BENDIX TABS-6 TRAILER ABS MODULE Manual page 11

Diagnostic Trouble Codes
Fault Description
1st 2nd
Digit Digit
6 1 Over-voltage
6 2 Low-voltage
6 3 Excessive power line resistance
7 1 MOD1 Hold solenoid shorted or open
7 2 MOD1 Release solenoid shorted or
open
8 1 MOD2 Hold solenoid shorted or open
9 1 MOD3 Hold solenoid shorted or open
8 2 MOD2 Release solenoid shorted or
open
9 2 MOD3 Release solenoid shorted or
open
7 3 MOD1 ABS modulator dynamic error
8 3 MOD2 ABS modulator dynamic error
9 3 MOD3 ABS modulator dynamic error
8 4 MOD2 Valve configuration error
9 4 MOD3 Valve configuration error
10 1 Valve MOD1/2 low-side switch shorted
to ground
10 2 Valve MOD3 low-side switch shorted
to ground
10 3 ABS modulator dynamic error - all
valves
10 4 Excessive ABS activity
11 1 ECU internal error
11 2 ECU configuration error
Repair Information
POWER
• Power supply diagnostic trouble code.
Go to Section F, page 28.
• Power supply diagnostic trouble code.
Go to Section F, page 28.
• Power supply diagnostic trouble code.
Go to Section F, page 28.
MODULATOR (MOD)
• Clear faults.
• If faults return, replace the TABS-6 Module.
Static ABS Modulator Fault.
Go to Section H, on Page 30.
Dynamic ABS Modulator Fault.
Go to Section H, on Page 30.
• Verify correct ABS configuration using blink codes
or other diagnostic tools.
• If needed, reset to the default ABS configuration
and power-up to initiate auto-configuration.
COMMON
• Check for corroded/damaged wiring or connectors
between the ECU and MOD.
At the MOD harness connector, verify:
• No continuity from modulator/AUX leads to ground.
• After repairs or if no issues found, then clear faults.
• If faults return, replace the TABS-6 Module.
Dynamic ABS Modulator Fault.
Go to Section H, on Page 30.
Dynamic Wheel Speed Sensor Fault.
Go to Section G, on Page 29.
ELECTRONIC CONTROL UNIT (ECU)
• Check for damaged or corroded connectors.
• Check for damaged wiring.
• After repairs or if no issues found, then clear faults.
• If faults return, replace the TABS-6 Module.
• Verify correct ABS configuration using blink codes,
PC-diagnostics or other off-board diagnostic tools.
• If needed, reset to the default ABS configuration and
power-up to initiate auto-configuration.
(DTCs)
(continued)
J1587 J1587
(SID) (FMI)
251 3
251 4
251 13
42 3, 4, 5
6 or 12
48 3, 4, 5
6 or 12
43 3, 4, 5
6 or 12
44 3, 4, 5
6 or 12
49 3, 4, 5
6 or 12
50 3, 4, 5
6 or 12
7 7
8 7
9 7
8 13
9 13
7 4
9 4
7 7
1 7
254 12
254 13
(Continued over . . .)
