Symptom:
16.0 Compressor
leaks air
Testing for leaks with
soap solution.
17.0 Compressor
leaks coolant
18.0 Noisy
compressor
(Multi-cylinder
compressors only)
This guide attempts to cover most com-
pressor system problems. Here are some
rare sources of problems not covered in
this guide:
• Turbocharger leakage. Lubricating oil
from leaking turbocharger seals can enter
the air compressor intake and give mis-
leading symptoms.
What it may indicate:
(a) Compressor leaks air at connections
or ports.
(b) Compressor unloader mechanism
malfunction.
(c) Damaged compressor head
gasket(s).
Head
gaskets
locations
(a) Improperly installed plugs or coolant
line fittings.
(b) Damaged compressor head
gasket.
(c) Porous compressor head casting.
(a) Damaged compressor.
Other Miscellaneous Areas to Consider
What you should do:
 Check for leaking, damaged or defective
compressor fittings, gaskets, etc. Repair
or replace as necessary.
 Go to Test 6 on page 25.
 An air leak at the head gasket(s) may
indicate a downstream restriction such as a
freeze-up or carbon blockage and/or could
indicate a defective or missing safety valve.
Find blockage (go to 9.0(f) for details) and
then replace the compressor. Do not re-
use the safety valve without testing. See
Symptom 12.0(a).
 Inspect for loose or over-torqued fittings.
Reseal and tighten loose fittings and plugs
as necessary. If overtorqued fittings and
plugs have cracked ports in the head,
replace the compressor.
 An air leak at the head gasket may indicate
a downstream restriction such as a freeze-
up or carbon blockage and/or could indicate
a defective or missing safety valve. Find
blockage (go to 9.0(f) for details) and then
replace the compressor. Do not re-use the
safety valve without testing. See Symptom
12.0(a).
 If casting porosity is detected, replace the
compressor.
 Replace the compressor.
• Where a compressor does not have
a safety valve installed, if a partial or
complete discharge line blockage has
occurred, damage can occur to the con-
necting rod bearings. Damage of this kind
may not be detected and could lead to
compressor problems at a later date.
