INSTRUCTION MANUAL MS-MBA-3-T4A2

TABLE OF CONTENTS:

1.00
1.10
Plan View Resultant Beam Layout
1.20
1.30
1.40
2.00
2.10
2.20
3.00
4.00
4.10
Bolts & Nuts Requirements
4.11
4.12
4.20
4.21
Adjustable Spanner
4.22
4.30
Bracket Spacing & Installation Sample
Revision History:
Date
email:
info@matsing.com
MS-MBA-3-T4A2
Date
Prepared by
Ray Ling
Description
website:
www.matsing.com
Instruction Manual
Approved by
Document nos
Pavel
MBA-3-T4A2-001
Rev
Revision
Revised by
nos.
Page
1
/
0
5

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MS-MBA-3-T4A2 and is the answer not in the manual?

Questions and answers

Related Manuals for Matsing MS-MBA-3-T4A2

Summary of Contents for Matsing MS-MBA-3-T4A2

  • Page 1 MS-MBA-3-T4A2 Instruction Manual Date Prepared by Approved by Document nos 19 Sep 2023 Ray Ling Pavel MBA-3-T4A2-001 INSTRUCTION MANUAL MS-MBA-3-T4A2 TABLE OF CONTENTS: 1.00 BEAMS & CONNECTORS: 1.10 Plan View Resultant Beam Layout 1.20 Connector Port Table 1.30 Connector Detail 1.40...
  • Page 2 (+45˚) (+45˚) (+45˚) Port 10 Port 6 Port 2 (-45˚) (-45˚) (-45˚) 1.40 Connector Layout MS-MBA-3-T4A2 REAR VIEW CONNECTOR LAYOUT BEAM 2 1.30 Connector Detail BEAM 3 BEAM 2 BEAM 1 AISG IN AISG IN-1 AISG IN-2 TB Beam: 3...
  • Page 3 2.00 PATTERN DIAGRAM 2.10 Horizontal Pattern Frequency: MS-MBA-3-T4A2 617 - 896 MHz 2.20 Vertical Pattern MS-MBA-3-T4A2 Frequency: 617 - 896 MHz Page...
  • Page 4 3.00 MANUAL TILT ADJUSTMENT The MBA antenna come in RET mode as default, but if needed can also be manually adjusted. To do so, please unscrew the waterproof cap behind the element whose tilt is to be adjusted. By Default the knob is on engaged mode, pull out the handle for manual tilt adjustment, turn the handle to change the tilt.
  • Page 5 4.00 BRACKET INSTALLATION 4.10 Bolts & Nuts Requirements 4.11 Bolts & Nuts Bracket Bolts Nuts Size Size M12 x 200mm 4.12 Bracket R76.0mm R76.0mm 4.20 Tools Requirement 4.21 Adjustable Spanner 4.22 M12 Spanner 4.30 Bracket Spacing & Installation Sample 185mm Page...
