Launch SMARTLINK C V2.0 Manual

LAUNCH
Copyright Information
Copyright © 2022 by LAUNCH TECH CO., LTD. All rights reserved. No part of this publication may be
reproduced, stored in a retrieval system, or transmitted in any form or by any means, electronic,
mechanical, photocopying, recording or otherwise, without the prior written permission of LAUNCH.
The information contained herein is designed only for the use of this unit. LAUNCH is not responsible
for any use of this information as applied to other units.
Important Safety Information
Warning: To avoid personal injury, property damage, or accidental damage to the product, read all of
the information in this section before using the product.
Work Area Safety
 Keep work area clean and well lit. Cluttered benches and dark areas may cause accidents.
 Do not connect or disconnect the tool while the ignition is on or the engine is running.
 DO NOT attempt to operate the tool while driving the vehicle. Have a second person to operate the
tool.
 Before testing a vehicle, put the transmission in PARK (for automatic transmission) or NEUTRAL (for
manual transmission). Engage the parking brake and chock the tires.
 NEVER smoke or allow a spark or flame in vicinity of battery or engine.
 The vehicle shall be tested in a well-ventilated work area, as engines produce various poisonous
compounds (hydrocarbon, carbon monoxide, nitrogen oxides, etc.)
 Do not operate the tool in explosive atmospheres, such as in the presence of flammable liquids,
gases, or heavy dust.
 Never leave the vehicle unattended while testing.
 Keep a fire extinguisher suitable for gasoline/chemical/electrical fires nearby.
 Use extreme caution when working around the ignition coil, distributor cap, ignition wires and spark
plugs. These components create hazardous voltages when the engine is running.
 Keep bystanders, children and visitors away while operating the tool.
 This product is not a toy. Do not allow children to play with or near this tool.
 Use as intended only. Do not modify.
 Inspect before every use; do not use if parts are loose or damaged.
 Do not place the tool on any unstable surface.
 Handle the tool with care. If the tool is dropped, check for breakage and any other conditions that
may affect its operation.
 Keep the tool dry, clean, free from oil, water or grease. Use a mild detergent on a clean cloth to clean
the outside of the tool when necessary.
 Store the tool and accessories in a locked area out of the reach of children.
 To avoid damaging the tool or generating false data, please make sure the vehicle battery is fully
charged and the connection to the vehicle DLC (Data Link Connector) is clear and secure.
 If the VCI (Vehicle Communication Interface) is not in use for a long period of time, it is suggested to
unplug the VCI from vehicle's DLC to conserve battery power.
Electrical Safety
 Do not use the tool while standing in water.
