BENDIX TABS-6 TRAILER ABS MODULE Manual page 19

Troubleshooting: System Schematics
2S/2M - AXLE CONTROL
7-PIN
CONNECTOR
Ground
Ignition
Power
Brake Light
Power
Dual Axle Trailer
Installation Guidelines for the TABS-6 2S/2M Axle ABS Configuration:
o MOD1 (TABS-6 ABS Unit) controls the left "road-side" wheel(s) of a primary axle(s).
o MOD2 ( Bendix BR9235
®
o SL & SR (Primary Sensors) senses wheels on the primary axle (always on ground) that MOD1 controls.
o For lift axle applications, MOD2 controls the wheels for the lift-able axle
2S/2M - SIDE CONTROL
7-PIN
CONNECTOR
Ground
Ignition
Power
Brake Light
Power
Dual Axle Trailer
Installation Guidelines for the TABS-6 2S/2M Side ABS Configuration:
o MOD1 (TABS-6 ABS Unit) controls the left "road-side" wheel(s) of a primary axle(s).
o MOD2 (Bendix BR9235
®
o For lift axle applications, SL & SR (Primary Sensors) senses the wheels of the stationary, non lift-able axle
A Brake Light Power
D
C
B Ignition Power
C NC
A
E
D Warning Lamp
B
E Ground
5-PIN
Trailer
CONNECTOR
Chassis Harness
ABS
Modulator Unit) controls the wheels of an additional axle(s).
™
A Brake Light Power
D C
B Ignition Power
C NC
A
E
D Warning Lamp
B
E Ground
5-PIN
Trailer
CONNECTOR
Chassis Harness
ABS
Modulator Unit) controls the right "curb-side" wheel(s) of a primary axle(s).
™
Right - "Curb-Side"
Trailer ABS
Pigtail Harness
SR-5 Trailer
™
Spring Brake
Valve
ABS Light
Left - "Road-Side"
Right - "Curb-Side"
Trailer ABS
Pigtail Harness
SR-5
Spring Brake
Valve
ABS Light
Left - "Road-Side"
(continued)
WS Sensor
"SR"
"MOD2"
Bendix
®
BR9235
™
"MOD1"
Modulator
TABS-6
Relay
Trailer
Valve
ABS
Module
WS Sensor
"SL"
WS Sensor
"SR"
Bendix
BR9235
Modulator
Relay Valve
"MOD2"
Trailer
™
"MOD1"
TABS-6
Trailer
ABS Module
WS Sensor
"SL"
®
™
9
