code Supported Test Unit Ready Verify BYTCHK bit Write Write and Verify DPO bit Write Buffer (modes 0, 2, supported) Firmware Download option (modes 5, 7, Ah and Bh supported) [3] Write Extended DPO bit FUA bit...
-
Page 57: Inquiry Data
12.3.1 Inquiry data Table lists the Inquiry command data that the drive should return to the initiator per the format given in the SAS Interface Manual. Table 21: Cheetah 15K.7 inquiry data Bytes Data (hex) 0-15 xx** Vendor ID 16-31 Product ID 32-47 48-63... -
Page 58: Mode Sense Data
12.3.2 Mode Sense data The Mode Sense command provides a way for the drive to report its operating parameters to the initiator. The drive maintains four sets of mode parameters: 1. Default values Default values are hard-coded in the drive firmware stored in flash E-PROM (nonvolatile memory) on the drive’s PCB. - Page 59 12.3.2.1 600GBmodel Mode Sense data MODE DATA HEADER: 01 6e 00 10 00 00 00 08 BLOCK DESCRIPTOR: 45 dd 2f b0 00 00 02 00 MODE PAGES: 81 0a c0 0b ff 00 00 00 05 00 ff ff 81 0a ff ff 00 00 00 00 ff 00 ff ff 82 0e 00 00 00 00 00 00 00 00 01 3a 00 00 00 00 82 0e 00 00 00 00 00 00 00 00 ff ff 00 00 00 00...
- Page 60 9a 0a 00 03 ff ff ff ff ff ff ff ff 9c 0a 10 00 00 00 00 00 00 00 00 01 9c 0a 9d 0f ff ff ff ff ff ff ff ff dc 01 00 0c 01 01 00 18 00 18 00 00 00 00 00 00 dc 01 00 0c 00 01 ff ff ff ff 00 00 00 00 00 00 80 06 00 80 0f 00 00 00 80 06 b7 c0 8f 00 00 00...
- Page 61 12.3.2.2 450GB model Mode Sense data MODE DATA HEADER: 01 76 00 10 00 00 00 08 BLOCK DESCRIPTOR: 34 65 f8 70 00 00 02 00 MODE PAGES: 81 0a c0 0b ff 00 00 00 05 00 ff ff 81 0a ff ff 00 00 00 00 ff 00 ff ff 82 0e 00 00 00 00 00 00 00 00 01 3a 00 00 00 00 82 0e 00 00 00 00 00 00 00 00 ff ff 00 00 00 00...
- Page 62 9c 0a 10 00 00 00 00 00 00 00 00 01 9c 0a 9d 0f ff ff ff ff ff ff ff ff dc 01 00 0c 01 01 00 18 00 18 00 00 00 00 00 00 dc 01 00 0c 00 01 ff ff ff ff 00 00 00 00 00 00 80 06 00 80 0f 00 00 00 80 06 b7 c0 8f 00 00 00...
- Page 63 12.3.2.3 300GB model Mode Sense data MODE DATA HEADER: 01 76 00 10 00 00 00 08 BLOCK DESCRIPTOR: 22 ec b2 5c 00 00 02 00 MODE PAGES: 81 0a c0 0b ff 00 00 00 05 00 ff ff 81 0a ff ff 00 00 00 00 ff 00 ff ff 82 0e 00 00 00 00 00 00 00 00 01 3a 00 00 00 00 82 0e 00 00 00 00 00 00 00 00 ff ff 00 00 00 00...
-
Page 64: Miscellaneous Operating Features And Conditions
9a 0a 00 02 00 00 00 05 00 00 8c a0 9a 0a 00 03 ff ff ff ff 00 00 00 00 9c 0a 10 00 00 00 00 00 00 00 00 01 9c 0a 9d 0f ff ff ff ff ff ff ff ff dc 01 00 0c 01 01 00 18 00 18 00 00 00 00 00 00 dc 01 00 0c 00 01 ff ff ff ff 00 00 00 00 00 00 80 06 00 80 0f 00 00 00... -
Page 65: Sas Physical Interface
Figure 12 shows the location of the SAS device connector J1. Figures 13 and 14 provide the dimensions of the SAS device. Details of the physical, electrical, and logical characteristics are provided within this section. The operational aspects of Seagate’s SAS drives are provided in the SAS Interface Manual.. SAS Interface connector Figure 12. - Page 66 0.80 (6X) 5.92 7.62 4.65 0.52 0.08 x 45 2.00 (3X) 0.45 0.03 (7X) 5.08 0.10 M E 42.73 REF. 41.13 0.15 0.20 B 0.30 0.05 (2X) 1.10 4.00 0.08 C OF DATUM D 0.15 D R0.30 0.08 (4X) 0.30 0.05 (4X) SEE Detail1 33.43...
-
Page 67: Physical Characteristics
Detail A 6.10 0.30 0.05 x 45 (5X) 2.25 0.05 0.40 0.05 X 45 (3X) 4.85 0.05 0.10 B CORING ALLOWED IN THIS AREA. 4.40 0.15 R0.30 0.08 SEE Detail 2 1.95 0.08 0.35 0.05 SECTION C - C 3.90 0.15 SECTION A - A CONTACT SURFACE FLUSH... -
Page 68: Electrical Description
12.4.4 Electrical description SAS drives use the device connector for: • DC power • SAS interface • Activity LED This connector is designed to either plug directly into a backpanel or accept cables. 12.4.5 Pin descriptions This section provides a pin-out of the SAS device and a description of the functions provided by the pins. Table 24: SAS pin descriptions Signal name... -
Page 69: Sas Transmitters And Receivers
12.4.6 SAS transmitters and receivers A typical SAS differential copper transmitter and receiver pair is shown in Figure 15. The receiver is AC cou- pling to eliminate ground shift noise. Differential Transmitter Receiver Transfer Medium Figure 15. SAS transmitters and receivers 12.4.7 Power The drive receives power (+5 volts and +12 volts) through the SAS device connector. -
Page 70: Differential Signals
For more information about the Phy, Link, Transport, and Applications layers of the SAS interface, refer to the Seagate SAS Interface Manual, part number 100293071. For more information about the SCSI commands used by Seagate SAS drives, refer to the Seagate SCSI Commands Reference Manual, part number 100293068. - Page 71 Index cache segments 11 caching write data 12 Canadian Department of Communications 3 Numerics capacity unformatted 9 12 volt CBC 37 pins 63 check condition status 59 5 volt pins 63 chemical pollutants 33 6 Gbps 64 Cipher Block Chaining 37 class B limit 3 clear ACA function 46 clear task set function 46...
- Page 72 drive mounting 34 heads drive select 62 read/write data 9 dual port support 47 heat removal 44 heat source 44 host equipment 45 hot plugging the drive 14 electrical humidity 30 description of connector 62 humidity limits 29 signal characteristics 63 specifications 20 electromagnetic compatibility 3 electromagnetic susceptibility 34...
- Page 73 Queue tagging 58 performance highlights 7 Reporting actual retry count 58 physical damage 33 Segmented caching 58 physical dimensions 34 SMP = 1 in Mode Select command 58 physical interface 59 Synchronized (locked) spindle operation 58 physical specifications 20 Zero latency read 58 pin descriptions 62 miscellaneous status support power 63...
- Page 74 Secure ID 37 temperature 29 security partitions 37 limits 29 Security Protocol In 37 non-operating 30 Security Protocol Out 37 regulation 3 seek error See also cooling defined 14 terminate task function 46 rate 13 terminators 44 seek performance characteristics 9 tracks per inch 9 seek time transmitters 63...
