Introduction
Packaging Content
Lists the components included in the product packaging, such as hood, bolts, clamps, and washers.
Installation Set-up
Step 1: Attach Hood
Attaches the hood to the UBR using four M6 flange nuts, ensuring the cut aligns with the lug connector.
Step 2: Attach Pole Clamp Assembly
Connects the pole clamp assembly and riveted U clamp using three M6 hex bolts and split spring lock washers.
Step 3: Mount Assembly on UBR
Mounts the previously assembled components onto the UBR using three M6 hex bolts and split spring lock washers.
Step 4: Mount on Pole
Mounts the assembled UBR onto the pole using M8 x 220 bolts, split spring lock washers, and flat washers.
Getting the UBR Online
Step 1: Connect Ethernet to Laptop/Computer
Connects an Ethernet cable from the UBR to a laptop or computer for initial setup.
Step 2: Connect Ethernet to PoE Adapter
Connects the other end of the Ethernet cable to the data port on the PoE adapter.
Step 3: Connect UBR to PoE Adapter
Connects the UBR's PoE-supported Ethernet port to the PoE adapter's power port for device activation.
Step 4: Access UBR via Web Browser
Opens a web browser and enters the default IP address (192.168.1.1) to access the UBR interface.
Step 5: Login Screen Appears
The system displays a login screen after accessing the UBR's IP address.
Step 6: Enter Login Credentials
Enters the default user credentials 'admin' and password 'HFcl!@23#ion' to access the UBR.
Step 7: Refer to User Manual
Directs users to the website for detailed configuration information in the user manual.
