- Page 1 Quick Start Guide ion4l2/ion4l3/ion4l4 ion4l2_ext/ ion4l3_ext/ion4l4_ext UNLICENSED BAND RADIO Point to Point High Capacity Radio...
- Page 2 ANYWHERE EVERYWHERE...
- Page 3 Introduction Thank you for purchasing our Unlicensed Band Radio (UBR). IO enterprise/carrier grade P2P solution is designed to serve highly critical enterprise applications in unlicensed 5 GHz spectrum for short-range and long-range links. Packaging Content 2x2 UBR (QTY:1) 2x2 UBR EXTENDED TEMP (QTY:1) (1.) (2.) (3.)
-
Page 4: Product Specifications
Product Specifications Peak Throughput Up to 700 Mbps Aggregate UL/DL Throughput (aggregate) Radio Mode 2x2 MIMO Modulation Upto 256 QAM Channel Bandwidth 10/20/40/80 MHz Wireless QoS 802.11e WMM Wireless Security WPA, WPA2 and 256-bit AES PSK with hardware acceleration Power Supply IEEE 802.3af/at PoE Power Consumption (Max) <15 W (max) - Page 5 Weight For Normal Temperature Variant: ion4l2 : 1.7 Kg ion4l3 : 2.0 Kg ion4l4 : 2.6 Kg For Extented Temperature Variant: ion4l2_ext : 2.4 Kg ion4l3_ext : 2.7 Kg ion4l4_ext : 3.3 Kg Operating Temperature -15ºC to 55ºC (Normal temperature operation) -40ºC to 55ºC (Extended temperature operation) Certifications FCC Class A, CE, RoHS 3.0, IP67...
-
Page 6: Product Overview
Product Overview Earthing Point Dish Antenna LAN + POE Port (with gland) [To Power up the device using PoE adaptor and a regular Ethernet cable]... -
Page 7: Installation & Setup
Attach the pole clamp assembly with a riveted U clamp with the help of three M6 hex bolts and split spring lock washers Insecure mounting might damage the device or cause injury. Note: HFCL cannot be held liable for any damages incurred during the process. - Page 8 Mount this assembly from the previous step on UBR using three M6 hex bolts and split spring lock washers. Once the UBR is assembled, the next step is to mount it on the pole using two M8 x 220 threaded rods, four split spring lock washers, and flat washers.
- Page 9 For Link Alignment Slightly loosen the M6 bolts, and rotate brackets to align the pointer mark, at an optimum angle to set the azimuth and elevation. Once the desired setting is attained, securely tighten the six bolts using a compatible spanner. Note: Angle marking for azimuth adjustment &...
- Page 10 Configure a computer with a 1-domain static IP address e.g. 192.168.1.X and a subnet mask of 255.255.255.0. Laptop/ Computer PoE Adapter (48V) Ethernet Cable Ethernet Cable For powering on UBR, only use HFCL PoE adapter. Note: Plug and Adaptor will vary by country/region.
- Page 11 The default static IP address for 2x2 UBR is set to “192.168.1.1”. A login screen will appear Enter the default login credential details: User- admin, Password- HFcl!@23#ion Refer to our user manual on our website io.hfcl.com for detailed information to configure UBR.
- Page 12 Step 2: Check the LED status LED COLOR STATUS Green color notifies the user Green LED (Power indication) that the device is powered ON Single blink: -1 to -50 dBm Double blink: -51 to -60 dBm Triple blink: Lesser than -60 dBm BLUE LED (RSSI/Link indication) NOTE: If the link is down, then the link LED will be in continuous OFF State.
-
Page 13: Safety Precautions
Safety Precautions Observe the following safety precautions to avoid damage to the UBR: Do not power the device during installation. Do not subject the device to high temperatures. Keep away from high voltage cables. Do not power off the unit in the middle of an upgrade process. The gland should be ground facing all the time. - Page 14 | io.hfcl.com Contact Us: 8, Commercial Complex, Masjid Moth, Greater Kailash-II, New Delhi- 110048 HFCL Limited All Rights Reserved. HFCL and io by HFCL are trademarks or registered trademarks of HFCL Ltd. Specifications are subject to change without notice.
