Launch Creader Elite HD User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
HD
User Manual
WARNING
Read this material before using this product.
Failure to do so can result in serious injury.
V1.00.000
107013678

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Creader Elite HD and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Launch Creader Elite HD

Summary of Contents for Launch Creader Elite HD

  • Page 1 User Manual WARNING Read this material before using this product. Failure to do so can result in serious injury. V1.00.000 107013678...
  • Page 2 Statement: LAUNCH owns the complete intellectual property rights for the software used by this product. For any reverse engineering or cracking actions against the software, LAUNCH will block the use of this product and reserve the right to pursue their legal liabilities.
  • Page 3 • To take full advantage of the unit, you should be familiar with the engine. • LAUNCH shall not be liable for any damages or problems arising from the use of any options or any consumable products other than those designated as Original LAUNCH Products or LAUNCH Approved Products by LAUNCH.
  • Page 4 LAUNCH device will void the warranty right. • Caution: This tool contains an internal Lithium Polymer battery. The battery can burst or explode, releasing hazardous chemicals. To reduce the risk of fire or burns, do not disassemble, crush, pierce or dispose of the battery in fire or water.
  • Page 5 LAUNCH • Use extreme caution when working around the ignition coil, distributor cap, ignition wires and spark plugs. These components create hazardous voltages when the engine is running. • Put the transmission in P (for A/T) or N (for M/T) and make sure the parking brake is engaged.
  • Page 6 LAUNCH - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio / TV technician for help. The device has been evaluated to meet general RF exposure requirement.

  • Page 7: Table Of Contents

    LAUNCH Table of Contents 1 Overview ....................1 1.1 Vehicle Coverage ................1 1.2 OBD II On-Board Diagnostics ............. 2 1.3 OBD II Definitions ................2 1.4 I/M Monitors ..................3 1.5 OBD II (DTCs) Diagnostic Trouble Codes ........... 4 1.6 HD Protocols &...
  • Page 8 LAUNCH 5.2 Urea drive (DEF) ................24 5.3 Maintenance reset ................25 5.4 Injector coding .................. 25 5.5 Speed limit reset ................25 5.6 Cylinder cut-off, compression test ............. 25 5.7 Clutch learning ................. 26 6 Upgrade ..................... 27 6.1 Update Diagnostic Software & App ........... 27 6.2 Renew Subscription ................
  • Page 9 LAUNCH 7.13.8 User Manual ................30 8 FAQ ....................31 Warranty ....................32...

  • Page 11: Overview

    LAUNCH 1 Overview 1.1 Vehicle Coverage This diagnostic tool is designed to work with OBD II/CAN, J1587, J1708 and J1939 compatible vehicles. OBD II was installed in some 1994 and 1995 model year gasoline vehicles. To verify if a 1994 or 1995 vehicle is OBD II compliant, check the following: 1.

  • Page 12: Obd Ii On-Board Diagnostics

    LAUNCH 1.2 OBD II On-Board Diagnostics It is required by the EPA that all 1996 and newer vehicles sold in the United States be equipped with an OBD II computer system. OBD II is an early warning system designed to monitor engine, transmission, and emissions control components by performing specific diagnostic tests.

  • Page 13: I/M Monitors

    LAUNCH Criteria for the I/M Monitors to run and complete their diagnostic tests.  Control Modules Individual computers that operate and monitor different systems in the vehicle. Control Modules vary depending on manufacturer.  MIL: Malfunction Indicator Light The vehicle’s “Check Engine” warning light that activates when a DTC is stored.

  • Page 14: Obd Ii (Dtcs) Diagnostic Trouble Codes

    LAUNCH CAT - Catalyst HCAT - Heated Catalyst EVAP - Evaporative System AIR - Secondary Air System O2S - Oxygen Sensors HTR - Oxygen Sensor Heater EGR - EGR System 2. Diesel Engine Monitors  Continuous MIS - Misfire FUEL - Fuel System CCM - Comprehensive Components ...
  • Page 15 LAUNCH system, after repairs are made, and a set number of Driving Cycles have been completed. • The 1st character is a letter (B, C, P or U). It identifies the main system where the fault occurred (Body, Chassis, Powertrain, or Network).
  • Page 16 LAUNCH P0201 - Injector circuit malfunction, Cylinder 1...

