S1682D-001-02
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TAHOE 2 ATX and is the answer not in the manual?

Questions and answers

Related Manuals for TYAN TAHOE 2 ATX

Summary of Contents for TYAN TAHOE 2 ATX

  • Page 1 S1682D-001-02...

  • Page 2: Table Of Contents

    4. T roubleshooting............... 24 4.1 Troubleshooting procedures........4.2 Technical Support procedures....... 26 4.3 Returning merchandise for service....... Appendix: LM78 System Hardware Monitor and Intel LANDesk® Client/Server Manager software LDCM..27 Declaration of Conformity..........28 BIOS - Speaker beep codes..........29 S1682D-001-02 http://www.tyan.com...

  • Page 3: Introduction

    Please refer to Tyan Computer's web site located at http://www.tyan.com for more information about your S1682 D board. Here you will also find information on all of Tyan's products along with FAQ's, distributors, drivers and CMOS setting explanations.

  • Page 4: Hardware Specifications

    • PIO Mode 3 & 4 (up to 17MB/sec DTR) • Support for up to 1GB (1024MB) of memory • 2 USB headers (use with optional bracket : Tyan PN# S1606-001-01) Rev. 1.2 compliant System RAM • Eight-72 pin SIMMs (4 double banks) •...

  • Page 5: Software Specifications

    Operating System • Operates with MS-DOS, Windows 3.x, Win dows for Workgroups 3.x, Windows 95, Windows NT • OS/2, Novell Netware, and SCO Unix, Linux. Tyan is also a Solaris certified manufacturer. 1.4 Environment Operating Temperature to +55 Humidity <80% @36C...

  • Page 6: Manual Conventions

    CMOS errors. Both AMI and Award BIOS Setup documents are also available in the Adobe Acrobat format. Please refer to the Web Page located at ftp://ftp.tyan.com/ s1682da.pdf for AMI and ftp://ftp.tyan.com/s1682db.pdf for Award BIOS information.
  • Page 7 Pentium II Boxed (Active) CPU Shown with Power Connector for Fan Pentium II (Passive) CPU Shown with Heatsink S1682D-001-02...

  • Page 8: Board Installation

    2.2 Installation of the motherboard You are now ready to install your motherboard. The mounting hole pattern of the S1682D matches the ATX system board specifications. Please install the board in the chassis designed for a standard ATX form factor board. S1682D-001-02 http://www.tyan.com...

  • Page 9: S1682D Board Layout & Jumper Locations

    Primary PCI Slot 4 PIIX3 Secondary IDE PCI Slot 5 ISA Slot 1 ISA Slot 2 APIC ISA Slot 3 CHSFAN (For more information about this mainboard, please visit our W eb Page and Clickable motherboards at http://www.tyan.com /html/faq.html.) S1682D-001-02...
  • Page 10 Pins13-16:HDD LED, Pins18-20:Power LED Pins22,23:Reset, Pins24-27: Speaker J30, J36 I/O Select J31-34 CPU Speed Settings Super I/O Clock Select (*Do not Change) CMOS Reset P12,17 BIOS EEPROM Voltage (*Do not Change) J1-J5,J9,J35, Reserved J38,J45-55,J57 Block J29 Pin Assignments S1682D-001-02 http://www.tyan.com...
  • Page 11 2.3.3 Jumper Settings CPU Speed Settings for Pentium II and Pentium Pro Processors: MHz J31 open close close close open open open close close close close open close open close close open open close open close close close open open open close close...
  • Page 12 BIOS EEPROM V oltage (Set at factory--DO NOT change!!) 5V (*default) Close Open Open Close *Default W ake on LAN connector: JP1 Pin# Signal SB 5V Ground W ake up LAN Reserved Jumpers: J1-J5,J9, J35, J38, J42-43, J45-55, J57 S1682D-001-02 http://www.tyan.com...
  • Page 13 Connectors: Block J29: (Refer to Page 10 for more information.) Pin# Signal 1 & 2 Power On 6-11 Infra Red 13-16 HDD LED 18-20 Power LED 22 & 23 Reset 24-27 Speaker J21/J22: Universal Serial Bus Ports (J21: USB2, J22: USB1) CON 5: FDD CON CON 6: Primary IDE CON 7: Secondary IDE...
  • Page 14 (Refer to Page 10 for more information.) HDD LED: J29 pins13-16 Signal HD Active# HD_PWR (Refer to Page 10 for more information.) Infra Red Interface: J29 pins 6-11 Signal IR in Ground IR out (Refer to Page 10 for more information.) S1682D-001-02 http://www.tyan.com...