  • Page 17: Hd Protocols & Diagnostic Trouble Codes

    LAUNCH 1.6 HD Protocols & Diagnostic Trouble Codes 1.6.1 HD Protocols SAE J1708, SAE J1587 and SAE J1939 are automotive diagnostic protocol standard developed by the Society of Automotive Engineers (SAE). SAE J1708 SAE J1708 is With respect to Open System Interconnection model (OSI), J1708 defines the physical layer.

  • Page 18: Dtcs For J1587/J1708 And J1939

    LAUNCH Adopted by diesel engine manufacturers, it can now be found in a range of diesel-powered applications, on and off-road vehicles, marine propulsion, power generation and industrial pumping. Applications of J1939 now include off-highway, truck, bus and even some passenger car applications.

  • Page 19: Product Descriptions

    LAUNCH 2 Product Descriptions 2.1 Components & Controls 1. Charging Port Charge the tool. 2. DB-15 Diagnostic Connector Connect it to the vehicle’s Data Link Connector (DLC) port. 3. Power Button Turn on/off the tool. 4. Touch Screen Indicates test results.

  • Page 20: Technical Specifications

    LAUNCH Return to previous menu. 2.2 Technical Specifications • Screen: 3.97” touch screen • Operating system: Android • CPU: 1.3GHz processor • RAM: 2GB • ROM: 16GB • WiFi: 802.11b/g/n 2.4GHz • OBDII input voltage range: 24V • Power up via: •...

  • Page 21: Initial Use

    LAUNCH 3 Initial Use 3.1 Charging There are two charging methods available: Via Diagnostic Cable: Insert the diagnostic cable into the vehicle’s DLC port. Via Data Cable: Plug one end of data cable (not included) into the charging port of the tool, and the other end to the PC.

  • Page 22: Job Menu

    LAUNCH workshop information. Input the required information, and tap “Next Step” to go to next step. Note: You are strongly recommended to fill in the valid email address. After you configured this option, the system will append it on the report every time a report is successfully generated.

  • Page 23: Diagnose

    LAUNCH 4 Diagnose 4.1 Connection 1). Turn the ignition off. 2). Locate the vehicle’s Data Link Connector (DLC) port. The DLC is normally located in driver’s cab (Refer to the vehicle’s owner manual for location of DLC). 3). Plug the diagnostic cable into the DB-15 diagnostic connector on the tool, and then tighten the captive screws.

  • Page 24: System Diagnostics

    LAUNCH b) For non-standard OBD II DLC, connect one end of the adaptor to the diagnostic cable, and the other end to the vehicle’s DLC port. Note: The adaptor is keyed and will only fit one way. If you have problems connecting the adaptor to the DLC, rotate the connector 180 and try again.

  • Page 25: Manual Diagnosis

    LAUNCH User can tap the desired system to start diagnosis. B. If the tool failed to access the VIN information, it will automatically enter the scan mode selection screen. Tap “Manually select” to enter the Manual Diagnosis mode. Refer to Chapter 4.2.2 for details.
  • Page 26 LAUNCH A. Version Information This option can read the version information of system mode, vehicle VIN, software and ECU. B. Read Fault Code This function displays the detailed information of DTC records retrieved from the vehicle’s control system. Tap “ Read Fault Code” on the test function selection screen, the screen will display the diagnostic result.
  • Page 27 LAUNCH part of an overall diagnostic strategy. Never replace a part based only on the DTC definition. Each DTC has a set of testing procedures, instructions and flow charts that must be followed to confirm cause of the problem. Refer to vehicle’s service manual for detailed testing instructions.
  • Page 28 LAUNCH have been carried out, you can use this function to erase the codes from the vehicle. Before performing this function, please be sure the vehicle’s ignition key is in the ON position with the engine off. Notes: 1. If you plan to take the vehicle to a Service Center for repair, DO NOT erase the codes from the vehicle’s computer.

  • Page 29: Obd Diagnosis

    LAUNCH On-screen Buttons: Combine: Tap to merge values in waveform for easier comparisons. Maximum 4 items can be selected at the same time. Report: To save the current data in text format. All diagnostic reports can be accessed from “Settings” -> “Data” -> “Diagnostic Report”.
  • Page 30 LAUNCH 1. After the tool is properly connected to the vehicle’s DLC, tap “HD OBD” to enter the following screen. Tap “System Automatic Search” to scan which systems are equipped on the test vehicle automatically. Tap “System Manual Selection” to manually select the desired system to proceed.

  • Page 31: Eobd Ii

    LAUNCH 4.3.2 EOBD II This option presents a quick way to check for DTCs, isolate the cause of the illuminated Malfunction Indicator Lamp (MIL), check monitor status prior to emissions certification testing, verify repairs, and perform a number of other services that are emission-related.
  • Page 32 LAUNCH This function checks whether or not the various emissions-related systems on the vehicle are operating properly, and are ready for Inspection and Maintenance testing. It can also be used to check the Monitor Run Status, and to confirm if the repair of a car fault has been performed correctly.

  • Page 33: History

    LAUNCH  CID (Calibration ID).  CVN (Calibration Verification Number). 4.4 History The History function provides direct access to the previously tested vehicles. Users can resume from the last operation, without starting from scratch. Tap “History” on the Diagnose main menu screen, all diagnostic records...

  • Page 34: Reset

    LAUNCH 5 Reset It offers coding, reset, relearn and more service functions, to help vehicles get back to functional status after repair or replacement. Available tests vary by vehicle manufacturer, year, and model. Due to continuing improvements, available service functions are subject to change without prior written notice.

  • Page 35: Maintenance Reset

    LAUNCH This function can drive the urea pump to perform reverse pumping, compression, injection and other operations through the diagnostic scanner. It needs to be performed in the following cases: • After the urea pump maintenance is performed. 5.3 Maintenance reset...

  • Page 36: Clutch Learning

    LAUNCH normal or not by separately cutting off certain cylinder and checking the working status of the engine. It needs to be performed in the following cases: • When engine is running abnormally or certain cylinder does not work. 5.7 Clutch learning This function can relearn clutch values to ensure normal operation of the clutch.

  • Page 37: Upgrade

    LAUNCH 6 Upgrade This function allows you to update the diagnostic app and software. All software is updated periodically. It is recommended to update and install the latest software version for the best service, functions and experience. 1). Use and update of the diagnostic software pre-installed on the tool is free of charge forever.

  • Page 38: Settings

    LAUNCH 7 Settings 7.1 Units of measurement This option can set the measurement unit. Metric System and English System are available. 7.2 Automatic detection on connect This option enables you to determine whether to start an automatic VIN detection once the tool is properly connected to the vehicle’s DLC.

  • Page 39: Recovery

    LAUNCH 7.9 Recovery This option can reset this tool to the default factory setting. Warning: Resetting may cause data loss. Before doing so, please be careful to perform this operation. 7.10 Clean Up This option allows user to clear some cache files and free up the storage space.

  • Page 40: Image

    LAUNCH This function helps you to find the location of the vehicle’s DLC. 7.13.5 Image This option allows you to view and manage all screenshots. 7.13.6 Feedback This item allows you to send the feedback of your diagnostic problems to us for further analysis and troubleshooting.
  • Page 41 LAUNCH 8 FAQ Here we list some frequently asked questions and answers related to this tool. 1. System halts when reading data stream. What is the reason? It may be caused by a slackened connector. Please turn this tool off, firmly connect the connector, and switch it on again.

  • Page 42: Warranty

    The exclusive remedy for any automotive meter found to be defective is repair or replacement, and LAUNCH shall not be liable for any consequential or incidental damages. Final determination of defects shall be made by LAUNCH in accordance with procedures established by LAUNCH.
  • Page 43 FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
  • Page 44 LAUNCH Statement: LAUNCH reserves the rights to make any change to this manual without notice. We have tried our best to make the descriptions and illustrations in the manual as accurate as possible, and defects are inevitable, if you have any question, please contact local dealer or LAUNCH TECH CO., LTD., LAUNCH...