  • Page 15: Cmos Rtc

    Register for the system. Normally, the life span of a RTC internal battery is more than 10 years. This RTC chip cannot be field upgraded and can only be changed at a Tyan repairing facility. 2.5 Installing Cables and Connectors 2.5.1 Speaker Connector Installation (J29)
  • Page 16 However, we do not recommend that you flash the onboard BIOS. This procedure should only be done by a qualified technician or a Tyan technical support engineer. J56 determines which type of Flash EPROM is used. This jumper has been set to match the onboard BIOS chip.

  • Page 17: Dram Installation

    2.6 DRAM Installation The S1682D uses a 64-bit data path from memory to the CPU which will accommodate up to 512MB of RAM. The motherboard supports FPM (Fast Page Mode), EDO (Extended Data Out), ECC (Error Correcting Code), and Parity 72-pin SIMMs. The following table shows some of the available memory configurations.

  • Page 18: L2 Cache Memory/Sram Memory

    PCI-Bus slots will support either a Master or a Slave device. 2.10 Connecting the Power Supply and On/Off Switch The system is configured for a standard ATX power supply. The ATX connectors can only be plugged in one way and should install easily. S1682D-001-02 http://www.tyan.com...

  • Page 19: Cpu Installation And Removal

    Chapter 3: CPU Installation and Removal Pentium II (233 through 300MHz) and Pentium Pro Processors (150 through 200 MHz) can be used on the S1682D. Please refer to section 2.3 for the correct CPU jumper settings for your board. Although the S1682D motherboard is designed as a dual CPU system, it will also function with a single CPU.

  • Page 20: Installing Cpu Cooling Fans

    Make sure that the black wire of the cable is plugged into Pin 1 of the connector. (Refer to Pin 1 marked on the layout on P10.) (Pin Assignments: Pin 1: ground--black, Pin 2: 12 V--red, Pin 3: Signal--yellow.) S1682D-001-02 http://www.tyan.com...

  • Page 21: Installing Pentium Ii Passive Processors

    3.4 Installation and Removal of Pentium II Passive Processors (Unlike Active Processors, Passive Processors are not equipped with cooling fans. Passive Processors are equipped with heat sinks instead.) Each CPU package should also contain the following: CPU Retention Module (x1) Heat-sink Retention Bracket with mounting locks (x1) Mounting Attach-mounts (x 2)
  • Page 22 CPU, the motherboard, and/or the CPU socket. 2. Slowly press down on the CPU module until the CPU locks into place. A clicking noise will be heard when the CPU is locked securely into the module. S1682D-001-02 http://www.tyan.com...
  • Page 23 3.4.4 Installing Heat-sink Locks The heat-sink lock has 4 notches which will correspond to the 4 pins on the heat-sink mounting bracket. Gently slide the lock between the heat- sink onto the heat-sink mounting bracket until both sides of the lock are firmly secured.

  • Page 24: T Roubleshooting

    1. Check to determine if SIMM modules are improperly installed. 2. Make sure that different types of SIMMs have not been installed in the same bank. (eg. a mixture of 265KB x 9 and 1 MB x 9) S1682D-001-02 http://www.tyan.com...
  • Page 25 3. Determine if different speeds of SIMMs have been installed in the same or different banks, and the BIOS setup is configured for the slowest speed of RAM used. It is recommended to use the same RAM speed for SIMMs in different banks. 4.

  • Page 26: Technical Support Procedures

    Be sure to go through the "Troubleshooting Procedures" section in this Chapter, and visit our Web site for additional information before calling Technical Support. (Tyan's Web Site address is: http://www.tyan.com.) If the problem is still not resolved, have the following information ready before you call for technical support: 1.

  • Page 27: Appendix: Lm78 System Hardware Monitor And Intel Landesk® Client/Server Manager Software Ldcm

    S1682D Board. Thus, by implementing both National Semiconductor's LM78 and LDCM in the S1682D system, Tyan provides you with the best quality board possible on the market. For more information, please refer to the W eb Page at: http://www.tyan.com...

  • Page 28: Declaration Of Conformity

    T rademarks Award BIOS/Flash are trademarks of Award Software International Inc. AMI BIOS is a trademarks of American Megatrends Inc. IBM,PC,AT,PS/2 are trademarks of IBM Corporation INTEL,Pentium are trademarks of Intel Corporation. S1682D-001-02 http://www.tyan.com...

  • Page 29: Bios - Speaker Beep Codes

    Chapter 6: Speaker Beep codes All Tyan motherboards come with a BIOS feature called "beep codes". What these do is inform you (the user) about potential problems in your configu- ration. These errors can occur during POST (Power On Self Test), which is performed every time the system is powered on.
